Rich Context TGS66CW Assembly Instructions

Advertisement

Available languages

Available languages

ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE

PARTS LIST

PART
MATERIAL CODE
NO.
1
TGS66CW-CS05-1
2
TGS66CW-CS04-1
3
TGS66CW-CS04-2
You will need the following tools:
- Phillips Screwdriver (Not Included)
- Hex. Key Wrench (See Part #7)

Step 1:

Place the table top (#1) onto a non-abrasive surface, such as a
carpet, with its underside facing upwards. Insert the legs (#2)
and the supports (#3) into the plastic holders attached on the
underside of the table top (#1) rim. Fasten them together by
using screws (#5). See Figure 1.
Use the correct bolts as indicated. Do not tighten any of the bolts until the table is completely
!
assembled.
Do not sit or stand on this table.
!
A weighted umbrella base must be used when using an umbrella with this table.
!
Do not discard of any of the packaging until you have checked that you have all of the parts and
!
fittings required.
Keep children away during assembly. This item contains small parts that can be swallowed by
!
children. Children should always be under direct adult supervision while using this product.
Retain these assembly instructions for future reference.
!
Quote the following FQC NO. when contacting the service center.
!
V-3
INTENDED FOR RESIDENTIAL USE ONLY.
TGS66CW
PART
Q'TY
1
TABLE TOP
4
LEG
2
SUPPORT
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
DON'T RETURN TO STORE!
STOP
PAGE 1 OF 2
4
62TGS66CWY101
5
17C17A0403001YX
6
17C40A0709001YX
7
17KAA0101----Y4
FIGURE 1
2
2
3
3
1
5
COURTYARD CREATIONS INC.
CENTER
CONNECTOR WITH RING
SCREW ST4.2*12
BOLT M6*25
HEX.KEY WRENCH 4MM
2
2
2
1
3
1
1
6
6
1
5
