  • Page 1 PWdoc0010 rev1.0...

  • Page 2: Table Of Contents

    Contents page Product Overview Using WebTrack with the BlackBox Creating a WebTrack Account Login on to WebTrack Downloading and Installing WebSync Using ‘My Unit Setup’, for recording jobs Adding Details Enhancing Details (Farm Fields) Creating and Adding Form Items to Job Types (BB Pro users) Checking VRT Plans are available (BB VRT users) Transferring data to and from WebTrack via WebSync Fitting Instructions...

  • Page 3: Product Overview

    Product Overview The BlackBox unit can be upgraded by unlocking various areas of the software allowing it to perform additional tasks. The basic unit will be supplied with the Plus software unlocked, please see the following for details on the different software versions:- BlackBox Plus This software is used to record either basic job information against a job name...

  • Page 4: Using Webtrack With The Blackbox

    Using WebTrack with the BlackBox WebTrack is an internet based solution for the storage and viewing of data that has been recorded using the BlackBox unit. It is recommended that the recorded data is regularly transferred to the WebTrack account to ensure your records are kept up to date and secure.

  • Page 5: Login On To Webtrack

    Using WebTrack with the BlackBox Login on to WebTrack Go to the WebTrack home page by typing www.bbwebtrack.com in your internet browsers address bar. At this point you can add the home page to your favourites for future access. Under the Existing Users heading enter your Username and Password, then left mouse click on Login (see fig 1) (If you do not have a Username and...

  • Page 6: Downloading And Installing Websync

    Using WebTrack with the BlackBox Downloading and Installing WebSync software N.B. WebSync is the essential tool to transfer data to and from the BlackBox unit via your WebTrack account. To download the WebSync software you need to log into WebTrack. If unsure how to log on to WebTrack ‘Login please...

  • Page 7: Using 'My Unit Setup' For Recording Jobs

    Using WebTrack with the BlackBox Using ‘My Unit Setup’ for recording jobs Before using the Blackbox for recording jobs, the Farm and Fields, Vehicles, Implements (switch type and width), Operators and Job types can all be preset in WebTrack. With the Pro version of the BlackBox the Job types can be enhanced by adding form items.

  • Page 8: Creating And Adding Form Items To Job Types (Bb Pro Users)

    Using WebTrack with the BlackBox ..Enhancing Details (Farm Fields) Enter details here A new set of options will appear. In the Field Name box type in the details and click Add. To add another repeat the previous step. Left mouse click here When complete Once complete click Save.
  • Page 9 Using WebTrack with the BlackBox ...Creating and adding form items to Job Types (BlackBox Pro users) Click in check box next to ‘Use Form Items on this Job Type’ Left mouse click here Left mouse click here The form items options will appear, left mouse click Add Select form item Select form item using the drop down...

  • Page 10: Checking Vrt Plans Are Available (Bb Vrt Users)

    Using WebTrack with the BlackBox Checking VRT Plans are available (BlackBox VRT users) When a precision farming contractor has completed variable rate plans of your fields, they can upload them directly to your WebTrack account in BBA, ShapeVRT or XML Format (please ask your precision farming contractor).

  • Page 11: Transferring Data To And From Webtrack Via Websync

    From the Desktop of your Personal Select measurement Computer, go to the Windows Start type Button, then All Programs, locate and open the Patchwork Technology folder, and left mouse click on PWWebSync. Left mouse click here fig 1 First time users will be presented with the Setup dialog box (fig 1).
  • Page 12 Using WebTrack with the BlackBox ...Transferring data to and from WebTrack via WebSync Once configured you can now transfer Left mouse click here data to and from the USB memory stick. From the WebSync menu screen left click on the Sync BlackBox button (see fig 3).

  • Page 13: Fitting Instructions

    Fitting Instructions Mounting the Screen to vehicle windscreen The mounting is supplied in several parts. The ram ball is already attached to the back of the Screen. Before connecting the arm and suction mount Loosen loosen the screws of the ram ball Screws using a flat head screwdriver (do not unscrew completely).

  • Page 14: Mounting The Tilt Correction Unit

    Fitting Instructions Mounting the Tilt Correction Unit To front Mount the unit on to a flat surface within the vehicle with the arrow on the label pointing to the front of the cab. Secure Quick snatch plate (optional) Mount If using a quick snatch plate (optional), firstly mount the bottom plate on a flat surface.

  • Page 15: Connection Diagrams

    Fitting Instructions Connection Diagrams Main Unit Guidance Screen Cable Connectors USB data stick For recording job data. Must be inserted for the unit to operate. Tilt Correction Unit Magnetic Antenna 12v DC Plug To cigarette lighter socket on vehicle. Warning - Please disconnect the unit from the power supply, if you need to jump start your vehicle.

  • Page 16: Connecting Vrt Cable

    Fitting Instructions ...Connection Diagrams Connecting VRT Cable Tilt Correction Unit Controller To serial To port on port 2 Controller Supplied Cable The BlackBox will need to be configured to work correctly with the controller, for details see VRT Options menu on page 28. Connecting an In Cab Printer Tilt Correction Unit In Cab Printer...

  • Page 17: Connecting A On/Off Recording Switch

    Fitting Instructions ...Connection Diagrams Connecting a on/off Recording Switch Tilt Correction Unit Rocker Switch To rocker switch or 12v feed. The BlackBox will need to be configured to work correctly with the switch, for details see Ports Setup menu ‘On/Off’ on page 31. Connecting a Weather Station Weather Station Tilt Correction Unit...

  • Page 18: Unit Functions

    Unit Functions Tilt Correction Unit Power On/Off button – This turns the power to the tilt correction unit on/off. The power must be on to provide power to the screen. GPS On/Off button - To use the built in GPS this needs to be set to On, if using an external GPS source via serial port 1 set to Off.

  • Page 19: Unit Setup

    Unit Setup When using the BlackBox from time to time there will be a requirement to enter information or select an option from a list to continue. This will occur in the menus or when starting a job and there are four different input methods:- Selection list Some of the selection lists are predefined in the BlackBox, others can be setup by the user on WebTrack in the My Units Setup section (see page 07 for...

  • Page 20: Start Up Menu

    Start BlackBox DR Not applicable Start Field Note Not applicable Upgrade Initiates and installs any upgrades for the BlackBox 510 that are stored on the USB stick. Upgrades are available from the under the Support Services section on the Patchwork website www.patchwork.co.uk...

  • Page 21: Blackbox Menu

    Unit Setup BlackBox Menu The BlackBox menu is the main menu for setting up and accessing the different job modes of the BlackBox software. Start a guidance job or new boundary (for more details see ‘Starting a Job > Start New Job Start New Job’...

  • Page 22: Setup Menu

    Unit Setup Setup Menu The Setup Menu is used to setup the hardware and software for use within the job modes and it is vital that the settings are setup correctly for the unit to function as you require. Recording Details Sets the details that will be recorded against the job for record keeping and also the implement working width which is important to accurately set the tracks when using the unit for guidance (See page 23 for more details).
  • Page 23 Unit Setup Recording Details menu All the details that are entered in this area will be added to the job recording and is displayed within the information area of a job report when viewed in WebTrack. Vehicle The name of the vehicle that is being used for the job. Implement The name of the implement that is being used for the job.
  • Page 24 Unit Setup Recording Options menu The settings entered in this menu alter how data is recorded on the BlackBox, this includes the green trace and weather station information (if fitted). Recording This option is used to turn job recording on and off. If recording is set to ‘No’...
  • Page 25 Unit Setup ...Recording Options menu Weather Station Recording Options menu The options in this menu are used to select the weather details that will be obtained from a vehicle mountable weather station. The weather station needs to be connected via the serial port (see connection diagram on page 17) and automatically saved to a job when complete (BlackBox Pro required).
  • Page 26 Unit Setup GPS Offset Menu The options in this menu are used to offset the GPS position in relation to the position of the antenna (the unit measurement will depend on the units setup in Local Setting, see page 27 for details).
  • Page 27 Unit Setup Local Setting Menu The options in this menu are used to set you locality in the world for, unit measurements, language and the time difference (based on GMT). Country To select which country you are in. Units Sets the unit measurement type (i.e. Miles or Kilometres); this will affect the menu areas and guidance screen where a measurement is required or displayed.
  • Page 28 Unit Setup VRT Options Menu The options in this menu are used to set up the unit to communicate with external controllers for variable rate and auto shut off. VRT Controller Sets the controller type that the unit is being connected to. The recommended Port Speed for the controller will automatically change for the selected controller.
  • Page 29 Unit Setup ...VRT Options menu Auto Shut Off Settings menu The options in this menu are used to turn auto shut off on or off and adjust its working tolerance (only accessible with Auto Shut Off). Turns auto shut off on or off. This option must be set to ‘Yes’ for auto shut Auto Shut Off off to work.
  • Page 30 Unit Setup ...VRT Options menu VRT Test Screen This option is used to ensure that there is communications between the BlackBox and the Controller before starting a variable rate job. It is recommended that the test is done with the implement empty.
  • Page 31 Unit Setup Port Setup menu The options in this menu are used to setup the serial ports on the tilt correction box, the tilt compensator and trace recording On/Off method. Printer Port Sets the serial port that the in cab printer is connected to. GPS Speed To setup the port speed for the GPS port (Serial Port 1), when using an external source.
  • Page 32 Unit Setup ...Port Setup menu Tilt Compensator options menu The options in this menu are used to setup the tilt compensator and to visually calibrate the tilt mechanism. Angle Gauges Angle Gauges These gauges display the front/back and left/right angle you are currently on based on the last reset that was done.
  • Page 33 Unit Setup ...Port Setup menu On/Off selection list The options in this menu are used to set how the guidance trace is turned on/off when doing a guidance job. Turning the trace recording on and off when turning in the head land can give a more accurate coverage area reading for the recorded data.
  • Page 34 Next make a call to Patchwork Technology on +44 (0) 1291 673366 and state the upgrade you require (see Product Overview on page 03). The operator will firstly take payment for the upgrade and then issue an unlock code for the upgrade.

  • Page 35: Starting A Job

    Starting a Job After the unit has been setup, position the vehicle in the field where the job will begin. In the BlackBox menu there are two options for starting a job:- Start New Job Is used to begin a guidance recording job (with auto shut off if available) or new boundary job (area measurement).

  • Page 36: Start Planned Job

    Starting a Job Start Planned Job Is used to open a VRT (variable rate application) plan or a planned job exported from a compatible farm management software program. If a planned type job has been paused use this option to continue it.

  • Page 37: Using The Guidance Screens

    Using the Guidance Screens The unit has 3D and VRT guidance screen modes on the unit, the 3D screen will open when selecting the Start New Job option or opening a farm management software plan through Start Planned Job. The VRT screen will open when a VRT plan is selected through Start Planned Job.

  • Page 38: Creating A Field Boundary Map

    Using the Guidance Screens Creating a Field Boundary Map When creating field boundaries for future use and records it is important to turn the Autonaming option off (see page 24 for details). The farm and field details can be entered manually to ease traceability and the function of the auto farm / field recognition.

  • Page 39: Pausing And Clearing Boundary Map During Run

    Using the Guidance Screens ...Creating a Field Boundary Map Pausing and clearing boundary map during run During the run the field boundary can be:- Paused Pause Boundary Press the pause boundary button, when the job has been paused the button will change to the start boundary button, Button press again to continue.

  • Page 40: Using Guidance And Field Recording

    Using the Guidance Screens Using Guidance and Field Recording Guidance can be used to assist the operator in reducing under or overlap when applying products, improving coverage and reducing waste. Once the guidance screen is open it is ready to start a guidance recording job. Setting and using a guidance line Start the job by doing a head land pass of the field and depending on the On/Off setting a green trace line will be drawn where the work has been done.

  • Page 41: Setting Points, Pausing And Finishing A Job

    Using the Guidance Screens ...Using Guidance and Field Recording Setting points, Pausing and Finishing a Job During the job or when complete press the menu button, this opens the Job Options menu. Return to Job Returns to the guidance screen. Save Point Here Use this to set a location point for your current position to return to if a refill is required.

  • Page 42: Vrt Guidance Screen Overview

    Using the Guidance Screens VRT Guidance Screen Overview Recording On/Off Zoom In Zoom Out Zoom Reset Menu Button Information Panel Speed Coverage Area Application Distance Travelled Field Area Rate Guidance Bar Guidance line set Distance from Track Number Centre Guide Arrow...

  • Page 43: Using Guidance And Field Recording (Vrt Mode)

    Using the Guidance Screens Using Guidance and Field Recording (VRT Mode) Once the guidance screen is open and the VRT plan map is loaded, it is ready to start a guidance recording job. Setting and using a guidance line (VRT Mode) Start the job by doing a head land pass of the field, the green trace line will be drawn where the work has been done (When the BlackBox is connected to a controller the trace recording will automatically turn on when the implement is working or off when not working).

  • Page 44: Setting Points, Pausing And Finishing A Job

    Using the Guidance Screens ...Using Guidance and Field Recording (VRT Mode) Setting points, Pausing and Finishing a Job During the job or when complete press the menu button, this opens the Job Options menu. Return to Job returns to the guidance screen. Save Point Here use this to set a location point for your current position to return to if a refill is required.
