Air Purifier Installation
Features
Air Outlet
Display
Top View
Installation
1. Remove Vacuum Cleaning Robot's cover. (Figure 1)
2. Install the cover onto the Air Purifier Module. (Figure 2)
3. Install the Air Purifier Module onto Vacuum Cleaning
Robot. (Figure 3)
4. Air Purifier Module and Vacuum Cleaning Robot properly
installed. (Figure 4)
Figure 2
C onnectors
Control Panel
Power Socket
Figure 3
20
Filter Holder
Air Inlet
Bumper
Bo om View
Figure 1
Figure 4.
