System Presentation; Overview Iris - IT Concepts iRis DVR X Operation Manual

System Presentation

Edge Protector
Control Panel
12,7cm (5") TFT
VGA Colour Display
Pins for
Neck Holder
Bedienhebel
oben/unten
Live and saved images as well as
video recordings are shown on the
TFT Display. Image captures and video
recordings can be marked with a text
line.
The probe can be inserted to a
cavity, e.g. a tube. The user can
lock the articulating head of the
probe in the desired position during
inspections. The articulation can be
moved in four directions (up/down and
left/right) which really facilitates passing
multiple covings.
9 9
SD Card Slot
(under Edge Protector)
Control Panel
Lever (left/right)
