Frigidaire FAS254M2A1 Factory Parts Catalog

Frigidaire fas254m2a1: supplementary guide
Hide thumbs
Table of Contents

Advertisement

Quick Links

PRODUCT NO.
BASE MODEL NO.
FAS254M2A1
FAS254M2A
MARKET
Frigidaire
WIRING DIAGRAM - # 309364201
OWNER'S GUIDE - # 309000848
ENERGY GUIDE - # 309369928
ELECTROLUX HOME PRODUCTS, INC
P.O.BOX 212378, AUGUSTA, GA 30917
FACTORY PARTS CATALOG

ROOM AIR CONDITIONER

SERIES
VOLTS
heavy duty
230
Publication No.
5995384178
030114
©2003 Electrolux Home Products, Inc.
-EN/SERVICE /KC
All rights reserved
345
BTU-COOLING
25000 BTU
ROOM AIR CONDITIONER
Model No.
FAS254M2A1

Advertisement

Table of Contents
loading

Related Manuals for Frigidaire FAS254M2A1

Summary of Contents for Frigidaire FAS254M2A1

  • Page 1: Room Air Conditioner

    PRODUCT NO. BASE MODEL NO. FAS254M2A1 FAS254M2A MARKET Frigidaire WIRING DIAGRAM - # 309364201 OWNER’S GUIDE - # 309000848 ENERGY GUIDE - # 309369928 ELECTROLUX HOME PRODUCTS, INC P.O.BOX 212378, AUGUSTA, GA 30917 FACTORY PARTS CATALOG ROOM AIR CONDITIONER SERIES...

  • Page 2: Cabinet Front And Wrapper

    Publication No. FAS254M2A1 5995384178 CABINET FRONT AND WRAPPER 01/03...
  • Page 3 309631404 Filter,air ,molded plastic 309633205 Front Assembly,w/7,8,9,12,43 309360105 Overlay,control 309321401 Door,vent ,with actuator 309330404 Handle,vent ,gray 309330202 Detent,vent 3015312 Screw,8-18AB x 0.500 309630904 Panel,cabinet front 309369701 Enclosure,control mount 309342607 Remote Control,transmitter ,with batteries 309369928 Energy Guide,FAS254M2A1 Publication No. 5995384178 01/03...
  • Page 4 Publication No. FAS254M2A1 5995384178 CONTROLS 01/03...
  • Page 5 POS. NO 13 # 17 # 61 # 71 # 72 # # = Fast-moving Parts * = Non-Illustrated Parts FAS254M2A1 CONTROLS PART NO DESCRIPTION 309630403 Control Box 5303015427 Screw,truss head ,8-18AB x 0.47 ,with nibs 309623602 Bulkhead,control system 309111201...

  • Page 6: Air Handling Parts

    Publication No. FAS254M2A1 5995384178 AIR HANDLING PARTS 01/03...
  • Page 7 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FAS254M2A1 AIR HANDLING PARTS PART NO DESCRIPTION 5304422465 Fan Blade,with clamp 3202975 Screw,10-16AB x 0.72 ,square drive 309623201 Shroud,cond fan motor 5303212504 Seal,sleeve/shroud ,23.72" x 1.25" ,bottom 5303015311 Seal,fan housing ,19.56" x 0.50" ,lower 5303015427 Screw,truss head ,8-18AB x 0.47 ,with nibs...

  • Page 8: Compressor Parts

    Publication No. FAS254M2A1 5995384178 COMPRESSOR PARTS 01/03...
  • Page 9 POS. NO 11 # 12 # 16 # 17 # # = Fast-moving Parts * = Non-Illustrated Parts FAS254M2A1 COMPRESSOR PARTS PART NO DESCRIPTION 309603118 Compressor,w/overload 5303283877 Grommet,compressor mtg ,(3) 5308006948 Nut,compressor mtg ,(3) 5304431275 Gasket,terminal cover 5304416126 Cover,elec terminal ,compressor...
  • Page 10 Publication No. FAS254M2A1 5995384178 WINDOW MOUNTING PARTS 01/03...
  • Page 11 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FAS254M2A1 WINDOW MOUNTING PARTS PART NO DESCRIPTION 5304407729 Seal,window stuffer 5303211056 Bracket,sash lock 5304426345 Extension,sliding frame ,LH ,w/closure panel 5304409250 Seal,top rail/cab 5304414933 Retainer,accordian mount 5304414105 Bracket,support ,RH 3001815 Bracket,sill/unit sprt.

  • Page 12: Wiring Diagram

    Publication No. FAS254M2A1 5995384178 WIRING DIAGRAM 01/03...
