The DA or OA will already be loaded. You should enter a 1000' ET, a final
ET, and TS. The 1000' ET is optional and is used for run completing. You do
not have to enter every run with a 1000' time in order to use run completing.
** For 1/8" runs you can enter a 330' time instead of a 1000' time**
If manual entry is desired you must select number 3. After selecting 3 the
following is displayed.
ENTER AS
Altitude
Temp, Hum, Press
If 1 is selected you will have to key in the DA or OA value. If 2 is selected you
will have to enter the temperature, humidity, pressure, and oxygen values.
Then the DA or OA will be calculated.
ET = will only be entered if the unit is in ET MODE.
TS = will only be entered if the unit is in TS MODE.
PLATE = will only be entered if the unit is in PLATE MODE
Each plate is identified by a letter followed by a number. First, you will choose the
letter. To change the letter, scroll up to advance forward in the alphabet, and scroll
down to advance backward. Once you have selected the correct letter, press the
"Enter" key. Next, you will select the plate's number. Scroll up to increase the number,
and scroll down to decrease the number. Again, once you have selected the correct
number, press the "Enter" key to continue. The run is now entered and you will be
returned to the main menu.
Wind Correction:
If wind correction has been enabled you will be asked to enter the wind speed
and direction for each run entered.
Enter Wind Speed
Enter Wind Dir
Head=1 Tail=2
CH=3 Ct=4 Cross=5
****HINT****
The easiest way to enter a run is by starting from the main menu and
pressing the keys 3, 2, 1, and ENTER. Now all you have to do is type in
your ET's and the run is stored.
=1
=2
Press 1or 2
MPH=
17
