Content
Introduction ........................................... 5
Warning Notices and Precautions ......... 6
Scope of Delivery ................................... 8
System Presentation
Overview iRis ........................................................... 9
The Control Panel .................................................. 11
Preparing the iRis
Charging the Battery .............................................. 12
Working with Mains Supply .................................... 13
Inserting the SD Card ............................................. 14
Starting Inspection
Switching-on the iRis ............................................. 15
Status Indicator Line .............................................. 15
Switching-On the LED Light Source ....................... 15
Language Selection ............................................... 16
Format SD Card ..................................................... 17
Setting Time and Date ........................................... 18
Resetting to Default Settings .................................. 19
Image Control ........................................................ 20
Turning the Display ................................................. 21
Controlling the Articulation ..................................... 21
Passing Covings .................................................... 22
Retracting the Endoscope ...................................... 23
Creating and saving Image Captures
Choosing a Standard Setting ................................. 24
Inserting Text ......................................................... 25
Image Capture and Video Recording
in Mode „OFF" ....................................................... 26
Image Capture and Video Recording
in Mode „ON" ........................................................ 27
Comparative Measuring with the iRis .....29
Playback of saved Images and
Video Recordings ....................................30
Optimising Camera Settings
Camera Setting ...................................................... 33
Camera Setting Standard ....................................... 34
Camera Setting Manual .......................................... 35
Cleaning and Care ............................... 36
Transport and Storage ......................... 38
Spare Parts and Accessories .............. 39
Service ................................................. 40
Technical Specifications ....................... 40
