ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE

PARTS LIST

PART
MATERIAL CODE
NO.
1
KUS795W-CS03-1
2
KUS795W-CS02-1
3
KUS795W-CS01-2
4
KUS795W-CS01-3
5
17C33A07A5001Y4
6
17C33A0706001Y4
7
17C02A0755131Y4
Attention:
Make sure that each bolt needed for all steps matches
the corresponding figure to ensure proper assembly.

Step 1:

Place the back assembly (#1) onto a non-abrasive
surface, such as a carpet. Insert the back assembly (#1)
into the seat assembly (#2). See Figure 1.
!
Use the correct bolts as indicated. Do not tighten any of the bolts until the bench is completely
assembled.
!
Do not discard of any of the packaging until you have checked that you have all of the parts and
fittings required.
!
Keep children away during assembly. This item contains small parts that can be swallowed by
children. Children should always be under direct adult supervision while using this product.
!
Retain these assembly instructions for future reference.
!
Quote the following FQC NO.when contacting the service center.
INTENDED FOR RESIDENTIAL USE ONLY.
KUS795W-
PART
BACK ASSEMBLY
SEAT ASSEMBLY
LEFT ARM
RIGHT ARM
BOLT M6*64
BOLT M6*16
BOLT M6*14
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
DON'T RETURN TO STORE!
STOP
PAGE 1 OF 3
WM
PART
Q'TY
MATERIAL CODE
NO.
1
8
17FA05040301-Y4
9
1
18000337004
1
10
18000337006
1
11
17KAA0101----Y4
4
12
17KAA0201----Y4
2
13
61K795WY00001BA
6
14
61K795WJ00001BA
FIGURE 1
PART
WASHER d6.5*D13*1.0
BOLT CAP
PLASTIC CAP M6
HEX.KEY WRENCH 4MM
HEX.KEY WRENCH 6MM
SEAT CUSHION
PILLOW
2
1
COURTYARD CREATIONS INC.
Q'TY
6
6
6
1
1
2
2
2
1
