H.264 to MPEG-2 HD Transcoder
for up to 12 SPTS Channels
Stock #
6559
© Blonder Tongue Labs, Inc.
All Rights Reserved. Specifications subject to change without notice. All trademarks are property of their respective owners.
Model Name
Description
Clearview 4:2 12
H.264
ISO 9001:2015 Certified
Clearview 4:2 12
to MPEG-2 HD Transcoder; 12 Channels
(AVC)
Quick Guide
P/N: 651245400A | Rev: 070921
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Blonder tongue Clearview 4:2 12
Summary of Contents for Blonder tongue Clearview 4:2 12
- Page 1 Clearview 4:2 12 H.264 to MPEG-2 HD Transcoder; 12 Channels (AVC) P/N: 651245400A | Rev: 070921 ISO 9001:2015 Certified © Blonder Tongue Labs, Inc. All Rights Reserved. Specifications subject to change without notice. All trademarks are property of their respective owners.
- Page 2 Quick Guide Product Introduction The Clearview 4:2 12 receives up to twelve (12) H.264 AES-128 encrypted IP channels from the Technicolor COM3000/2000 devices. The Clearview 4:2 12 decrypts the AES-128 content into clear IP, transcodes the decrypted H.264 content into MPEG-2, while preserving the “forensic watermarking”...
- Page 3 Clearview 4:2 12 Quick Guide Step 2: Connecting to a PC/Laptop ETHERNET ACCESS: Local or remote communication with the unit is only possible through a GUI-based menu via web browser (Chrome or Firefox is recommended). Before you can communicate with the unit, you must configure your computer's IP address to be in the same subnet as the units default IP address.
- Page 4 An Ethernet Cable should be connected between your PC and the “Control” port on the unit. Open a Web browser (Chrome or Firefox recommended) and type http://172.16.70.1 in to your web browser to view and configure your Clearview 4:2 12. Enter the username “Admin” and “pass” as the password and click [LOG IN]. Step 4: Basic Configuration System Status Once you are logged into the unit, you will be presented with the “System Status”...
- Page 5 Clearview 4:2 12 Quick Guide Step 4: Basic Configuration (continued) System Settings Go to the “System” tab to change the System Settings, including unit identification and network settings. The user is also able to reboot the unit and upload/download configuration files. Once downloaded, the settings can be applied to the unit or the user can choose to set the unit back to the default factory settings with a click of a button.
- Page 6 6 Clearview 4:2 12 Quick Guide Step 5: Transcoder Configuration Transcoders: Settings The final information to setup within the unit is located in the “Transcoders:” > “Settings” tab. Transcoders: Settings Page - Example On this page, the user is able to set up the Video and Audio Pipeline settings, located on the right side.
- Page 7 (XC1 - XC6) IP addresses assigned to avoid collisions with XC IP addresses on other Clearview 4:2 12 units. In other words, all XC IP addresses on a network *must* be unique across all Clearview 4:2 12 units.
- Page 8 A Return Material Authorization (RMA) Number is required on all products returned to Blonder Tongue, regardless if the product is being returned for repair or credit. Before returning product, please contact the Blonder Tongue Service Department at 1-800-523-6049, Ext. 4256 or visit our website: www.blondertongue.com...
