956152
ENGLISH
- Tornado -
ELHO
SideChopper
Tornado 330
OY
Email: elho@elho.fi
1
Series 10.1/10.2
ELHO
AB
68910 BENNÄS
Finland
www.elho.fi

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SideChopper Tornado 330 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for elho SideChopper Tornado 330

Summary of Contents for elho SideChopper Tornado 330

  • Page 1 - Tornado - Series 10.1/10.2 ELHO SideChopper Tornado 330 ELHO 956152 68910 BENNÄS ENGLISH Finland www.elho.fi Email: elho@elho.fi...
  • Page 2 Industrivägen 6 68910 Bennäs FINLAND As the manufacturer of: ELHO Side Chopper Tornado 330 Serie 10.1/10.2 we hereby declare that these machines are in conformity with the essential requirements of: 2006/42/EC Relevant parts of the following standards have been followed when designing the machines.
  • Page 3 This limited warranty does not cover damages to the machine or its components caused, according the judgement of ELHO, by unsuitable hydraulics or electrical connections. As the use of ELHO products is outside of our control, we can only guarantee quality and do not accept liability in respect of performance.
  • Page 4 Type Serie Paint To ensure a long life span of the ELHO machines, also the colour and the coating process of the manufacturing process conform to the highest international requirements. Even a good colour coat may become damaged or scratched, for example during transport and operation.

  • Page 5: Table Of Contents

    - Tornado - Contents 1. Warranty 2. Intended use 3. Technical specification 4. Safety instructions 5. Starting up of a new machine 6. Assembly 7. Connecting and disconnecting to the tractor 8. Adjustments 9. Work with the machine 10. Maintenance 11.

  • Page 6: Intended Use

    - particularly important advice related to the operation of the machine 2. Intended use ELHO Side Chopper is designed to be attached to conventional farm tractors for cutting of shrubbery and other vegetation outside normal farming areas, for example ditches or roadsides.

  • Page 7: Safety Instructions

    We recommend for the machine to be used with the tractor windows closed.  With the window open, the noise level from ELHO Side Chopper may be as high as 80- 96dB(A) in the driver's seat, when the machine is operating.
  • Page 8 - Tornado - 4.1 Safety signs on the machine ELHO Side Chopper is equipped with guards and safety devices according to regulations. All hazards have, however, been impossible to eliminate through design. The machine has therefore been equipped with a number of warning tags, to highlight risks that cannot be avoided in the design or by using guards.

  • Page 9: Starting Up Of A New Machine

     Check that the machine has been properly installed and that it has not been damaged during transport.  ELHO Side Chopper Tornado is as standard delivered with the following drive shafts: Primary shaft: Bondioli 810686CE007001 equipped with ~1800Nm friction clutch Secondary shaft: Bondioli 8G7T155FX014001 Or similar drive shaft of other brands.

  • Page 10: Assembly

    - Tornado - 6. Assembly The ELHO Side Chopper Tornado is normally delivered assembled. 7. Connection- and disconnection to the tractor Attaching the machine to and detaching it from the tractor must only be done with the machine in working position, i.e. with the cutting device against the ground.
  • Page 11 - Tornado - 7.3 Lifting into transport position  Lift the machine free from ground.  Lift the cutting head into vertical position.  Swing the cutting head behind the tractor. Note! Close the valve B for transport!  Ensure the tractor has enough stability fort he weight of the machine.

  • Page 12: Adjustments

    - Tornado - 8. Adjustments 8.1 Cutting height As the machine mainly is used outside of cultivated fields the cutting head normally is carried during work by the 3-P linkage of the tractor there normally are little need of adjustments on the machine itself.

  • Page 13: Work With The Machine

    - Tornado - 9. Work with the machine  Putt he cutting head into horizontal position before connecting the PTO. Check § 7.4. Bringing into work position   The machine is intended for 540 rpm on the PTO.  Use moderate drive speed ...

  • Page 14: Maintenance

    Tension torque is 95-105 Nm. It is recommended that the lock nut is replaced each time the chain is replaced. Always use only ELHO original chain.   Check also that the chain rotor is free from cracking’s. Damaged or worn chain rotor must be...
  • Page 15 - Tornado - 10.2 Lubrication Use high quality bearing grease Point Item 1 x /10 h Note! Lubricate also the profiles Driveshafts All swivel pins and cylinder 4 pcs bolts...

  • Page 16: Storage

    - Tornado - 10.3 Checking and changing of oil  Check the angular gear oil level before starting to use a new machine. The level must reach the level plug A, with the machine in a horizontal position.  Regularly check, during breaks in the work, that no extern oil leaks are visible. The machine can have type A or type B gearbox Oil: SAE 90 EP Oil amount type A: Up to level plug approx.
