580 GAS FIRE – INSTALLATION & SERVICING INSTRUCTIONS
Inset Live Fuel Effect
MODEL 580 Deluxe Inset
For use on Natural Gas at a supply pressure of 20mbars in G.B / I.E
USER'S
INSTRUCTIONS
These instructions must be handed to the user
to be kept in a safe place for future reference
Part No. 200380
Issue 4
GC No. 32-210-25
Patent application No. 0123387.3
Be Modern Customer Care, Bede Industrial Estate
Jarrow, Tyne and Wear, NE32 3BE
Tel: (0191) 489 8266 option 4
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Be Modern 580 Deluxe Inset
Summary of Contents for Be Modern 580 Deluxe Inset
- Page 1 Part No. 200380 Issue 4 GC No. 32-210-25 Patent application No. 0123387.3 Be Modern Customer Care, Bede Industrial Estate Jarrow, Tyne and Wear, NE32 3BE Tel: (0191) 489 8266 option 4...
-
Page 2: Table Of Contents
The model number of this appliance is as stated on the rating plate. In the event of any problems, please telephone (0191) 430 0901. This product has been manufactured by Be Modern Appliances, Pilgrim Way, Bede Industrial Estate, Jarrow, NE32 3HG. Important notice to installer The cream fibre board which may be supplied with this appliance, may discolour on its initial startup. -
Page 3: Important Notes
580 GAS FIRE – INSTALLATION & SERVICING INSTRUCTIONS Important Safety Notes FAILURE TO COMPLY WITH ANY OF THESE REGULATIONS COULD LEAD TO PROSECUTION AND DEEM THE WARRANTY INVALID. This appliance has been designed to work on natural gas. It is law that all appliances using natural gas shall be installed by a competent person who shall fit in accordance with the current Gas Safety Regulations, the relevant British Standard Installation specifications, Codes of Practice and in accordance with the manufacturer’s instructions and the various recommendations contained in the following regulations: -... -
Page 4: Site Requirements
580 GAS FIRE – INSTALLATION & SERVICING INSTRUCTIONS Site Requirements Please read these instructions carefully before installation Any exposed brickwork should be inspected and repaired where necessary. The opening should be from 390 mm to 430mm wide and from 540mm to 568mm high and a minimum depth for precast and 5’’... -
Page 5: Ventilation
580 GAS FIRE – INSTALLATION & SERVICING INSTRUCTIONS This fire requires a hearth constructed of non-combustible materials and must conform to the minimum dimensions. Diagram 1C Diagram 1C Diagram 1D The hearth must be at least 12mm thick and the top surface should not be less than 50mm above the surrounding floor level, or have a fixed fender 50mm high, surrounding the hearth. -
Page 6: Fire Box Installation
580 GAS FIRE – INSTALLATION & SERVICING INSTRUCTIONS Fire Box Installation ENSURE that the gas supply is isolated before you commence the installation of this appliance. Read all previous sections of these instructions prior to starting the installation of this appliance. Having previously prepared the installation site as detailed, remove the fire components from the carton. -
Page 7: Fitting The Ceramic Fibre
580 GAS FIRE – INSTALLATION & SERVICING INSTRUCTIONS Fitting the Ceramic Fibre Depending on which model you have purchased your fire will be supplied with either coal or pebble fibres. Fitting the rear fibre bed Place the rear fibre bed into position, ensuring that the slot on its underside has correctly located into the up stand just behind the burner. -
Page 8: Trim Installation
580 GAS FIRE – INSTALLATION & SERVICING INSTRUCTIONS Trim Installation Depending on the model of fire you have purchased, your fire may have been supplied with either a one-piece magnetic trim or a three-piece clip on trim. If there are separate instructions supplied with the trim please refer to those. One-Piece Magnetic Trim The one-piece trim is delivered with the trim attached, by magnets. -
Page 9: Fret Fixing Instructions
580 GAS FIRE – INSTALLATION & SERVICING INSTRUCTIONS Fret Fixing Instructions Depending on the model of fire you have purchased, your fire may have been supplied with a fret that locates on keyhole brackets. If there are separate instructions supplied with the fret please refer to those. Use the two M5 screws and two M5 nuts to fix fret to fire as follows: Thread nut onto screws up to the screw head. -
Page 10: Operating The Appliance
580 GAS FIRE – INSTALLATION & SERVICING INSTRUCTIONS Operating the Appliance The gas control valve is situated at the base of the fire tray behind the ash pan cover along with the data information badge. The gas control valve incorporates a thermoelectric oxygen depletion device, which in the event of a problem with the flue performance causing the spillage of products into the room, the valve will automatically shut off the gas and turn off the fire. -
Page 11: Commissioning The Fire
580 GAS FIRE – INSTALLATION & SERVICING INSTRUCTIONS Commissioning the Fire Check for Spillage The appliance must be tested for spillage. Close all the doors and windows in the room containing the appliance. The appliance must be completely installed with all the ceramics fitted including the coals, the front and fret and the fire surround. -
Page 12: Short Spares List
580 GAS FIRE – INSTALLATION & SERVICING INSTRUCTIONS Spares List No Of Description Part No GC No 1 set Rear Fibre Bed (black) 101762 H50-707 One Piece Front Coal (black) Loose Coal Bag 1 set Rear Fibre Bed (cream coloured) 101764 H50-708 One Piece Front Bed (cream coloured) -
Page 13: User Instructions
580 GAS FIRE – INSTALLATION & SERVICING INSTRUCTIONS USER’S INSTRUCTIONS To the Customer Annual checking of the flue and regular servicing of this fire is recommended to ensure continued safe operation. Once a year is the recommended service interval. British Gas/Scottish Gas can carry out this work. Important Notes: This appliance has been designed to work on natural gas. - Page 14 The model number of this appliance is as stated on the rating plate. In the event of any problems, please telephone (0191) 489 8266 option 4. This product has been manufactured by Be Modern Appliances, Pilgrim Way, Bede Industrial Estate, Jarrow, NE32 3HG.
