LPG Marine Cooker User and Installation Instructions for Australia GN Espace OceanChef XL 5 Burner - Model G1007G GN Espace Galley Solutions Limited Importer & Distribution in Australia Unit 1 Church Barns Ocean Solutions International Widford P.O Box 4446 Hertfordshire...
Page 2
IMPORTANT NOTICES THE INSTRUCTIONS PACKAGED WITH THIS APPLIANCE CONTAIN IMPORTANT INFORMATION ABOUT INSTALLATION AND USE. TO BE INSTALLED ONLY BY AN AUTHORIZED PERSON IN ACCORDANCE WITH LOCAL AND STATUTORY REGULATIONS THIS APPLIANCE IS NOT SUITABLE FOR INSTALLATION WITH AFTERMARKET LIDS/COVERS PROPANE GAS ONLY BEFORE FIRST USE—AFTER INSTALLATION THE APPLIANCE MUST BE TESTED FOR GAS SOUNDNESS AND SATISFACTORY OPERATION.
CONTENTS Page Number Introduction General Description Product Overview (5 Burner Shown) Using the appliance For your safety Lighting the appliance Hob, grill, and oven ignition Replacing the battery Using the hob Using and adjusting the pan fiddles (pan holders) Using the grill Grill Using the oven Oven...
General Description The GN Espace marine cooker is a single cavity gas oven with grill and a 5 Burner hob. Each burner has an indi- vidual gas safety thermocouple. It is designed to operate using an external LPG (Propane) regulated gas supply as per Australian regulations at 2.75kPa.
Gas types Propane gas pressures can vary depending on the country of origin. This may necessitate a change to your pro- pane tank regulator and a need to adapt your galley range to the new pressure. The chart below lists orifice and by-pass sizes for Australian propane pressures.
Introduction This marine cooker has been designed and manufactured to meet the required CE approvals. This It is important that you understand how to use and care for the appliance properly before you use it for the first time. This booklet is written with your safety in mind. Keep the booklet in a safe place so that anyone who uses the appliance can read it.
Using the Appliance Lighting the appliance Warning. All hob and burner flames should be predominately blue and without yellow tips. Hob, grill and Oven Ignition Replacing the Battery The battery for the ignition will usually last for many months. If the ignition system doesn't work you probably need to replace the battery.
Using and Adjusting the Pan Fiddles The cooker is fitted with a sea rail onto which the adjustable pan fiddles (2 per burner) are fitted. To attach the pan fiddle, open the thumbscrew on the clamp and place the saddle onto the sea rail. When the fiddle is in the correct position, tighten the thumb screw to hold the fiddle firmly in position.
Using the Oven Shelf Positions The oven has three shelf positions—top (for grilling), middle and lower. The oven is supplied with two removable oven shelf pan holder as standard. Additional oven shelf pan holders are available as optional accessories. 1. To remove the oven shelf pull it out until it reaches the safety stop.
Care and Cleaning General Clean your appliance regularly using a cloth that has been wrung out in hot soapy water (i.e. hot water with dishwashing liquid). Rinse and polish it dry using a soft cloth. Do not use any polishes, caustic cleaners, abrasives, washing soda or soap except those recommended. When you remove parts of your appliance for cleaning do not plunge them into water whilst they are very hot as this may damage the finish of the parts.
Cleaning the Grill and Oven General Regularly clean the oven cavity and door while they are still slightly warm. This way you can easily remove any splashes and spills. Wipe with a cloth that has been wrung out in hot soapy water. To avoid the possibility of the shelf jamming, ensure that all the entrance holes to the shelf runners are kept clean and clear of spillage.
Installing the Appliance It is a legal requirement that all gas appliances are installed by competent persons qualified in accordance with the local and Australian regulations (Check with your individual state’s regulatory body for qualified gas fitters to complete an installation of your appliance to the appropriate regulation standard in force at the time of installation ).
Electric 1.5v connection for ignition The battery holder and battery are supplied as loose component when the cooker delivered. This is supplied loose for transportation reasons. Fix the battery holder to the base of the cooker using the provided screws into the pre-drilled holes.
The cooker is set up to fit into a 625mm gap (this allows 2.5mm either side) with the gimbal pins removed. The cooker is designed to be mounted and held safely in place by means of a set of specifically designed runners (available from GN Espace as an accessory - sup- plied separately) fitted to the cooker box base.
Technical Specification The appliance is for use with LP gas. Propane (G31) 2.75kPa / 27.5 mbar Oven Internal dimensions (H x W x D - mm): 260 x 535 x 390 Number of tray positions: 5 Burner Total Heat Input (kW/g/h) 13.4 kW (983 g/h) Hotplate burners 1 x 3.0kW (226g/h) 3 x 1.9 kW (140 g/h),1 x 1.1 kW (80 g/h)
This instruction booklet is accurate at the date of printing, but will be superseded if specification or appearance are changed. Information Safety Information for users ANNEX A Emergency procedures Leakage • If LPG leakage is detected or suspected, the following action should be taken immediately. •...
ANNEX B Safe usage : Changing a cylinder The following safe practices should be complied with when changing a cylinder. Ensure that any manually operated valves on both the full and empty cylinder are turned off before changing. Replace the plastic safety cap or plug on disconnected cylinders. Store, transport and use cylinders vertically with the valve uppermost.
The unit is not designed to have a cover placed over it, and will cause a hazard if the unit is covered. The diagram above shows the drill locations for the runners (shown right) on the cabinet base which is common to the Levante, OceanChef and OceanChef XL models. Remote location of the 1.5V ignition battery holder For models intended for build-in installation, the battery holder and battery are supplied as loose component when the cooker is delivered.
