Shallow well jet pump
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
owners
manual
MODEL NO.
390.250290
390.251590
CAUTION:
Read All Instructions
Carefully Before Start-
ing The Installation.
Save This Manual For
Future Reference.
PRINTED IN U.S.A.
HYDRO-GLASS
SHALLOW WELL
JET PUMP
Craftsman Model No. 390.251590
Sears Model No. 390.250290
• Installation
• Operation
• Repair Parts
Sears, Roebuck and Co., Chicago, IL 60684 U.S.A.
®
F642-9206
Form No.
(Rev. 3/18/93)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HYDRO-GLASS 390.250290 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sears HYDRO-GLASS 390.250290

Summary of Contents for Sears HYDRO-GLASS 390.250290

  • Page 1 Read All Instructions Carefully Before Start- ing The Installation. Sears Model No. 390.250290 • Installation • Operation • Repair Parts Save This Manual For Future Reference. Sears, Roebuck and Co., Chicago, IL 60684 U.S.A. PRINTED IN U.S.A. F642-9206 Form No. (Rev. 3/18/93)
  • Page 2 Wear safety glasses at all times when working on pumps. FULL ONE YEAR WARRANTY ON SHALLOW WELL JET PUMPS For one year from the date of purchase, Sears will repair or replace this well pump, free of charge, if defective in materials or workmanship.

  • Page 3: Pump/Piping Installation

    Before You Install Your Pump 3. Wrap 1-1/2 to 2 layers of Teflon tape clockwise (as you face end of pipe) on all male threads being attached to pump. Pre-installation 4. Tighten joints hand tight plus 1-1/2 turns. Do not 1.

  • Page 4: Well Pipe Installation

    Electrical Priming Plug To service Ground motor before WARNING connecting to electrical power supply. Failure to ground motor can cause severe or fatal electrical shock hazard. Do not ground to a gas supply line. To avoid dangerous or fatal electrical shock, Hazardous voltage.

  • Page 5: Operation

    WIRING CHART Recommended Wire and Fuse Sizes DISTANCE IN FEET (M) FROM MOTOR TO SUPPLY Branch Max. Fuse* 0 - 50 51 - 100 101 - 200 201 - 300 301 - 400 401 - 500 Model Motor Load Rating (0 - 15) (15 - 30) (30 - 61)

  • Page 6: Pump Disassembly

    PUMP DISASSEMBLY Hold motor fan Cut tubing carefully to remove. Do not damage barb. To order parts, call: Sears Product Service 1-800-366-7278 REPAIR PARTS LIST Part Number Part Number Model Model Part Model Model Part 390.250290 390.251590 Description 390.250290 390.251590...

  • Page 7: Pump Reassembly

    Do not overtighten. PUMP REASSEMBLY Press in seal. Do not nick or scratch seal faces. Hold motor fan TROUBLESHOOTING CHART SYMPTOM POSSIBLE CAUSE(S) CORRECTIVE ACTION Motor will not run Disconnect switch is off Be sure switch is on Fuse is blown Replace fuse Starting switch is defective DISCONNECT POWER;...

  • Page 8: How To Order Repair Parts

    • PART DESCRIPTION • MODEL NUMBER • NAME OF ITEM All parts listed may be ordered from any Sears Service Center. If the parts you need are not stocked locally, your order will be electronically transmitted to a Sears Repair Parts Distribution Center for handling.
