Micro Marble Fireplaces
INSTALLATION INSTRUCTIONS AND USER GUIDE
Important Information
Before you begin the installation, please ensure that a full and detailed inspection of all component parts is
undertaken jointly by the installer and purchaser to ensure there is no damage or manufacturing defects with the
product. Once the fireplace has been installed, no claims or responsibility will be accepted by the manufacturer
relating to chips, scratches or any other obvious defects.
Please also ensure you carefully read and fully understand these instructions before commencing installation as
we cannot accept responsibility for any damage or defects caused by non-compliance with these instructions.
These instructions are written in accordance with the 'Stone Federation Great Britain' guidance on fire surround
standard building practice, Building Regulations (Approved Document J) and all relevant British Standards.
This fireplace should be installed only by competent professional fireplace installers and fitted only to suitable
surfaces. You should check with your installer that the constructional elements of the intended chimney breast
and flue comply with current Building Regulations, and that they are suitable for the appliance that is to be
installed.
NOTE: Installation is not recommended as a DIY or single person task. In addition to this giving rise to the
potentially increased risk of product damage and/or incorrect installation, it should also be noted that some
marble components can be very heavy and will require two people to lift/handle. Caution should always be
exercised if attempting to lift heavy or awkward objects.
Following the installation, please leave these instructions with the householder.
Advertisement
Table of Contents
Related Manuals for Be Modern Elgin & Hall
Summary of Contents for Be Modern Elgin & Hall
-
Page 1: Important Information
Micro Marble Fireplaces INSTALLATION INSTRUCTIONS AND USER GUIDE Important Information Before you begin the installation, please ensure that a full and detailed inspection of all component parts is undertaken jointly by the installer and purchaser to ensure there is no damage or manufacturing defects with the product. -
Page 2: General Information
Micro Marble is produced from small pieces of real marble finely crushed and bonded to produce a quality product for your home. Be Modern selects only the highest quality marble to manufacture your fireplace within our UK manufacturing facilities. -
Page 3: Installing The Fireplace
Installing the Fireplace If fitting a model with halogen lights (or with an electric fire), firstly ensure that there is access to a suitable power supply in the fitting area. If a fused spur is to be fitted (recommended), this should be fitted prior to installation. - Page 4 Remove one of the screws from the surround brackets and turn it into a vertical position (Figure 2). This allows the bracket to be “flipped down” later for easier fitting. Do not replace the surround on the hearth as before final fixing of the surround and back panel you will need to prepare the wall ‘keyhole’...
- Page 5 Please note that the keyhole bracket is an additional safety feature which - if installed correctly - will prevent the mantel shelf from tipping or falling from the surround in the unlikely event of bonding failure. It is not however intended to secure the mantel fully to the wall so a little “play” on the bracket is to be expected and this won’t compromise the feature.
- Page 6 LIGHTING INSTALLATION INSTRUCTIONS Step 1 Before beginning, ensure that your work area is clear and dry and that you have read through the full installation instructions. Step 2 Unravel the cable to the light bulb housing and feed the cable up through one of the light apertures in the surround, securing in place (see Photograph A).
- Page 7 To switch the lights off, glide your hand past the sensor once again. REPLACING THE HALOGEN BULBS Bulb specification: Halogen 12V MAX 20W G4. For replacement halogen bulbs contact the BE MODERN HELPLINE on 0191 430 0901 or alternatively consult your local electrical retailer / DIY store. Step 1 Before replacing the bulb switch off the power and allow the bulbs to cool down completely.
- Page 8 GUARANTEE Be Modern (‘the Company’) provides a 12 month guarantee in respect of the fireplace (‘the Product’) ranges subject to the following terms and conditions. In the event of service being required, the purchaser should initially contact the retailer/installer who supplied the product and they will assist and advise you further as necessary.
