GN Espace Levante G1001 User And Installation Instructions Manual

Lpg marine cooker
Hide thumbs
Table of Contents

Advertisement

Quick Links

GN Espace Levante
4 Burner - Model G1001
3 Burner - Model G1003
2 Burner - Model G1004
LPG Marine Cooker
User and Installation Instructions
GN Espace Galley Solutions Limited
3A Millbrook Business Park
Hoe Lane, Nazeing
Essex, EN9 2RJ
UK
Tel: +44 (0)1992 893713
Email:
info@gn-espace.com
Web:
www.gn-espace.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Levante G1001 and is the answer not in the manual?

Questions and answers

Related Manuals for GN Espace Levante G1001

Summary of Contents for GN Espace Levante G1001

  • Page 1 GN Espace Levante 4 Burner - Model G1001 3 Burner - Model G1003 2 Burner - Model G1004 LPG Marine Cooker User and Installation Instructions GN Espace Galley Solutions Limited 3A Millbrook Business Park Hoe Lane, Nazeing Essex, EN9 2RJ...

  • Page 2: Table Of Contents

    Contents Introduction....................3 General Description ..................3 Product Overview (2 burner shown) .............. 4 Using the appliance .................. 4 For your safety .................... 4 Lighting the appliance ................5 Hob, grill and oven ignition ................5 Replacing the Battery ................... 5 Using the hob ....................

  • Page 3: Introduction

    Never check for leaks with a naked flame. General Description The GN Espace marine cooker is a single cavity gas oven with grill and a hob. Each burner has an individual gas safety thermocouple. It is designed to operate using an external LPG, Propane or Butane gas supply (subject to appropriate injectors and gas pressure) petroleum gas (LPG) systems.

  • Page 4: Product Overview (2 Burner Shown)

    Gas types The appliance is suitable for use with LPG. Both propane and butane. No other gas must be used. The following gas details and pressures must be applied: CAT I3+ (28-30/37) CAT I3B/P Butane (G30) 28-30mbar Butane (G30) 30mbar Propane (G31) 37mbar Propane (G31) 30mbar Product Overview (2 burner shown)

  • Page 5: Lighting The Appliance

     The appliance must be sited in an area free from draughts which could effect combustion in a manner which will allow a build up of unburned gas.  All air vents must be open and well maintained.  Whenever operating the appliance ensure that the gas cylinder is correctly connected to the appliance gas supply ...

  • Page 6: Using And Adjusting The Pan Fiddles

    1. Push in the control knob and turn it to the maximum setting. Keep the control knob pushed in and press the ignition button immediately. 2. When the burner has lit, release the ignition button, but keep holding in the control knob for 15 seconds (to heat the thermocouple).

  • Page 7: Using The Oven

    If the burner flame is accidentally extinguished during cooking, turn off the gas and wait at least one minute before attempting to reignite. Fitting the grill deflector. Using the oven Shelf positions The oven has three shelf positions - top (for grilling), middle and lower. The oven is supplied with two removable oven shelf pan holder as standard.

  • Page 8: Oven

    Oven To light oven: 1. Open the oven door. 2. Push in the control knob and turn it to the maximum oven setting. Keep the control knob pushed in and press the ignition button immediately. 3. When the burner has lit, release the ignition button, but keep holding in the control knob for 15 seconds (to heat the thermocouple) 4.
  • Page 9  Make sure that the electrode and the hole and slots in the ring are not blocked with food or cleaning materials.  Clean the burner rings by soaking them in very hot soapy water.  You can remove any stubborn stains by scouring with a soap-filled scrubbing pad. ...

  • Page 10: Installing The Appliance

    Warning. Any servicing or maintenance work carried out by an unauthorised person will invalidate the manufacturers warranty and could result in a dangerous situation. Installing the appliance It is a legal requirement that all gas appliances are installed by competent persons qualified in accordance with the local and national regulations (GasSafe registered in the UK).

  • Page 11: Gas Connection

    5. Suitable mounting blocks for the gimbal pivot facing bracket and harbour lock facing bracket in order to create a 485mm wide gap need to be fabricated. See pictures below. 6. Attach counterweight to base of cooker (if not already fitted) with screws provided. Lift cooker into position on the gimbal pivot facing bracket.

  • Page 12: Gas Connection (Recreational Vehicles, Caravans)

    Flexible hoses should not pass through bulkheads, decks or partitions unless protected from abrasion. Flexible hoses should not be subjected to temperatures above 50°C After installation the appliance must be tested for gas soundness. In the event of problems being encountered during installation, commissioning or operation the manufacturer should be informed and any necessary service arranged.

  • Page 13: Technical Specification

    Technical Specification The appliance is for use with LP gas. CAT I3+ (28-30/37) CAT I3B/P(30) Butane (G30) 28-30 mbar Butane (G30) 30 mbar Propane (G31) 37 mbar Propane G(31) 30 mbar Oven Internal dimensions (HxWxDmm): 265 x 337 x 325 Number of tray positions: 4 Burner Total Heat Input (kW/g/h)

  • Page 14: Product Dimensions

    Product Dimensions Gas connection at right rear of the appliance IMPORTANT NOTICE In line with our continuing policy of research and development, we reserve the right to alter models and specifications without prior notice. This instruction booklet is accurate at the date of printing, but will be superseded if specification or appearance are changed.

  • Page 15: Annex A Emergency Procedures

    Information Safety Information for users ANNEX A Emergency procedures Leakage  If LPG leakage is detected or suspected, the following action should be taken immediately.  Shut off the LPG supply at the cylinder valve(s).  Extinguish naked flames and other ignition sources(heaters,cooking appliances, pilot lights, cigarettes etc).
  • Page 16 (5) Joints should be firm and gas tight. If a leak is suspected, after changing a cylinder and opening the valve, check the cylinder valve with an ammonia free leak detection fluid. Do not use a naked flame for testing. (6) If a leak cannot be stopped, move the cylinder to a safe place in the open, ensuring that the leaking LPG is dispersed safely.
