OWNER'S
MANUAL
Model No.
390.260251
CAUTION:
Read and Follow
All Safety Rules and
Operating Instructions
Before First Use of
This Product.
Save This Manual For
Future Reference.
Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A.
PRINTED IN U.S.A.
PORTABLE UTILITY PUMP
• Safety Instructions
• Installation
• Service
• Repair Parts
F642-9302
Form No.
(Rev. 8/28/95)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sears 390.260251
Summary of Contents for Sears 390.260251
- Page 1 Operating Instructions Before First Use of This Product. • Safety Instructions • Installation Save This Manual For • Service Future Reference. • Repair Parts Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A. PRINTED IN U.S.A. F642-9302 Form No. (Rev. 8/28/95)
- Page 2 Repair Parts................7 FULL ONE YEAR WARRANTY For one year from the date of purchase, Sears will repair or replace this pump, free of charge, if defective in materials or work- manship. This warranty does not cover repairs on replacement parts necessary because of abuse or negligence including failure to install, adjust and operate this pump according to the instructions in the owner’s manual.
- Page 3 INSTALLATION To prevent damage to pump materials, do not use pipe joint Pump is supplied with WARNING compounds on pump ports. Use only teflon tape or Plasto- 3-conductor ground- Joint-Stik* to seal threads. ing type cord. Connect only Hazardous voltage. Tighten all piping to pump hand tight plus 1-1/2 turns only.
- Page 4 INSTALLATION / SERVICE Plug pump into a 115 Volt, 60 Cycle outlet only. Pump is NOTICE: When reinstalling the same brushes that were equipped with a 3-wire, grounded, cord and plug. Do not removed, replace on same side of motor that they were modify or remove plug.
- Page 5 SERVICE Seal Replacement: Pump Reassembly: 1. Use a piece of tubing or copper pipe to press old seal half 1. Slide rubber slinger onto motor shaft; mount seal plate on out of seal plate (Figure 5A). end of shaft. Push seal plate onto shaft until ball bearing race is seated in tolerance ring in seal plate cavity.
- Page 6 TROUBLESHOOTING CHART TROUBLE AND CAUSE REMEDIES FAILURE TO PUMP Pump not properly primed. Make sure tank body is full of water. See priming instructions. Speed too low. Check voltage at motor terminals and at meter when pump is operating. If low, refer to wiring instructions, or check with your Power Company.
- Page 7 Brush Kit* – (Includes 1 pair Brushes, Pkg 193 1 pair brush holder caps) • Strainer RP0001663 • Owner’s Manual F642-9302 • Not illustrated * One brush kit is included with each pump. To order parts, call: Sears Product Service 1-800-366-7278...
- Page 8 9 am - 5 pm, Monday-Saturday 1-800-827-6655 • Model Number • Part Number • Part Description REPAIR SERVICES America's Repair Specialists Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A. Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A.
