AssembLY iNsTrucTiONs

risk of electric shock. Do not plug in pump
until assembly is complete.
1. Turn pump body upside down and install the
shield (E) as shown.
2. Install the screen (F) as shown. Do not insert
screws yet.
3. Using the three screws (AA), attach the base (G) as
shown, inserting screws through the base, screen,
and shield.
NOTE: Rectangular cutout notch in base must align
with anti-airlock hole in motor body.
Hardware used
AA
Base Screw
1
2
3
AA
AA
x 3
5
e
Align part
number
with anti-
airlock
hole
5841 0408
F
5842 0408
AA
Cut-out notch;
align with
anti-airlock hole
G
6681 0912
®
