PRODUCT NO.
BASE MODEL NO.
PLEB27S8CCA
PLEB27S8C
WIRING DIAGRAM - # 318046208
OWNER'S GUIDE - # 318200919
TIMER INSTRUCTION SHEET - # 318200181
INSTALLATION INSTRUCTIONS - # 318201507
ELECTROLUX HOME PRODUCTS, INC.
P.O. BOX 212378, Augusta, GA 30917
FACTORY PARTS CATALOG
FACTORY NO.
COLOR
38257793G30S1
stainless
Publication No.
5995379368
021007
-EN/SERVICE /ECL
377
RANGE
MARKET
North America
ELECTRIC
WALL OVEN
Model No.
PLEB27S8C
©2002 Electrolux Home Products, Inc.
All rights reserved
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire PLEB27S8C
Summary of Contents for Frigidaire PLEB27S8C
- Page 1 PRODUCT NO. BASE MODEL NO. PLEB27S8CCA PLEB27S8C WIRING DIAGRAM - # 318046208 OWNER’S GUIDE - # 318200919 TIMER INSTRUCTION SHEET - # 318200181 INSTALLATION INSTRUCTIONS - # 318201507 ELECTROLUX HOME PRODUCTS, INC. P.O. BOX 212378, Augusta, GA 30917 FACTORY PARTS CATALOG FACTORY NO.
-
Page 2: Control Panel
Publication No. PLEB27S8CCA 5995379368 CONTROL PANEL 10/02... - Page 3 318028330 Trim,canopy 318111602 Bracket,clock & relay 318027310 Trim,vent 318037200 Cover,oven vent ,stainless 318029602 Trim,top ,stainless steel 318111501 Relay,convection ,oven light ,(2) 316037700 Seal,vent cover 316037800 Tape,vent cover 5303300265 Screw,8-18 x 0.500 ,chrome 218490900 Cleaner,stainless steel 3201861 Screw,6 x 0.375 08002868 Screw,10-24 x 0.500 ,probe,thrm brkt ,shield,drwr,box...
- Page 4 Publication No. PLEB27S8CCA 5995379368 BODY 10/02...
- Page 5 Rack,broiler pan 318025200 Shelf,oven 5303317977 Pan,broiler 5303317976 Insert,broiler pan 318089913 Switch,light 5308011085 Receptacle,oven light 5303013071 Bulb/Lamp,oven light 3201911 Cover,oven light ,glass 5304400195 Retainer,light cover 316111203 Sensor,oven temp probe 5303310526 Cover,hinge cutout 5303310514 Housing,oven light 318145516 Trim,bodyside 318133758 Insulation,oven wrapper 318133749...
- Page 6 Publication No. PLEB27S8CCA 5995379368 DOOR 10/02...
- Page 7 DESCRIPTION 318073502 Shield,air wash 318133751 Insulation,oven door 318156705 Liner,oven door 5303311174 Screw,10-24 x 3/8 318053100 Seal,oven door 318187932 Stainless Panel,oven door ,w/ glass/nmplt 318172903 Stiffener,glass 318042300 Glass,oven door ,heat barrier ,(2) 318042000 Spacer,glass 318053000 Seal,rope 5303310511 Bar,glass retainer 5303320452 Hinge,oven door...
-
Page 8: Wiring Diagram
Publication No. PLEB27S8CCA 5995379368 WIRING DIAGRAM 10/02...
