PRODUCT NO.
FAS255J2A2
WIRING DIAGRAM - # 309343701
OWNER'S GUIDE - # 309000825
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O.BOX 212378, AUGUSTA, GA 30917
FACTORY PARTS CATALOG
BASE MODEL NO.
MARKET
FAS255J2A
USA
Publication No.
5995348751
010122
-EN/SERVICE /DJH
345
ROOM AIR CONDITIONER
BTU-COOLING
25000BTU
ROOM AIR CONDITIONER
©2001 White Consolidated Industries, Inc.
All rights reserved
Model No.
FAS255J2A2
Advertisement
Related Manuals for Frigidaire FAS255J2A2
Summary of Contents for Frigidaire FAS255J2A2
-
Page 1: Room Air Conditioner
PRODUCT NO. BASE MODEL NO. FAS255J2A2 FAS255J2A WIRING DIAGRAM - # 309343701 OWNER’S GUIDE - # 309000825 ELECTROLUX HOME PRODUCTS NORTH AMERICA P.O.BOX 212378, AUGUSTA, GA 30917 FACTORY PARTS CATALOG ROOM AIR CONDITIONER MARKET BTU-COOLING 25000BTU ROOM AIR CONDITIONER Publication No. -
Page 2: Cabinet Front And Wrapper
Publication No. FAS255J2A2 5995348751 CABINET FRONT AND WRAPPER 08/01... - Page 3 POS. NO 26A* # = Fast-moving Parts * = Non-Illustrated Parts FAS255J2A2 CABINET FRONT AND WRAPPER PART NO DESCRIPTION 309632704 Cabinet,sleeve ,top louvers 309632804 Grille,rear ,with rail 309631104 Link,vertical louver 309630804 Louver,horizontal 309633305 Louver Assy,horizontal 309631004 Louver 309631404 Filter-air,molded plastic...
- Page 4 Publication No. FAS255J2A2 5995348751 CONTROLS 08/01...
- Page 5 POS. NO 13 # 16 # 72 # # = Fast-moving Parts * = Non-Illustrated Parts FAS255J2A2 CONTROLS PART NO DESCRIPTION 309630403 Control Box 309331801 Clip-control bulb,(2) 309623601 Bulkhead,control system 5303316594 Capacitor,370 V ,7.5x35 mfd 5303303077 Strap-capacitor 5304408753 Harness-wiring 309343114 Service-cord,type’D’12AWG...
-
Page 6: Air Handling Parts
Publication No. FAS255J2A2 5995348751 AIR HANDLING PARTS 08/01... - Page 7 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FAS255J2A2 AIR HANDLING PARTS PART NO DESCRIPTION 5303321440 Fan blade & clamp 3202975 Screw,10-16 x 0.72 ,square drive 309623201 Shroud-condenser,one piece 5303015311 Seal,fan housing ,lower 5303015427 Screw,truss head ,8-18AB x 0.47...
-
Page 8: Compressor Parts
Publication No. FAS255J2A2 5995348751 COMPRESSOR PARTS 08/01... - Page 9 POS. NO 11 # 12 # # = Fast-moving Parts * = Non-Illustrated Parts FAS255J2A2 COMPRESSOR PARTS PART NO DESCRIPTION 5304408299 Compressor 5303286606 Grommet,compressor mtg ,(3) 5308006948 Nut,compressor mtg ,(3) 5303002069 Wire-Bale,terminal cover 5303002068 Gasket,terminal cover 5303002067 Cover,compr terminal 309634201...
- Page 10 Publication No. FAS255J2A2 5995348751 WINDOW MOUNTING PARTS 08/01...
- Page 11 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FAS255J2A2 WINDOW MOUNTING PARTS PART NO DESCRIPTION 5304407729 Seal-window frame,stuffer 5304414928 Frame,LH 309313303 Kit-window mounting,heavy duty 5304409250 Seal-top rail 5304414933 Retainer,accordian 5304414105 Bracket-support,RH 309313204 Kit-mounting support 5304409248 Hardware-mounting 5304414106 Bracket-support,LH 3015312 Screw,8-18AB x 0.500...
- Page 12 Publication No. FAS255J2A2 5995348751 WIRING DIAGRAM # = Fast-moving Parts 08/01 * = Non-Illustrated Parts...
