2-2. Models: AOUH12LUAS1 and AOUH18LUAS1

4-M10 hole
3/4 (19)
Side view
2-2. Models: AOUH12LUAS1 and AOUH18LUAS1
22-13/16 (580)
Pitch of bolts for installation
Top view
31-7/16 (799)
Front view
Airflow
Hole
Hole
15-11/16 (399)
Drain port Ø1-5/8 (42)
Bottom view
4-5/16 (109)
2-11/16 (68) 1/2 (13)
1-5/16 (33)
Hole
- 74 -
Unit: in (mm)
11-7/16 (290)
1-3/16 (30)
Side view
7-1/16 (180)
Side view (Valve part)
2. Dimensions
