Summary of Contents for Mackworth SA180
- Page 1 SA180 Stand Aid User Manual Doc No. 999065 Revision of document: A Revision Date: 19.04.21...
-
Page 2: Table Of Contents
Battery ............................14 5.7.1 Charging the Battery Pack ....................14 Slings ............................14 Technical Specification ........................17 Mackworth SA180 Dimensions ..................... 17 Specifications ..........................18 Electrical Specifications ........................ 18 999065 – Revision A P a g e | 2 of 32... - Page 3 Standards Applied ........................18 Environmental - Storage and Operating Conditions ................19 Normal Operating Conditions ....................... 19 Shipping and Storage Conditions ....................19 Disposal ............................19 Fault Finding ............................ 20 General Inspection, Maintenance and Cleaning ................21 Service ............................21 Inspection ..........................
-
Page 4: Safety Instructions And Warnings
Please read and understand this manual in its entirety before using your Mackworth SA180 Stand Aid. The information in this manual is important for the safety of anyone near the Mackworth SA180 Stand Aid and must be read and understood to help prevent injuries. It is also crucial to the proper operation and maintenance of the Stand Aid. -
Page 5: Symbols Used
Symbols Used The Table below includes all Symbols from BS EN ISO 15223-1:2016 that can be found in this Manual and on the Product and what they represent. Refer back to this Table when you are unsure of what a symbol represents. Consult instructions before use Caution –... -
Page 6: Contraindications / Limitations
Carrying out each transfer correctly for minimal strain or risk to the caregiver, while providing complete safety, dignity and comfort to the client. The Mackworth SA180 is suitable for patients in the SITTING position only, who have a degree of weight- bearing ability but require assistance to stand. -
Page 7: Warning Notes
2. ALL Stand Aids are dangerous to the person being transferred when used recklessly or pushed at speed. Operating Environment The Mackworth SA180 is suitable for use within the professional health care facility environment as well as the home health care environment. The Stand Aid is not suitable for any special environments. -
Page 8: Components / Key Parts
COMPONENTS / KEY PARTS Please see below to familiarise yourself with the components of the Mackworth SA180 Stand Aid. The images below show the contents of the Stand Aid. If you have not received all the components contact Prism Medical UK dealer immediately – contact details are provided on the last page of this manual. -
Page 9: Assembly Instructions
ASSEMBLY INSTRUCTIONS Unpacking Some of the parts are heavy and will need to be lifted with care. Items weighing over 20kg will require a two person lift. Please refer to (6.0) technical specifications for components weights. The Stand Aid will arrive to you in a robust box, please be careful when removing the components from the box. Please read the user guide in full before operating. -
Page 10: Stand Aid Assembly
Stand Aid Assembly A. Carefully open the box and remove all loose parts and excess packaging from the box. 2 person lift recommended for the following points. B. Carefully holding onto the handle and boom, lift the Stand Aid components out of the box. -
Page 11: Electrical Connections
Electrical Connections Connect all the cables to the control box as shown in the pictures opposite. A. Connect the lift actuator cable connector to the second port (marked No. 1) from the left side of the control box (as shown in Fig. 6). Figure 6 B. -
Page 12: Operating Instructions
Figure 11 Raising and Lowering The up and down movement of the lifting arm on the Mackworth SA180 Stand Aid is achieved by an electric actuator which is controlled by hand control. The hand control has two buttons with directional arrows up and down. The actuator stops automatically at the limit of travel in both directions. -
Page 13: Emergency Stop Button
Emergency Stop Button The Mackworth SA180 Stand Aid is fitted with an Emergency Stop button. Push the Emergency Stop button (as shown in Fig. 16) to cut all power on the Stand Aid. Figure 16 To resume power, release the emergency stop button by turning in a clockwise direction (indicated by arrows on the Emergency Stop button) as shown in Fig. -
Page 14: Battery Status
5.6.1 Battery Status A single LED is used to indicate Low Battery, the LED will light up orange when battery power is low. This means the battery needs charging. At this stage some of the functionality of the lift is lost. At this battery stage, it is not possible to drive the lifting arm up or down. - Page 15 BS EN ISO 10535 before its use. The slings with a safe working load of 180kg that can be used with the Mackworth SA180 Stand Aid are shown below in Table’s 3 and 4 complete with product codes. For all components, the lowest maximum safe working load must always be adhered too...
- Page 16 CA800PP4 CA800MP4 CA800SP4 CA800PAP4 CA800PP5 CA800MP5 CA800SP5 CA800PAP5 X Small CA800PXS CA800MXS CA800SXS CA800PAXS Small CA800PS CA800MS CA800SS CA800PAS Small/Medium CA800PSM CA800MSM CA800SSM CA800PASM Medium CA800PM CA800MM CA800SM CA800PAM Medium/Large CA800PML CA800MML CA800SML CA800PAML Large CA800PL CA800ML CA800SL CA800PAL X Large CA800PXL CA800MXL CA800SXL...
-
Page 17: Technical Specification
TECHNICAL SPECIFICATION Mackworth SA180 Dimensions All dimensions below are shown in millimetres. Figure 27 Figure 28 999065 – Revision A P a g e | 17 of 32... -
Page 18: Specifications
Specifications Dimensions Turning Circle 1230mm Overall Height 1720mm Overall Width 680mm Ground Clearance 33mm Front and Rear Castors Size 100mm Table 5 Weights: Safe Working Load (SWL) 180 kg Full Product 47 kg Base Assembly 23 kg Mast & Boom Assembly 24 kg Table 6 Operational Forces... -
Page 19: Environmental - Storage And Operating Conditions
ENVIRONMENTAL - STORAGE AND OPERATING CONDITIONS The Mackworth SA180 is intended for internal use within normal environmental conditions. It is not intended to be used in environments where there are rapid changes in the environmental temperature and humidity during intended use. -
Page 20: Fault Finding
FAULT FINDING If a problem arises with the Stand Aid, the Table below will hopefully assists in determining the fault and what actions you can take. If the fault cannot be found or the fault is found and the action guide does not provide a fix (e.g. – a damaged wire would need replacement), contact your local Prism Medical UK authorised dealer immediately, a service engineer will be required to repair the Stand Aid. -
Page 21: General Inspection, Maintenance And Cleaning
GENERAL INSPECTION, MAINTENANCE AND CLEANING Service No service is to be carried out on the Mackworth SA180 while transferring a person to reduce the risk of injury. Service must be completed by a Prism Medical UK authorised Service Engineer. Do not attempt to service the product yourself, or warranty is void. -
Page 22: Cleaning
The exterior of the Mackworth SA180 can be cleaned using a damp soapy cloth for general cleaning duties. Please ensure the cloth is damp and not wet. Ensure the exterior of the device is dry after cleaning. Dry using a clean dry cloth. - Page 23 • 1 tablet (1.7g formed tablet (x1)) will create a virucidal solution, diluted in 1 litre of water to provide effective means to clean a “dirty” device. This is also ideal for use after an outbreak of the Norovirus/winter vomiting and can be used as a precaution against C.Diff.
-
Page 24: Warranty
This guarantee does not affect or in any way limit your Statutory Rights. 1. Prism Medical UK guarantees the Mackworth SA180, supplied as new, against failure within the period of 24 months from the date of purchase by virtue of defects in material or workmanship. (Excluding Batteries) 2. -
Page 25: Service Record History
SERVICE RECORD HISTORY Complete this section after each service, repair inspection and/or maintenance. 999065 – Revision A P a g e | 25 of 32... - Page 26 999065 – Revision A P a g e | 26 of 32...
- Page 27 999065 – Revision A P a g e | 27 of 32...
- Page 28 999065 – Revision A P a g e | 28 of 32...
- Page 29 999065 – Revision A P a g e | 29 of 32...
- Page 30 User notes: 999065 – Revision A P a g e | 30 of 32...
- Page 31 User notes: 999065 – Revision A P a g e | 31 of 32...
- Page 32 Dealer/service contact details: Manufacturer contact details: Prism Medical UK Address: Unit 1 • Tir Llwyd Industrial Estate • St Asaph Avenue • Kinmel Bay • Conwy • LL18 5JZ Telephone Number: 01924 840100 Disclaimer While every effort has been made to ensure the accuracy of information contained in this user manual, no liability can be accepted by Prism Medical UK for any errors or omissions.
