Thank you for purchasing this Skye 1 drawer wardrobe. Please read the instructions
carefully before use to ensure safe and satisfactory operation of this product.
For spare parts, please contact the TCH John Lewis helpdesk on 01691 770 157
Pre-assembly preparation
Please ensure instructions are read in full before attempting to assemble this product
Necessary Tools
You will require a cross head screwdriver to assemble this product. An electric drill may
cause damage to the product and is not recommended.
Please check the pack contents before attempting to assemble this product.
A full checklist of components is given in this leaflet. If any components are missing,
please contact the number on the front of this assembly instruction.
Skye 1 drawer wardrobe
Stock number: 80312610
Advertisement
Related Manuals for John Lewis Skye
Summary of Contents for John Lewis Skye
- Page 1 Skye 1 drawer wardrobe Stock number: 80312610 Thank you for purchasing this Skye 1 drawer wardrobe. Please read the instructions carefully before use to ensure safe and satisfactory operation of this product. For spare parts, please contact the TCH John Lewis helpdesk on 01691 770 157...
- Page 2 This product takes approximately 60 MINUTES to assemble with 2 PERSONS. The fittings pack contains SMALL ITEMS which should be KEPT AWAY FROM YOUNG CHILDREN. Read this leaflet in full before commencing assembly. Fittings and parts checklist...
- Page 4 Step by step assembly instructions Step One Lay parts (01) & (09), (02) & (03) and add cams ( D ). Fittings (A) add to the doors using screws (C) as shown in the diagram. PLEASE PLACE THE PARTS ON A SMOOTH SURFACE, in order not to scratch the paint.
- Page 5 Step Three Two people required. Please position ( 02 ), ( 03 ), ( 05 ) and ( 08 ) parts as shown in the picture. All fittings ( D ) go into the prepared holes with the cam. Side panels ( 02 ) and ( 03 ) attach to the shelves ( 05 ) and ( 08 ).
- Page 6 Step Four Two people required. Attach the back panel ( 04 ) to the wardrobe, use 38 x screws ( E ) to tighten the panel to the wardrobe. Step Five Please attach four legs ( 10 ) to the wardrobe base ( 09 ) as shown in the diagram.
- Page 7 TWO PEOPLE REQUIRED.Please stand the product upright. Step Six Take part ( 11 ) left door and attach to the left side ( 03 ) of the wardrobe. Use both fittings ( A ) & ( B ) and connect hinges with their screws. Please follow same steps for the right door ( 12 ) as shown in the diagram below.
-
Page 8: Care And Maintenance
Insert drawer to his place and push the wooden dowels to secure it as per diagram below. Step Eight Attach one end of the wall fixing strap ( H ) to the top of the unit with the screw provided and the other end should be attached to the wall by a competent person. -
Page 9: Safety Instructions
Please be careful to retain all fittings when doing this. TCH John Lewis helpdesk on 01691 770 157 for queries regarding parts. PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE John Lewis Partnership 171 Victoria Street London SW1E 5NN...
