ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
CM7427Q
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 7
(Included)
(Not Included)
Rev: 18-05-25
Advertisement
Table of Contents
Related Manuals for Furniture of America CM7427Q
Summary of Contents for Furniture of America CM7427Q
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7427Q ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 7...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. Finial Page 3 of 7...
- Page 4 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. Slat Page 4 of 7...
- Page 5 3) Attach HB finial (#4) to headboard (#1), then attach finial (#5) to HB finial (#4). #A x 8pcs #B x 4 pcs #D x 12 pcs #E x 12 pcs 2) Align HB legs (#2R/L) to the holes of the headboard (#1), then secure by using bolts (#A) with washers (#D,E).
- Page 6 Screw bolts (#C) half way into the holes of the headboard (#1) and footboard (#6), then rest hooks on side rails (#10) to bolts (#C). Secure by tightening bolts (#C). #C x 12 pcs Attach support legs (#12) to the slats (#11), then adjust the leveler on the support legs (#12) according to ground level.
- Page 7 Align slats (#11) evenly throughout the side rails (#10), then secure by using screws (#G). #G x 8 pcs ASSEMBLY IS COMPLETED Page 7 of 7...
