Frigidaire PLEB27S8A Factory Parts Catalog

Electric wall oven
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
PLEB27S8ACA
PLEB27S8A
WIRING DIAGRAM - # 318046208
OWNER'S GUIDE - # 318200919
TIMER INSTRUCTION SHEET - # 318200181
INSTALLATION INSTRUCTIONS - # 318201507
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. BOX 212378, Augusta, GA 30917
FACTORY PARTS CATALOG
FACTORY NO.
COLOR
38257793G10S1
stainless
Publication No.
5995363578
020110
-EN/SERVICE /ECL
377
RANGE
MARKET
North America
ELECTRIC
WALL OVEN
Model No.
PLEB27S8A
©2002 White Consolidated Industries, Inc.
All rights reserved

Advertisement

loading

Related Manuals for Frigidaire PLEB27S8A

Summary of Contents for Frigidaire PLEB27S8A

  • Page 1 PRODUCT NO. BASE MODEL NO. PLEB27S8ACA PLEB27S8A WIRING DIAGRAM - # 318046208 OWNER’S GUIDE - # 318200919 TIMER INSTRUCTION SHEET - # 318200181 INSTALLATION INSTRUCTIONS - # 318201507 ELECTROLUX HOME PRODUCTS NORTH AMERICA P.O. BOX 212378, Augusta, GA 30917 FACTORY PARTS CATALOG FACTORY NO.

  • Page 2: Control Panel

    Publication No. PLEB27S8ACA 5995363578 CONTROL PANEL 01/02...
  • Page 3 318028330 Trim,canopy 318111602 Bracket,clock & relay 318027310 Trim,vent 318037200 Cover,oven vent ,stainless 318029602 Trim,top ,stainless steel 318111500 Relay,convection ,oven light ,(2) 316037700 Seal,vent cover 316037800 Tape,vent cover 5303300265 Screw,8-18 x 0.500 ,chrome 218490900 Cleaner,stainless steel 3201861 Screw,6 x 0.375 08002868 Screw,10-24 x 0.500 ,probe,thrm brkt ,shield,drwr,box...
  • Page 4 Publication No. PLEB27S8ACA 5995363578 BODY 01/02...
  • Page 5 318071501 Shield,oven top 318025300 Rack,oven 5303311206 Shelf,broiler pan 318025200 Shelf,oven 5303317977 Pan,broiler 5303317976 Insert,broiler pan 318089910 Switch,oven light ,door frame 5308011085 Receptacle,oven light 3201908 Light,oven 3201911 Cover,oven light ,glass 5304400195 Retainer,light cover 316111203 Sensor,oven temp probe 5303310526 Cover,hinge cutout 5303310514...
  • Page 6 Publication No. PLEB27S8ACA 5995363578 DOOR 01/02...
  • Page 7 Insulation,oven door 318048501 Liner,oven door 5303311217 Screw,handle ,door 318053100 Seal,oven door 318009201 Panel,oven door ,stainless ,exterior 318091101 Bracket,glass ,(3) 318042300 Glass,oven door ,heat barrier ,(2) 318042000 Spacer,glass 318053000 Seal,rope 318086020 Spacer,handle ,(2) 5303310511 Bar,glass retainer 5303320452 Hinge,oven door 318014400 Spacer,door...

  • Page 8: Wiring Diagram

    Publication No. PLEB27S8ACA 5995363578 WIRING DIAGRAM 01/02...
