ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE

PARTS LIST

PART
MATERIAL CODE
NO.
1
RWS6298-CS03-1
2
RWS6298-CS02-1
3
RWS6298-CS01-2
4
RWS6298-CS01-3
Attention:
Make sure that each bolt needed for all steps
matches the corresponding figure to ensure proper
assembly.

Step 1:

Fasten the seat assembly (#2) to the back
assembly (#1) by using bolts (#6). Keep the bolts
loose. See Figure 1.
Use the correct bolts as indicated. Do not tighten any of the bolts until the chair is completely
!
assembled.
Do not discard of any of the packaging until you have checked that you have all of the parts and
!
fittings required.
Keep children away during assembly. This item contains small parts that can be swallowed by
!
children. Children should always be under direct adult supervision while using this product.
Retain these assembly instructions for future reference.
!
Quote the following FQC No. when contacting the service center.
!
V-3
INTENDED FOR RESIDENTIAL USE ONLY.
RWS6298
PART Q'TY
BACK ASSEMBLY
SEAT ASSEMBLY
LEFT ARM
RIGHT ARM
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
DO NOT RETURN TO THE STORE!
STOP
PAGE 1 OF 3
5
17C40A0705001YX
1 6
17C40A0710001YX
1 7
17C40A0716001YX
1 8
17KAA0101----Y4
1 9
17KAC3101----Y3
FIGURE 1
1
BOLT M6*15
BOLT M6*30
BOLT M6*45
HEX. KEY WRENCH 4MM
HEX. KEY WRENCH 10MM
30
#6 BOLT M6*30
COURTYARD CREATIONS INC.
4
4
2
1
1
2
6
