OWNER'S
MANUAL
MODEL NO.
390.2514
390.2518
CAUTION:
Read and Follow
All Safety Rules and
Operating Instructions
Before First Use of
This Product.
Save This Manual For
Future Reference.
Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A.
PRINTED IN U.S.A.
PROFESSIONAL
"HYDROGLASS"
SHALLOW WELL JET PUMP
• Safety Instructions
• Installation
• Operation
• Troubleshooting
• Repair Parts
®
®
Form No.
F642-04073
(8/3/04)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CRAFTSMAN HYDROGLASS 390.2514 and is the answer not in the manual?

Questions and answers

Heriberto
April 11, 2025

Necesito información de partes sobre el plato **** detrás de las aspas

User image 67f970e7e83b2
0

Related Manuals for Sears CRAFTSMAN HYDROGLASS 390.2514

Summary of Contents for Sears CRAFTSMAN HYDROGLASS 390.2514

  • Page 1 Before First Use of • Safety Instructions This Product. • Installation Save This Manual For • Operation Future Reference. • Troubleshooting • Repair Parts Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A. PRINTED IN U.S.A. F642-04073 Form No. (8/3/04)

  • Page 2: Safety

    READ AND FOLLOW SAFETY INSTRUCTIONS! This is the safety alert symbol. When you see this symbol on your pump or in this manual, look for one of the following signal words and be alert to the potential for personal injury: DANGER warns about hazards that will cause serious personal injury, death or major property damage if ignored.

  • Page 3: Table Of Contents

    ® PROFESSIONAL HYDROGLASS ® WELL PUMPS After one year and through three years from the date of purchase, Sears will furnish, free of charge, a replacement part for any defective part. You pay for labor. LIMITED WARRANTY ON CRAFTSMAN ®...

  • Page 4: Major Components

    Plastic Pipe Pipe A shallow well jet pump can be installed on a dug well, drilled well or a driven point. SEARS shallow well jet pumps have a built-in 5’ To 10’ Pumping Level check valve. In a dug or cased well, a foot valve and strainer should...

  • Page 5: Electrical

    ELECTRICAL Disconnect power before working on pump, motor, pressure switch, or wiring. Motor Switch Settings If the motor can operate at either 115 or 230 volts, it is set at the Dial Type Voltage Selector factory to 230 volts. Do not change motor voltage setting if line voltage is 230 volts, or if you have a single voltage motor.
  • Page 6 ELECTRICAL WIRING CONNECTIONS Connection Procedure: 1. Connect the ground wire first as shown in Figure 9. The ground Fire hazard. Incorrect voltage can cause a fire or wire must be a solid copper wire at least as large as the power seriously damage the motor and voids the warranty.

  • Page 7: Installation

    The installation, operation, and care of your Hydroglass ® Pump is very similar to cast iron pumps. We ask, however, that you keep SEARS jet pumps should be used with Captive Air ® Tanks (See the following points in mind.

  • Page 8: Maintenance

    SERVICE MAINTAINING YOUR PUMP B. Loosen two screws and remove motor canopy. C. If motor has capacitor, partially unscrew capacitor clamp and Lubrication move capacitor to one side. It is not necessary to lubricate the pump or its motor. The motor Risk of electrical shock.

  • Page 9: Helpful Hints

    SERVICE C. With finger pressure press seat firmly and squarely into cav- K. Remount diffuser on seal plate. ity. See Figure 12A. Polished face of seat faces inside of pump. Cleaning Impeller If seat will not locate properly, place cardboard washer over 1.

  • Page 10: Repair Parts

    REPAIR PARTS 16 17 766 1194 To Order Parts in the U.S.A., Call To Order Parts outside the U.S.A., Call Sears Product Service, 1-800-366-7278 Your local Sears Service Center or Store...
  • Page 11 REPAIR PARTS 1/2 HP 3/4 HP Model Model Part 390.2514 390.2518 Description J218-953C – Motor - 1/2 HP - 115/230V - 60 Cycle – J218-954C Motor - 3/4 HP - 115/230V - 60 Cycle 17351-0009 17351-0009 Water Slinger – – Reducer Bushing - 1/2"...

  • Page 12: Troubleshooting Guide

    TROUBLESHOOTING CHART PROBLEM POSSIBLE CAUSES REMEDIES Motor will not run. 1. Disconnect switch is off. 1. Be sure switch is on. 2. Fuse is blown. 2. Replace fuse. 3. Starting switch is defective. 3. Replace starting switch. 4. Wires at motor are loose, 4.
  • Page 16 9 am - 5 pm, Monday-Saturday 1-800-827-6655 information: • Product Type • Model Number • Part Number REPAIR SERVICES • Part Description America's Repair Specialists Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A. Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A.
