Campbell Hausfeld IN729300AV Operating Instructions Manual

See Warranty on page 10 for important information about commercial use of this product.
Operating Instructions
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
Table of Contents
Description . . . . . . . . . . . . . . . . . . . . . 1
Unpacking . . . . . . . . . . . . . . . . . . . . . . 1
Safety Guidelines . . . . . . . . . . . . . . . . 1
Important Safety Instructions . . . . . . 1
Tool Components and
Specifications. . . . . . . . . . . . . . . . . . . . 2
Operating Instructions . . . . . . . . . . . . 4
Lubrication . . . . . . . . . . . . . . . . . . . . 4
Recommended Hookup. . . . . . . . . . 5
Operational Mode . . . . . . . . . . . . . . 5
Work Contact Element (WCE) . . . . . 5
Loading/Unloading The Tool. . . . . . 6
Adjusting the Fastener
Penetration. . . . . . . . . . . . . . . . . . . . 6
Adjusting the Direction
of the Exhaust . . . . . . . . . . . . . . . . . 6
User-Maintenance Instructions . . . . . 6
Clearing A Jam From The Tool . . . . 6
Technical Service . . . . . . . . . . . . . . . 6
Fastener And Replacement Parts . . 6
Tool Repair . . . . . . . . . . . . . . . . . . . . 6
Assembly Procedure For Seals . . . . . 6
Fasteners . . . . . . . . . . . . . . . . . . . . . . . 7
Troubleshooting Chart . . . . . . . . . . . . 8
Warranty . . . . . . . . . . . . . . . . . . . . . . 10
Description
This tool is designed for picture frame
assembly, cabinetry, casebacks, and
crafts. Features include: convenient top
loading magazine which holds up to
100 staples, adjustable depth control,
adjustable exhaust.
Unpacking
After unpacking the unit, inspect
carefully for any damage that may
have occurred during transit. Make sure
to tighten fittings, bolts, etc., before
putting unit into service.
Campbell Hausfeld Nailers meet or exceed Industries' Standards as set forth by the American
National Standard Institute/International Staple, Nail and Tool Association in ANSI/ISANTA
SNT-101-2002.
© 2009 Campbell Hausfeld/Scott Fetzer
Safety Guidelines
This manual contains information
that is very important to know and
understand. This information is
provided for SAFETY and to PREVENT
EQUIPMENT PROBLEMS. To help
recognize this information, observe the
following symbols.
hazardous situation which, if not
avoided, WILL result in death or serious
injury.
hazardous situation which, if not
avoided, COULD result in death or
serious injury.
hazardous situation which, if not
avoided, MAY result in minor or
moderate injury.
information, that if not followed, may
cause damage to equipment.
NOTE: Information that requires special
attention.
Important Safety Instructions
INSTRUCTIONS PERTAINING TO A
RISK OF FIRE, ELECTRIC SHOCK, OR
INJURY TO PERSONS
This manual contains safety, operational
and maintenance information. Contact
your Campbell Hausfeld representative
if you have any questions.
should always be followed, including
the following:
REMINDER: Keep your dated proof of purchase for warranty purposes!
Attach it to this manual or file it for safekeeping.
For parts, product & service information
visit www.chpower.com
1-1/4 inch Stapler
Model SN338K00
Danger indicates
an imminently
Warning indicates
a potentially
Caution indicates
a potentially
Notice indicates
important
CALIFORNIA PROPOSITION 65
contain chemicals known to the State
of California to cause cancer and birth
defects or other reproductive harm.
Wash hands after handling.
You can create dust when
you cut, sand, drill or grind
materials such as wood,
paint, metal, concrete, cement, or other
masonry. This dust often contains
chemicals known to cause cancer, birth
defects, or other reproductive harm.
When using tools,
Wear protective gear.
basic precautions
SN338K00
Locate model and date code on
tool magazine and / or body, and
record below:
Model No.: _____________________
Date Code: _____________________
Retain these numbers for
future reference.
This product or
its power cord may
IN729300AV 6/09
