GN Espace OceanChef XL
Model G1007
LPG Marine Cooker
User and Installation Instructions
GN Espace Galley Solutions Limited
3A Millbrook Business Park
Hoe Lane
Nazeing
Essex
EN9 2RJ
UK
Tel: +44 (0)1992 893713
Email:
info@gn-espace.com
Web:
www.gn-espace.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OceanChef XL G1007 and is the answer not in the manual?

Questions and answers

Summary of Contents for GN Espace OceanChef XL G1007

  • Page 1 GN Espace OceanChef XL Model G1007 LPG Marine Cooker User and Installation Instructions GN Espace Galley Solutions Limited 3A Millbrook Business Park Hoe Lane Nazeing Essex EN9 2RJ Tel: +44 (0)1992 893713 Email: info@gn-espace.com Web: www.gn-espace.com...
  • Page 2: Table Of Contents

    Contents Introduction....................3 General Description ..................3 Product Overview ..................4 Introduction ..................... 5 Rating Plate ....................5 Using the appliance .................. 5 For your safety ..................5 Using the appliance ..................6 Lighting the appliance ................6 Hob, grill and oven ignition ..............6 Replacing the Battery ................
  • Page 3: Introduction

    Never check for leaks with a naked flame. General Description The GN Espace marine cooker is a single cavity gas oven with grill and a 5-burner hob. Each burner has an individual gas safety thermocouple. It is designed to operate using an external LPG, Propane or Butane gas supply (subject to appropriate injectors and gas pressure).
  • Page 4: Product Overview

    Camping Gaz (Butane) – The restricted orifice size on a CampingGaz container (R907, R904) limits the gas flow reaching the cooker (especially in cold weather) resulting is longer heat-up and cooking times. Gas types The appliance is suitable for use with LPG. Both propane and butane. No other gas must be used.
  • Page 5: Introduction

    Control panel Oven/Grill controller Hob Controls Ignition OceanChef XL Operating and Installation Instructions Introduction This marine cooker has been designed and manufactured to meet the required CE approvals. It is important that you understand how to use and care for the appliance properly before you use it for the first time.
  • Page 6: Using The Appliance

    Using the appliance Lighting the appliance Warning : All hob and burner flames should be prominently blue and without yellow tips. Hob, grill and oven ignition Replacing the Battery The battery for the ignition will usually last for many months. If the ignition system doesn't work you probably need to replace the battery.
  • Page 7: Using And Adjusting The Pan Fiddles

    Using and adjusting the pan fiddles The cooker is fitted with a sea rail onto which the adjustable pan fiddles (2 per burner) are fitted. To attach the pan fiddle, open the thumbscrew on the clamp and place the saddle onto the sea rail. When the fiddle is in the correct position, tighten the thumb screw to hold the fiddle firmly in position Using the grill...
  • Page 8: Oven

    The oven is supplied with two removable oven shelf pan holder designed to accommodate a Gastronorm GN 1/1 container as standard. Additional oven shelf pan holders are available as optional accessories. To remove the oven shelf pull it out until it reaches the safety stop. Slightly press the arms of the shelf inwards to disengage from the cavity runners.
  • Page 9: Care And Cleaning

    Care and cleaning General Clean your appliance regularly using a cloth that has been wrung out in hot soapy water (ie. hot water with dishwashing liquid). Rinse and polish it dry using a soft cloth. Do not use any polishes, caustic cleaners, abrasives, washing soda or soap except those recommended.
  • Page 10: Installing The Appliance

    General Regularly clean the oven cavity and door while they are still slightly warm. This way you can easily remove any splashes and spills. Wipe with a cloth that has been wrung out in hot soapy water. Do not clean the grill burner or oven burner itself. The burners are designed to be self cleaning. Cleaning the burners may cause the holes in the burner to become blocked preventing them from operating correctly.
  • Page 11: Electric 1.5V Connection For Ignition

    Electric 1.5v connection for ignition The battery holder and battery are supplied as loose component when the cooker delivered. This is supplied loose for transportation reasons. Fix the battery holder to the base of the cooker using the provided screws into the pre-drilled holes. Connect the cable to the battery holder using the push connections.
  • Page 12: Fixed Installation (Boats, Recreational Vehicles And Caravan)

    (available from GN Espace as an accessory - supplied separately) fitted to the cooker box base. ventilation gap of at least 30mm must be provided at the back edge of the cooker.
  • Page 13: Before First Use

    Before first use  Remove all accessories and packing from within the oven and before the first use, clean the interior and all fittings with a soap and warm water solution.  Important When using the grill for the first time, or when re-connecting after the gas supply has run out, you will need to prime the grill burner.
  • Page 14: Product Dimensions

    Product Dimensions Gas connection at right rear of the appliance IMPORTANT NOTICE In line with our continuing policy of research and development, we reserve the right to alter models and specifications without prior notice. This instruction booklet is accurate at the date of printing, but will be superseded if specification or appearance are changed.
  • Page 15: Annex A Emergency Procedures

    Information Safety Information for users ANNEX A Emergency procedures Leakage  If LPG leakage is detected or suspected, the following action should be taken immediately.  Shut off the LPG supply at the cylinder valve(s).  Extinguish naked flames and other ignition sources(heaters,cooking appliances, pilot lights, cigarettes etc).
  • Page 16 (5) Joints should be firm and gas tight. If a leak is suspected, after changing a cylinder and opening the valve, check the cylinder valve with an ammonia free leak detection fluid. Do not use a naked flame for testing. (6) If a leak cannot be stopped, move the cylinder to a safe place in the open, ensuring that the leaking LPG is dispersed safely.
