Summary of Contents for Milagrow AguaBot 21
- Page 1 AguaBot 21 Floor Mopping Robot User Guide...
- Page 2 Thank you for choosing Milagrow AguaBot 21 Floor Mopping Robot! You’ve joined millions of people to get cleaning done robotically. This user manual helps you to keep your robot performing at its best. Please take a few moments to read through it.
-
Page 3: Table Of Contents
AguaBot 21 Contents 1. Important Safety Instructions ............1 2. Important Tips ....................3 2.1 How to start ....................3 2.2 How to perform the best ................3 3. In the Box ......................5 4. Product Anatomy ..................6 4.1 Main body ......................6 4.2 Display panel ....................6 4.3 Host machine ....................7... - Page 4 AguaBot 21 Contents 7. APP Download ..................17 8. Maintenance ....................18 8.1 Clean the dirty water tank ...............18 8.2 Clean the main brush .................19 8.3 Clean the filter ....................20 8.4 Clean the water tank openings ...............20 8.5 Clean the metal pins on the dirty water tank /main body / charging dock ....................21...
-
Page 5: Important Safety Instructions
AguaBot 21 Important Safety Instructions When using electrical appliance, basic precautions should always be followed, including the following: Read all instructions before using this appliance. WARNING - To reduce the risk of fire, electric shock, or injury. Do not leave appliance when plugged in. Unplug from outlet when not in use and before servicing. - Page 6 AguaBot 21 Important Safety Instructions CAUTION- To reduce the risk of injury from moving parts, unplug before servicing. Do not allow robot to clean anything that is burning or smoking, such as cigarettes, matches, or hot ashes. Do not use without water tank in place.
-
Page 7: Important Tips
AguaBot 21 Important Tips Milagrow AguaBot 21 contains electronic parts. DO NOT immerse the robot’s main body in water. How to start Turn on/off To turn the robot on, press for 0.5s. To turn it off, press for 3s. Release the button after a sound alert. - Page 8 AguaBot 21 Important Tips The robot works on a variety of hard floor surfaces, such as porcelain tiles, vinyl flooring, and laminated floors. The robot performs well on tile floor with small gaps. Tile Tile The robot does not work properly on tile floors with gaps wider than 10mm.
-
Page 9: In The Box
AguaBot 21 In the Box Robot main body Charging dock Adapter (include a main brush) Extra Main brush Cleaning tool Remote control User guide For more details, please visit www.milagrowhumantech.com... -
Page 10: Product Anatomy
AguaBot 21 Product Anatomy Main body Water tank release button Handle Front bumper Dirty water outlet Side wheel Display panel Cleaning modes Start/Stop clean Camera Area mode Water tank alert Path mode WIFI indicator For more details, please visit www.milagrowhumantech.com... -
Page 11: Host Machine
AguaBot 21 Product Anatomy Host machine Integrated water tank Dirty water level detector Main brush Main brush soft cap Main brush gearwheel Clean water inlet Fan-coil inlet For more details, please visit www.milagrowhumantech.com... - Page 12 AguaBot 21 Product Anatomy Side wheel Sprinkler nozzles Cliff sensors Charging pins Universal wheel Side wheel Cliff sensors Rear wheel Lock button Suction passage Scraper Fan-coil outlet Clean water outlet Minimum water level Clean water inlet cap For more details, please visit...
-
Page 13: Remote Control
AguaBot 21 Product Anatomy Remote control Right Left Down Path mode Area mode Spot mode Voice (Turn on/off the voice alert) Water flow (Adjust water flow from 1st-3rd level) Repeat (Repeat cleaning 3 times at max) Brush (Adjust brush speed from low to high) Up/Down/Left/Right Direction can only be changed when the robot is on standby. -
Page 14: Indicator
AguaBot 21 Product Anatomy Indicator Lights Status Orange light flashes Charging Green Light goes out Fully charged Green light flashes Select modes Red light goes on Machine fault Orange light flashes Low battery Green light goes on Auto Mode Green light goes on... -
Page 15: Installation
AguaBot 21 Installation Install the charging dock Milagrow AguaBot 21 is not a self-charging robot. Please take it to the dock manually for recharging after each use. Step 1 Turn the charging dock Plug in the power cord. Secure wires around the cable channel. -
Page 16: Install The Main Brush
AguaBot 21 Installation Install the main brush It's recommended to properly dampen the main brush before installation for better cleaning performance. Insert the recessed end of the main brush into the gearwheel. Press down on the capped end into the other end of the main body. - Page 17 AguaBot 21 Installation Step2. Install the water tank Align the bottom of the integrated water tank with the main body and push forward. Align Align the ends and move the water tank to insert it into the main body. Align Press from the top until a splat is heard.
-
Page 18: Start Cleaning
AguaBot 21 Start Cleaning Select cleaning mode Press button on robot to select cleaning modes. When the cleaning mode is selected, its related indicator light will be in green. Then press button to start cleaning. Remote control and APP can be also used to select cleaning modes. - Page 19 AguaBot 21 Start Cleaning Area mode Recommended to clean a specific area. The robot will clean the area ahead of its starting point at zigzag path. It will return to the starting point when cleaning finished. Press button to pause the robot.
-
Page 20: Place The Robot
AguaBot 21 Start Cleaning Spot mode Recommended to clean a localized area with heavy stains. The robot cleans in “spiral” path and return to the starting point and goes into standby mode when cleaning finished automatically. (The below right picture shows the cleaning path of Spot mode, subject to the actual situation. -
Page 21: App Download
AguaBot 21 APP Download Downloading the APP The robot can be controlled by the "Milagrow AguaBot 21" app. Please find the APP with its name "Milagrow Aguabot Robot" on Google Play/APP store. Or check our website www.milagrowhumantech.com for the QR code downloading. -
Page 22: Maintenance
AguaBot 21 Maintenance To keep the robot running at peak performance, you are advised to perform the following maintenance regularly: Component Maintain Replace Water tank After each use Main brush Once per week 3-5 months Suction passage Once per week... -
Page 23: Clean The Main Brush
AguaBot 21 Maintenance Clean the main brush Remove the integrated water tank and take out the main brush, then rinse with clean water. Detach the integrated Remove the main brush water tank. from the robot body. Remove all the debris on Rinse the main brush with the main brush. -
Page 24: Clean The Filter
AguaBot 21 Maintenance Clean the filter Remove the filter from the water tank and rinse with water. Filter Remove the filter. Rinse it with water. Clean the water tank openings After removing the filter, press the water tank lock button to open the fan-coil outlet. -
Page 25: Clean The Metal Pins On The Dirty Water Tank /Main Body / Charging Dock
AguaBot 21 Maintenance To keep the tanks tightly sealed, clean the inlet and outlet, and the caps of both tanks regularly. Caps Inlet Outlet Caps Clean the metal pins on the dirty water tank /main body / charging dock Wipe the the metal pins on the dirty water tank /main body / charging dock regularly with dry clean cloth. -
Page 26: Clean The Universal Wheel
AguaBot 21 Maintenance Clean the universal wheel Turn the robot upside down and check if the universal wheel can rotate smoothly. Remove the universal wheel by pulling it out vertically. Check if there is any hair or debris stuck on it. -
Page 27: Troubleshooting
AguaBot 21 Troubleshooting Voice Alerts Alert Light signal Possible cause Solution Please install Water tank isn't Ensure the water tank installed or water tank is installed properly. correctly properly installed. The green Clean water tank Please fill the •Fill with clean water... -
Page 28: Others
AguaBot 21 Troubleshooting Others Solutions Malfuntions Check the air inlet and outlet. Dirty water leak Clean up the sealing rings. Check if the roller brush is installed. (Refer to page 12 as how to install) Do not suck dirty Check if the filter is blocked. (Refer to page 19 as... -
Page 29: Product Specifications
AguaBot 21 Product Specifications Specification Description Battery DC 14.8V 2900mAh Li-ion Input: AC 100-240V~50/60HZ 0.5A max Adaptor Output: DC 19V 0.6A Clean water tank capacity 0.85L Dirty water tank capacity 0.9L Charging time <380mins Working time >80mins Main body size... -
Page 30: Warrantycard
AguaBot 21 Warranty Card Username Address Telephone number Postal code Product model Purchase date Invoice number Warranty date Date Repairman Repair records Product Warranty Description: 1. There isn’t man-made damage and the packaging, products and all accessories (including gifts) are complete, the user can apply for refund or replacement within 7 days from the date of purchase.
