Campbell Hausfeld JB004250 Operating Instructions Manual

See Warranty on page 8 for important information about commercial use of this product.
Operating Instructions
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury, death
and/or property damage! Retain instructions for future reference.
Table Of Contents
General Safety . . . . . . . . . . . . . . . 1 - 3
Specifications . . . . . . . . . . . . . . . . . . .2
Operating the Nailer . . . . . . . . . . 3 - 5
Contact Trip Safety Mechanism . . . 4
Fasteners . . . . . . . . . . . . . . . . . . . . . . 6
Troubleshooting . . . . . . . . . . . . . . . . 6
Warranty . . . . . . . . . . . . . . . . . . . . . . 8
Description
This nailer is designed for decorative trim,
molding, window casings, furniture trim
and picture frame assembly. Features
include: convenient side loading
magazine which holds up to 100 nails, an
adjustable exhaust , a sequential trigger,
and a quick clear nose.
General Safety
Information
CALIFORNIA PROPOSITION 65
You can create dust when
you cut, sand, drill or grind
materials such as wood,
paint, metal, concrete, cement, or other
masonry. This dust often contains
chemicals known to cause cancer, birth
defects, or other reproductive harm.
Wear protective gear.
to vibration, working in awkward
positions and repetitive work motions can
cause injury to hands and arms. Stop using
any tool if discomfort, numbness, tingling
or pain occur and consult a physician.
Campbell Hausfeld Nailers meet or exceed Industries' Standards as set forth by the American National
Standard Institute/International Staple, Nail and Tool Association in ANSI/ISANTA SNT-101-2004.
© 2008 Campbell Hausfeld/Scott Fetzer
This manual contains safety,
operational and maintenance
information. Contact your Campbell
Hausfeld representative if you have any
questions.
OPERATOR'S RESPONSIBILITY:
The tool operator is responsible for:
●
Reading and understanding tool
labels and manual.
●
Selecting an appropriate tool
actuation system, taking into
consideration the work application
for which the tool is used.
●
The safe use of the tool.
●
Ensuring that the
tool is used only
when the operator
and all other
personnel in the
work area are wearing ANSI Z87 eye
protection equipment, and when
required, other appropriate
protection equipment such as head,
hearing and foot protection
equipment. Serious eye or
permanent hearing loss could result.
●
Assuring that the tool is kept in safe
working order as described in this
manual.
EMPLOYER'S RESPONSIBILITY:
●
Selecting an appropriate tool
actuation system, taking into
consideration the work application
Excessive
for which the tool is used.
exposure
●
Ensuring that this manual is
available to operators and
personnel performing maintenance.
●
The safe use of the tool.
REMINDER: Keep your dated proof of purchase for warranty purposes!
Attach it to this manual or file it for safekeeping.
For parts, product & service information
visit www.chpower.com
Model JB004250
Brad Nailer
Model JB004250
Locate model and serial number
on tool and record below:
Model No. ________________________
Serial No. _________________________
Retain these numbers for
future reference.
●
Enforcing that the
tool is used only
when the operator
and all other
personnel in the
work area are wearing ANSI Z87 eye
protection equipment, and when
required, other appropriate
protection equipment such as head,
hearing and foot protection
equipment. Serious eye or
permanent hearing loss could
result.
●
Assuring that the tool is kept in safe
working order as described in this
manual.
●
Assuring the proper maintenance of
all tools in employer's possession.
IN726800AV 7/08
