KEYPAD FUNCTIONS
MENU/ON key - Turns unit ON and allows the unit to leave any current
menu and return to the MAIN menu.
▲/LIGHT key - used to scroll up and turn backlit on. The backlit can
only be turned on and off when unit is in the main menu or when
weather data is being displayed.
▼/CLEAR key – Scrolls down and is used to clear data.
3/OFF key – Turns unit off when pressed from MAIN menu. (NOTE:
OFF key must be held for at least 1 full second). Unit turns itself off
automatically if no keys are pressed for 1 minute.
ENTER/HOLD key - must be pressed after keying in a value to confirm the
value is correct. When pressed in SAMPLE AIR mode the air sample is held in
memory and can be used for data entry later on. To view the "Held" data you
can press the HOLD key when you are at the main menu.
MAIN MENU - When unit is turned on the MAIN menu automatically is
displayed after the greeting message.
SAMPLE AIR/WIND
SET UP
RUN ENTRY
PREDICT
Hit the "MENU" key again and see:
DOWNLOAD
SET CLOCK
BAD RUNS
AUTO POWER OFF
Hit the "MENU" key again and see:
SAMPLE METHOD
BATTERY CHECK
Refer to Appendix for MENU chart
MENUS
= 1 (Wind optional)
= 2
= 3
= 4
=5
=6
=7
=8
=9
=0
5
