DÉCO NANO
(DB03215 model)
CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION INSPECTION REQUIREMENTS
IN LOCAL AREA.
READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND USE OF THIS WOOD STOVE. FAILURE TO FOLLOW THESE
INSTRUCTIONS COULD RESULT IN PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH.
READ AND KEEP THIS MANUAL FOR REFERENCE
Printed in Canada
Wood Stove
Owner's Manual
Part 2 of 2
INSTALLATION AND
OPERATION REQUIREMENTS
US Environmental Protection Agency
phase II certified wood stove compliant
with 2020 cord wood standard
Safety tested according to ULC S627,
UL 1482 and UL 737 standards by an
accredited laboratory.
MOBILE
HOME
46243I_A
2021-05-21

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DECO NANO Escape 1200 and is the answer not in the manual?

Questions and answers

Related Manuals for Drolet DECO NANO Escape 1200

Summary of Contents for Drolet DECO NANO Escape 1200

  • Page 1 Wood Stove Owner's Manual Part 2 of 2 INSTALLATION AND OPERATION REQUIREMENTS DÉCO NANO (DB03215 model) US Environmental Protection Agency phase II certified wood stove compliant with 2020 cord wood standard Safety tested according to ULC S627, UL 1482 and UL 737 standards by an accredited laboratory.
  • Page 2 If it can not be provided, the warranty period will be determined by the date of manufacture of the product. It is also highly recommended to register the warranty online at https://www.drolet.ca/en/warranty/warranty-registration/ Registering the warranty will help to quickly find the information needed on the unit.

  • Page 3: Table Of Contents

    7. Maintenance/Parts Replacement ..................30 7.1 Replacement ........................30 7.2 Gasket ..........................31 7.3 Door ..........................31 7.3.1 Adjustment ......................32 7.3.2 Gasket ........................32 8. Exploded Diagram and Parts List ..................33 DROLET LIMITED LIFETIME WARRANTY ................. 36 Installation and Operation Manual - Déco Nano Page 3...

  • Page 4: Certification Plate

    1. CERTIFICATION PLATE Page 4 Installation and Operation Manual - Déco Nano...
  • Page 5 Installation and Operation Manual - Déco Nano Page 5...

  • Page 6: General Information

    2. General Information Performances Values are as measured per test method, except for the recommended heating area, firebox volume, maximum burn time and maximum heat output. Model Escape 1200 (DB03182) Combustion type Non-catalytic Fuel Type Dry Cordwood Recommended heating area (sq. ft. 250 to 1,200 ft (23 to 111 m Total firebox volume...

  • Page 7: Specifications

    Specifications Maximum log length 17 in (432 mm) north-south Flue outlet diameter 6 in (150 mm) Recommended connector pipe diameter 6 in (150 mm) Type of chimney ULC-S629, UL 103 HT (2100 °F) Minimum chimney height 12 feet Baffle material Vermiculite Approved for alcove installation Approved for mobile home installation...
  • Page 8 Dimensions 2.3.1 Stove Dimensions 18 1/2" 470mm 9 1/4" 235mm 6" 153mm Figure 1: Top View 29 1/8" 739mm 22 3/4" 578mm 10 1/4" 260mm 19 1/2" 494mm 16" 407mm Figure 2: Front View Figure 3: Side View Page 8 Installation and Operation Manual - Déco Nano...
  • Page 9 2.3.2 Combustion Chamber Dimensions 7 5/8" 195mm 12" 305mm Figure 4: Door Opening 1/4" 3/16" 11 3/4" 298mm 14 1/4" 19 1/8" 360mm 484mm Figure 5: Front View - Combustion Chamber Figure 6: Side View - Combustion Chamber Installation and Operation Manual - Déco Nano Page 9...

  • Page 10: Epa Loading

    EPA loading The charging methods shown below are those that were used during emissions certification. 2.4.1 Air control The air control is located underneath the ash shelf. To open the air control, push the air control handle completely to the left (High).

  • Page 11: Clearances To Combustible Material

    3. Clearances to Combustible Material The clearances shown in this section have been determined by tests according to procedures set out in safety standards ULC S627 (Canada), UL 1482 (U.S.A.) and UL 737 (U.S.A.). When the stove is installed so that its surfaces are at or beyond the minimum clearances specified, combustible surfaces will not overheat under normal and even abnormal operating conditions.
  • Page 12 48" Flush 48" 36" 122 cm 92 cm Figure 7: Clearances - Top Figure 8: Clearances - Corner 84" 213 cm Figure 9: Clearances - Side Page 12 Installation and Operation Manual - Déco Nano...

  • Page 13: With Heat Shield Ac02762

    3.1.1 With Heat Shield AC02762 To reduce the clearances of an appliance using a single wall pipe connector, the use of a heat shield certified with the single wall pipe connector to be used as close as 6" from combustible materials must be used.

  • Page 14: With Lowered Ceiling

    3.1.2 With Lowered Ceiling APPLIANCE CLEARANCES WITH SINGLE WALL PIPE CONNECTOR Canada 14" (356 mm) 14" (356 mm) 20" (508 mm) 20" (508 mm) 11" (279 mm) 11" (279 mm) 72" (1829 mm) 72" (1829 mm) APPLIANCE CLEARANCES WITH DOUBLE WALL PIPE CONNECTOR Canada 6"...

  • Page 15: With Heat Shield Ac02762 And Lowered Ceiling

    3.1.3 With Heat Shield AC02762 and Lowered Ceiling To reduce the clearances of an appliance using a single wall pipe connector, the use of a heat shield certified with the single wall pipe connector to be used as close as 6" from combustible materials must be used.

  • Page 16: Inside An Alcove

    3.1.4 Inside an Alcove See section 3.1 for single wall pipe installation. APPLIANCE CLEARANCES WITH DOUBLE WALL PIPE CONNECTOR Canada 6" (152 mm) 6" (152 mm) 20" (508 mm) 20" (508 mm) 48" (1219 mm) 36" (914 mm) 72" (1829 mm) 72"...

  • Page 17: Mobile Home With Heat Shield Ac02762

    3.1.6 Mobile Home With Heat Shield AC02762 It is strictly forbidden to install a unit with a single wall pipe in a mobile home. APPLIANCE CLEARANCES WITH DOUBLE DISTANCES FROM PIPE CONNECTOR WALL PIPE CONNECTOR WITH DOUBLE WALL PIPE CONNECTOR Canada Canada 3"...

  • Page 18: Floor Protection

    4. Floor Protection This stove is designed to prevent the floor from overheating. However, it must be placed on a non-flammable surface to protect the floor from hot embers that may fall during loading. The floor protection must be a continuous, non combustible material, such as steel with a minimum thickness of 0.015"...

  • Page 19: Reducing Wall And Ceiling Clearances Safely

    5. Reducing Wall and Ceiling Clearances Safely It is often desired to use as little space as possible when installing a wood stove. To do this, it is possible to reduce the clearances safely and install the stove closer to the walls by permanently installing a heat shield between the stove and the flammable material.
  • Page 20 Figure 13: Heat shield clearances Figure 14: Heat shield clearances Page 20 Installation and Operation Manual - Déco Nano...
  • Page 21 CLEARANCES MAY BE REDUCED BY THESE PERCENTAGES TYPE OF SHIELD SIDES AND REAR TOP (CEILING) CAN / CAN / USA (%) MIN. USA (%) MIN. Sheet metal, a minimum of 24 gauge (0.61 mm) in thickness , spaced out at least 1" (25 mm)* by non-combustible spacers 12"...

  • Page 22: Options Installation On Your Product

    6. OPTIONS INSTALLATION ON YOUR PRODUCT Page 22 Installation and Operation Manual - Déco Nano...

  • Page 23: Optional Fresh Air Intake Kit Installation

    Optional Fresh Air Intake Kit Installation THE IMAGES SHOWN ARE INDICATIVE ONLY AND MAY DIFFER OF YOUR PRODUCT, BUT THE ASSEMBLY REMAINS THE SAME. This mobile home approved stove requires the installation of a fresh air intake kit (A) and an insulated fresh air intake pipe (HVAC type, must meet ULC S110 or UL 181 class 0 or class 1) (B), sold separately.
  • Page 24 2. Remove the air control cover (D). To do this, unscrew the two screws (E) which hold it to the stove. 3. Pull firmly on the heat shield (F) to remove it. Page 24 Installation and Operation Manual - Déco Nano...
  • Page 25 4. Remove the two plates cut from the heat shield (F) by cutting the knockouts with pliers. Remove the backplate by cutting the knockouts with pliers. MICROJOINTS Installation and Operation Manual - Déco Nano Page 25...

  • Page 26: Optional Fire Screen Installation

    Optional Fire Screen Installation THE IMAGES SHOWN ARE INDICATIVE ONLY AND MAY DIFFER OF YOUR PRODUCT, BUT THE ASSEMBLY REMAINS THE SAME. In the United States or in provinces with a particulate emission limit (eg US EPA), the use of wood stoves with open door with and fire screen is prohibited.

  • Page 27: Optional Blower And Thermodisc Installation

    Optional Blower And Thermodisc Installation THE IMAGES SHOWN ARE INDICATIVE ONLY AND MAY DIFFER OF YOUR PRODUCT, BUT THE ASSEMBLY REMAINS THE SAME. A blower and a thermodisc, sold separately, can be installed on the stove. The installation of the blower is identical for a stove on legs or pedestal.

  • Page 28: Air Tubes And Baffle Installation

    Air Tubes And Baffle Installation Starting with the rear tube, lean and insert the right end of the secondary air tube into the rear right channel hole. Then lift and insert the left end of the tube into the rear left channel. Align the notch in the left end of the tube with the key of the left air channel hole.
  • Page 29 Note that secondary air tubes (B) can be replaced without removing the baffle board (A) and that all tube are not necessarely identical (look at the part number on the tube). Installation and Operation Manual - Déco Nano Page 29...

  • Page 30: Mobile Home Installation

    Mobile Home Installation THE IMAGES SHOWN ARE INDICATIVE ONLY AND MAY DIFFER OF YOUR PRODUCT, BUT THE ASSEMBLY REMAINS THE SAME. Screw the base on the floor with the proper hardware. Page 30 Installation and Operation Manual - Déco Nano...

  • Page 31: Maintenance/Parts Replacement

    7. Maintenance/Parts Replacement Do not clean the glass when the stove is hot. Do not abuse the glass door by striking or slamming shut. Do not use the stove if the glass is broken. Replacement The glass used is a ceramic glass, 5/32" (4 mm) thick, tested to reach temperatures up to 1400º F.

  • Page 32: Gasket

    Gasket The glass gasket is flat, adhesive-backed, woven fibreglass. The gasket must be centred on the edge of the glass. Follow the steps of the previous section to remove the glass. Remove the old gasket and clean the glass thoroughly. Peel back a section of the paper covering the adhesive and place the gasket on a table with the adhesive side Stick the end of the gasket to the middle of one edge, then press the edge of the glass down onto...
  • Page 33 7.3.2 Door Alignment Door alignment should be checked before lighting the wood stove for the first time, as it may not be properly aligned. To align, open the door and loosen the pressures screws located on the lower and upper hinges of the door using a 3/32”...
  • Page 34 7.3.3 Gasket It is important to replace the gasket with another having the same diameter and density to maintain a good seal. Remove the door and place it face-down on something soft like a cushion of rags or a piece of carpet.

  • Page 35: Exploded Diagram And Parts List

    8. Exploded Diagram and Parts List Installation and Operation Manual - Déco Nano Page 35...
  • Page 36 IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement parts for your stove, please provide the model number and serial number. We reserve the right to change parts due to technology upgrade or availability. Contact an authorized dealer to obtain one of these parts.
  • Page 37 Item Description AC02055 QUICK CONNECT THERMODISC 44028 CERAMIC THERMODISC F110-20F AC02050 BLOWER ASSEMBLY WITH VARIABLE SPEED CONTROL (UP TO 100 CFM) 44085 RHEOSTAT KNOB 44087 RHEOSTAT NUT 44080 RHEOSTAT WITHOUT NUT (MODEL KBMS-13BV) 44073 CROSSFLOW BLOWER 115V-60Hz-39W 100 CFM 60013 POWER CORD 96"...

  • Page 38: Drolet Limited Lifetime Warranty

    Shall your unit or a component be defective, contact immediately your DROLET dealer. To accelerate processing of your warranty claim, make sure to have on hand the following information when calling: •...
  • Page 40 Resale is strictly prohibited. The manufacturer may update St-Augustin-de-Desmaures (Québec) Canada this document from time to time and cannot be responsible G3A 2H3 for problems, injuries, or damages arising out of the use 418-908-8002 of information contained in any document obtained from https://www.drolet.ca/en/ unauthorized sources. tech@sbi-international.com...
