Lifetime FRONT COURT QUICK ADJUST II Owner's Manual page 10

This step cannot be reversed.
1.3: Strike each end of the pole firmly 5 to 6 times on a piece
of wood or cardboard.
If the Top and Middle Poles do not completely cover the slots on the
Middle and Bottom Poles after seating, DO NOT COMPLETE ASSEMBLY.
Call our Customer Service Department.
Do not hit your feet with the pole sections, as serious injury could occur.
Failure to seat the pole sections together and secure the Pole Joint
Screws could cause the pole sections to separate, resulting in property
damage or severe personal injuries as listed on Page Two.
1.4: Insert the 1.3cm and 0.95cm Nylon Plugs (U & S) into the
holes on each side of the Middle Pole.
10
Hardware Bag # HP21800
U
(2)
WARNING
MP
S
(2)
S
S
MP
U
U
BP
MP
TP
Front of Pole
Back of Pole
