IMPORTANT: Fill out the product record information below.
Serial Number:
See rating label on unit for serial number.
Date Purchased
Note: Sales docket must be kept as
proof o f purchase date.
For customer service in
New Zealand contact:
Aber Holdings, Ltd via: Telephone:
080016116
Email: service@aber.co.nz
www.aber.co.nz
2531CS0048
ESS 1796520172
468640017N1
For use with propane gas only | For Outdoor Use Only
2531-19
CHAR-BROIL
PERFORMANCE SERIES
2 BURNER
DO NOT USE INDOORS
06/20/19 • G362-016-130801
Advertisement
Table of Contents
Related Manuals for Char-Broil PERFORMANCE 468640017N1
Summary of Contents for Char-Broil PERFORMANCE 468640017N1
- Page 1 CHAR-BROIL PERFORMANCE SERIES 468640017N1 2 BURNER IMPORTANT: Fill out the product record information below. Serial Number: See rating label on unit for serial number. Date Purchased Note: Sales docket must be kept as proof o f purchase date. For customer service in...
- Page 2 THIS APPLIANCE SHALL ONLY BE USED IN AN ABOVE GROUND OPEN AIR SITUATION WITH NATURAL VENTILATION, WITHOUT STAGNANT AREAS, WHERE GAS LEAKAGE AND PRODUCTS OF COMBUSTION ARE RAPIDLY DISPERSED BY WIND AND NATURAL CONVECTION. ANY ENCLOSURE IN WHICH THE APPLIANCE IS USED SHALL COMPLY WITH ONE OF THE FOLLOWING: •...
-
Page 3: For Your Safety
FOR YOUR SAFETY DANGER Safety Symbols If you smell gas: The symbols and boxes shown below explain what each heading means. Read and follow all of the messages found throughout 1. Shut off gas to the appliance, if possible. the manual. 2. - Page 4 USE AND CARE Gas Cylinder • The gas cylinder used with your barbecue must meet the following requirements: WARNING • Use gas cylinders only with these required measurements: 30.5 cm diameter x 45.7 cm tall with 9 kg. capacity maximum. This is the minimum cylinder that can be used.
- Page 5 Connecting Regulator to the LP Cylinder LP Cylinder Leak Test 1.LP cylinder must be properly secured onto grill. (Refer to For your safety assembly section.) •Leak test must be repeated each time LP cylinder is 2.Turn all control knobs to the OFF position. exchanged or refilled.
-
Page 6: Match-Lighting
Safety Tips Ignitor Lighting • Do not lean over barbecue while lighting. Before opening gas cylinder valve, check the regulator for Ÿ 1. Turn gas burner control valves to (off). tightness. 2. Open lid during lighting or re-lighting. When appliance is not in use, turn off all control knobs and Ÿ... -
Page 7: Spider Alert
NOTE: Your barbecue may NOT be equipped with a IF APPLIANCE FAILS TO LIGHT Hot plate! Ÿ Make sure gas is turned on at cylinder. Hot plate Ignitor Lighting Ÿ Make sure there is gas in the cylinder. •Do not lean over barbecue while lighting. Ÿ... -
Page 8: Maintenance
MAINTENANCE It is your responsibility to properly maintain your barbecue. •Stainless steel surfaces: To maintain your barbecue’s high quality appearance, wash with mild detergent and warm soapy water The frequency of the maintenance will depend on the level and wipe dry with a soft cloth after each use. Baked-on grease you use the barbecue. -
Page 9: Storing Your Appliance
Continued... Cleaning the Burner Assembly Follow these instructions to clean and/or replace parts of burner assembly or if you have trouble igniting barbecue. Firebox 1. Turn gas off at control knobs and LP cylinder. Electrode 2. Remove cooking grates and heat tents. 3. - Page 10 TECHNICAL DATA CHAR-BROIL, LLC Appliance Name Gas Barbecue Total Nominal Heat Input 19.0 MJ/Hr. Gas Category I3B/P(30) Model No. 468640017NZ Gas Type LP/ULPG Gas Pressure 2.75 kPa Injector Size (Dia. mm) Barbecue: 0.78 x 2 pcs Destination Countries Electrical Supply...
-
Page 11: Limited Warranty
The collection and delivery of your product, unless local regulations specify otherwise in which case local regulations will override this. In markets where there is no distributor or an authorized reseller Char-Broil consumers bear these costs themselves. 7. Pickup and delivery of your product. - Page 12 PARTS LIST 468640017N1...
- Page 13 PARTS DIAGRAM...
- Page 14 (Black) (Black) (Black)
- Page 17 Note: remove the tie wraps...
- Page 23 AA Battery Not included...
- Page 26 Leak test before first use, at least once per year, and every time the gas cylinder is changed or disconnected.
- Page 27 Inspect your infrared grate before each use to ensure that the openings are not covered with debris. See the Grilling Guide for detailed cleaning instructions.
-
Page 28: Troubleshooting
EMERGENCIES: If a gas leak cannot be stopped, or a fire occurs due to gas leakage, call the fire department. Emergencies Possible Cause Prevention/Solution Gas leaking from •Damaged hose. •Turn off gas at LP cylinder or at source on natural gas systems. Discontinue use of product and replace valve/hose/regulator. - Page 29 Troubleshooting (continued) Problem Possible Cause Prevention/Solution Burner(s) will not light PIEZO PUSH-BUTTON AND ROTARY: using ignitor. •Push-button sticks at bottom. •Replace ignitor. •Rotary knob rotates without clicking. •Replace knob. •Sparking between ignitor and electrode. •Inspect wire insulation and proper connection. Replace wires if insulation is broken.
- Page 30 Authorized Distributors List If you have a question or need help during assembly, call: Australia New Zealand Chile Sitro Group Australia Pty. Ltd. Aber Holdings Representaciones JCE Ph: 1-300-174-876 Ext. 1 Customer Service Line: 080016116 Servicio Técnico: 2414-2600 Email: service.group@sitro.com.au Email: serviciotecnico@jce.cl Email:...
- Page 31 Mexico Costa Rica Honduras Comercializadora DESICO JyG Importaciones DIUNSA Ph: 818-398-8250 Ph: 2222-5444 Ph: 2553-2721 Ext. 1468 Email: mercadotecnia@desico.com.mx Ave. 10, Calles 11 y 1E Edif. Ferretería email: Centro_dellamadas@diunsa.hn Email: servicio.cliente@desico.com.mx Website: www.diunsa.hn Jiménez. San José, COSTA RICA Website: www.desico.com.mx Email: info@grupojyg.com Ecuador...
- Page 32 For customer service in New Zealand contact: Aber Holdings, Ltd via: Telephone: 080016116 Email: service@aber.co.nz www.aber.co.nz...
