ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
DIFFICULT
CM7426CK
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 6
(Included)
(Not Included)
Rev: 18-05-25
Advertisement
Related Manuals for Furniture of America CM7426CK
Summary of Contents for Furniture of America CM7426CK
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7426CK ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 6...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1 pc #A x 16pcs Headboard Bolt Ø1/4" x 1-3/4" #2 x 2 pcs #B x 16pcs Lock Washer Ø1/4"...
- Page 4 Exploded View #A x 12pcs #B x 12pcs #C x 12pcs Align headboard legs (#2R/L) to the holes of the headboard (#1), then secure by using bolts (#A) with washers (#B,C). Align headboard rail (#3) to the holes of the headboard legs (#2R/L), then secure by using bolts (#A) with washers (#B,C).
- Page 5 #A x 4pcs #B x 4pcs #C x 4pcs Align footboard legs (#5R/L) to the footboard (#4), then secure by using bolts (#A) with washers (#B,C). #D x 12pcs Screw bolts (#D) half way into the holes of the headboard (#1) and footboard (#4), then hook and place the side rails (#6) to the bolts (#D).
- Page 6 Attach support legs (#8) to the holes of the slats (#7), then adjust leveler on the support legs (#8) according to ground level. Align slats (#7) to the side rails (#6) evenly, then secure by using screws (#F). #F x 8pcs Page 6 of 6...
