PRODUCT NO.
BASE MODEL NO.
FAS255J2A5
FAS255J2A
MARKET
USA
WIRING DIAGRAM - # 309343701
OWNER'S GUIDE - # 309000825
ELECTROLUX HOME PRODUCTS, INC
P.O.BOX 212378, AUGUSTA, GA 30917
FACTORY PARTS CATALOG
ROOM AIR CONDITIONER
VOLTS
BTU-COOLING
230
25000 BTU
Publication No.
5995367108
020227
-EN/SERVICE /BLT
©2002 Electrolux Home Products, Inc.
345
All rights reserved
ROOM AIR CONDITIONER
Model No.
FAS255J2A5
Advertisement
Table of Contents
Related Manuals for Frigidaire FAS255J2A5
Summary of Contents for Frigidaire FAS255J2A5
-
Page 1: Room Air Conditioner
PRODUCT NO. BASE MODEL NO. FAS255J2A5 FAS255J2A MARKET WIRING DIAGRAM - # 309343701 OWNER’S GUIDE - # 309000825 ELECTROLUX HOME PRODUCTS, INC P.O.BOX 212378, AUGUSTA, GA 30917 FACTORY PARTS CATALOG ROOM AIR CONDITIONER VOLTS BTU-COOLING 25000 BTU ROOM AIR CONDITIONER FAS255J2A5 Publication No. -
Page 2: Cabinet Front And Wrapper
Publication No. FAS255J2A5 5995367018 CABINET FRONT AND WRAPPER 02/02... - Page 3 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FAS255J2A5 CABINET FRONT AND WRAPPER PART NO DESCRIPTION 309632704 Cabinet,sleeve ,top louvers 5303212504 Seal,sleeve/chassis ,bottom 309632804 Grille,rear ,with rail 309631104 Link,vertical louver ,with handle 309630804 Louver,horizontal 309633305 Louver Assy,Incl-7,8,9 309631004...
- Page 4 Publication No. FAS255J2A5 5995367018 CONTROLS 02/02...
- Page 5 POS. NO 13 # 61 # 71 # 72 # 72*# # = Fast-moving Parts * = Non-Illustrated Parts FAS255J2A5 CONTROLS PART NO DESCRIPTION 309630403 Control Box 5303015427 Screw,truss head ,8-18AB x 0.47 309623602 Bulkhead,control system 309111201 Grommet,wire protector 5304413782...
-
Page 6: Air Handling Parts
Publication No. FAS255J2A5 5995367018 AIR HANDLING PARTS 02/02... - Page 7 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FAS255J2A5 AIR HANDLING PARTS PART NO DESCRIPTION 5304422465 Fan Blade,with clamp 3202975 Screw,10-16AB x 0.72 ,square drive 309623201 Shroud,cond fan motor 5303212504 Seal,sleeve/chassis ,bottom 5303015311 Seal,fan housing ,lower 5303015427 Screw,truss head ,8-18AB x 0.47...
-
Page 8: Compressor Parts
Publication No. FAS255J2A5 5995367018 COMPRESSOR PARTS 02/02... - Page 9 POS. NO 11 # 12 # 16 # 17 # # = Fast-moving Parts * = Non-Illustrated Parts FAS255J2A5 COMPRESSOR PARTS PART NO DESCRIPTION 309646901 Compressor,w/internal ovld 5303283877 Grommet,compressor mtg ,(3) 5308006948 Nut,compressor mtg ,(3) 309364305 Gasket,terminal cover 309364301 Cover,compr terminal...
- Page 10 Publication No. FAS255J2A5 5995367018 WINDOW MOUNTING PARTS 02/02...
- Page 11 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FAS255J2A5 WINDOW MOUNTING PARTS PART NO DESCRIPTION 5304407729 Seal,window stuffer 5303211056 Bracket,sash lock 5304419163 Frame,cab extension ,LH ,sliding 5304409250 Seal,top rail/cab 5304414933 Retainer,accordian 5304414105 Bracket,support ,RH 3001815 Bracket,sill/unit sprt. 3007756 Screw,1/4-20 x 0.750...
-
Page 12: Wiring Diagram
Publication No. FAS255J2A5 5995367018 WIRING DIAGRAM 02/02...
