MICROWAVE INFORMATION

SPECIFICATION

ITEM
Power Requirements
Control Complement
Oven Cavity Light

GENERAL INFORMATION

GROUNDING INSTRUCTIONS
This oven is equipped with a three prong grounding plug. It must be
plugged into the wall oven receptacle that is properly installed and
grounded in accordance with the National Electrical Code and local
codes and ordinances.
In the event of an electrical short circuit, grounding reduces the risk
of electric shock by providing an escape wire for the electric
current.
WARNING: Improper use of the grounding plug can result in
a risk of electric shock.
Electrical Requirements
The electrical requirements are a 120 volt 60 Hz, AC only, a branch
circuit protection fuse, 20 amp is provided in series with the ac
outlet on top of the wall oven support.
*Note: Branch circuit fuse 20 amp shall be replaced with class cc type.
120 Volts
14.3 Amperes, 1700 watts
60 Hertz
Single phase, 3 wire grounded
Touch Control System
Clock ( 1:00 - 12:59 )
Timer (0 - 99 min. 99 seconds)
Microwave Power for Variable
Cooking Repetition Rate;
P-HI ........................................ Full power throughout the cooking time
P-90 .......................................................... approx. 90% of Full Power
P-80 .......................................................... approx. 80% of Full Power
P-70 .......................................................... approx. 70% of Full Power
P-60 ....................................................... .. approx. 60% of Full Power
P-50 .......................................................... approx. 50% of Full Power
P-40 .......................................................... approx. 40% of Full Power
P-30 .......................................................... approx. 30% of Full Power
P-20 .......................................................... approx. 20% of Full Power
P-10 .......................................................... approx. 10% of Full Power
P-0 ........................................... No power throughout the cooking time
Add 1 minute pad, Sensor cooking pads, Defrost pads, Number selection
pads, Power Level pad, Timer/Clock pad,STOP/Clear pad, One touch
cooking pads, and Start pad.
Yes
2
DESCRIPTION
