Product No.
FED355EBA
37854335E5061 37854335E5011
Series
30" drop-in
Color
black
Market
North America
Wiring Diagram
318271906
Owner's Guide
318203810
Installation Instructions 318201613
Timer Guide
318200184
Publication No.
5995441572
05/07/13
(EN/SERVICE/ECL)
377
FED355ESA
30" drop-in
white
North America
318271906
318203810
318201613
318200184
30-INCH DROP-IN
ELECTRIC RANGE
Model No.
FED355E
©
Copyright
2005 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Related Manuals for Frigidaire FED355E
Summary of Contents for Frigidaire FED355E
- Page 1 Product No. Series Color Market Wiring Diagram Owner's Guide Installation Instructions 318201613 Timer Guide FED355E.eps la20bg0034.eps B79045482500.eps LA20CT0050.eps D79046592500.eps 318271906.eps Electrolux Major Appliances North & Latin America P.O. BOX 212378 AUGUSTA, GA 30917 FED355EBA FED355ESA 37854335E5061 37854335E5011 30" drop-in 30" drop-in...
- Page 2 Publication No: 5995441572 FED355E BACKGUARD 07/05...
- Page 3 318301100 318224812 318224815 08016432 5303300265 # Functional Parts * Non-Illustrated Parts FED355E BACKGUARD A FED355E (FED355ESA) B FED355E (FED355EBA) DESCRIPTION Light, indicator, 125v, (2) Console, assy., white Console, assy., black Clip, console, (2) Panel, control, white Panel, control, black Panel, control mtg.
- Page 4 Publication No: 5995441572 FED355E BODY 07/05...
- Page 5 5303211311 5303307980 5303323129 5304415832 5304436875 # Functional Parts * Non-Illustrated Parts FED355E BODY A FED355E (FED355ESA) B FED355E (FED355EBA) DESCRIPTION Back, main Panel, main back, upper Shield, insulation, upper Panel, bodyside, upper RH Panel, bodyside, upper LH Panel, subtop Rack, oven...
- Page 6 Publication No: 5995441572 FED355E MAIN TOP 07/05...
- Page 7 318122500 318301000 5303211311 5303300265 # Functional Parts * Non-Illustrated Parts FED355E MAIN TOP A FED355E (FED355ESA) B FED355E (FED355EBA) DESCRIPTION Element, surface, 8", large Element, surface, 6", small Main Top, white Main Top, black Rod, support, main top panel Hinge, maintop, (2)
- Page 8 Publication No: 5995441572 FED355E DOOR 07/05...
- Page 9 316221001 5304415832 # Functional Parts * Non-Illustrated Parts FED355E DOOR A FED355E (FED355ESA) B FED355E (FED355EBA) DESCRIPTION Trim, oven door, black, upper Trim, oven door, side, (2) Glass Assy., oven door, white, outer, w/trim Glass Assy., oven door, black, outer, w/trim...
-
Page 10: Wiring Diagram
Publication No: 5995441572 FED355E WIRING DIAGRAM 07/05...
