2018 FORD FOCUS RS
Owner's Manual Supplement

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FOCUS RS 2018 and is the answer not in the manual?

Questions and answers

Related Manuals for Ford FOCUS RS 2018

Summary of Contents for Ford FOCUS RS 2018

  • Page 1 2018 FORD FOCUS RS Owner's Manual Supplement...
  • Page 3 No part of this publication may be reproduced, transmitted, stored in a retrieval system or translated into any language in any form by any means without our written permission. Errors and omissions excepted. © Ford Motor Company 2017 All rights reserved. Part Number: JM5J 19A285 LAA 201706 20170710101557...

  • Page 5: Table Of Contents

    Table of Contents Introduction Towing About This Supplement.........3 Towing a Trailer..........22 SVT.................3 Driving Hints Team RS...............3 Ford Performance..........4 Driving Through Water........23 Engine Overspeed..........23 At a Glance Engine Overboost...........23 Unique Features..........5 Roadside Emergencies Instrument Cluster Transporting the Vehicle......24 Gauges..............7 Fuses Warning Lamps and Indicators....7 Fuse Specification Chart......25...
  • Page 6 Table of Contents Suspension Specifications......40 Motorcraft Parts..........41 Transmission Code Designation....41 Capacities and Specifications....41 Scheduled Maintenance General Maintenance Information..44 2018 Focus RS (CEW) RS, Canada/United States of America, JM5J 19A285 LAA enUSA, Edition date: 201706, First Printing...

  • Page 7: Introduction

    Thank you for choosing Ford Performance. to you on your vehicle. If you have owned or leased a Ford Performance vehicle before, welcome back. If this is your first Ford Performance vehicle, welcome to the family. We are...

  • Page 8: Ford Performance

    Performance and racing are deeply aerodynamics, lightweighting, electronics, embedded in Ford s DNA, dating back to powertrain performance, fuel efficiency October 10, 1901 when Henry Ford won his and other technologies that can be applied first race against Alexander Winton, across Ford s product portfolio.

  • Page 9: At A Glance

    At a Glance UNIQUE FEATURES E215060 • High-flow, dual-mode exhaust system. Powertrain • Enhanced torque vectoring control. • 2.3L EcoBoost engine. • All-wheel drive. • High-capacity intercooler. • Limited-slip differential. 2018 Focus RS (CEW) RS, Canada/United States of America, JM5J 19A285 LAA enUSA, Edition date: 201706, First Printing...
  • Page 10 At a Glance Chassis • Brembo front brake calipers. • Launch control. • Drive modes. • Dual-mode dampers. Exterior • Radiator grille. • Underbody shield. • Diffuser. • Spoiler. • Light-weight aluminum or forged aluminum wheels. • Michelin Pilot Super Sport or Michelin Pilot Sport Cup 2 tires.

  • Page 11: Instrument Cluster

    Instrument Cluster GAUGES WARNING LAMPS AND INDICATORS Performance Shift Indicator It illuminates when the powertrain reaches the optimum upshift point. It flashes when the E218767 engine is close to hitting the engine speed limiter. E215771 Oil temperature gauge. Turbocharger boost gauge. Oil pressure gauge.

  • Page 12: Information Displays

    Information Displays possible acceleration when launching from GENERAL INFORMATION a standing start. Launch Control Note: When you switch the feature on, it is only active once. You must switch the The system configures the chassis and feature on each time it is required. powertrain systems to deliver the fastest To switch the feature on, do the following: Note: Your vehicle must be completely stationary.
  • Page 13 Information Displays All-Wheel Drive Message Action and Description AWD OFF Displays when the system has been automatically disabled to protect itself. This is caused by operating the vehicle with a severely mismatched tire installed, if the system is over- heating or if there is an issue with another vehicle system preventing AWD operation.

  • Page 14: Seats

    Seats MANUAL SEATS Repeatedly push the lever down to lower the seat. WARNING Rotate the handle or move the Make sure the seat fully locks into lever to recline the seatback. place by rocking it backward and forward. E215587 Lift the handle to move the seat backward and forward.

  • Page 15: Fuel And Refueling

    Fuel and Refueling • Fuels containing the octane booster FUEL QUALITY additive, methylcyclopentadienyl manganese tricarbonyl (MMT). Choosing the Right Fuel • Leaded fuel (using leaded fuel is prohibited by law). The use of fuels with metallic compounds such as methylcyclopentadienyl manganese tricarbonyl (commonly known as MMT), which is a manganese-based fuel additive, will impair engine...

  • Page 16: Transmission

    Transmission MANUAL TRANSMISSION Manual transmission vehicles have a starter interlock that prevents cranking the engine unless you fully press the clutch pedal. Due to the high performance of the powertrain, a certain amount of noise from the transmission is normal. Note: During each shift, you must fully press the clutch pedal to the floor and fully release the accelerator.

  • Page 17: All-Wheel Drive

    All-Wheel Drive Using Mismatched Tires or Wheels USING ALL-WHEEL DRIVE WARNINGS Your vehicle has All-Wheel Drive with Only use replacement tires and Dynamic Torque Vectoring. This feature wheels that are of the same size, uses all four wheels to power the vehicle load index, speed rating and type as and independently controls the torque to those originally fitted to your vehicle.
  • Page 18 All-Wheel Drive Major mismatched tire or wheel sizes sharply. It may be better to strike small between the front and rear axles, for objects, for example highway reflectors, example 18 inch low profile tires on the with minor damage to your vehicle rather front axle and 20 inch high profile tires on than attempt a sudden return to the road the rear axle could cause the system to...
  • Page 19 All-Wheel Drive Note: Do not rock the vehicle if the engine has adequately cooled and the engine has is not at normal operating temperature or been restarted, the message turns off and damage to the transmission may occur. normal all-wheel drive function returns. If you do not switch the engine off, the Note: Do not rock the vehicle for more than message only turns off, when the system...
  • Page 20 All-Wheel Drive Hilly or Sloping Terrain Snow and Ice WARNING WARNING Avoid driving across or turning on If you are driving in slippery steep hilly or sloping terrain. Your conditions that require tire chains or vehicle may lose traction and slip cables, then it is critical that you drive sideways increasing the risk of rolling over.
  • Page 21 All-Wheel Drive Avoid sudden braking while driving on snow or icy roads. Although your vehicle may accelerate better than a two-wheel drive vehicle on snow and ice, stopping distances are not reduced. Make sure you allow sufficient distance for stopping. Drive slower than usual and consider using a lower gear.

  • Page 22: Brakes

    Brakes GENERAL INFORMATION Your vehicle has a braking system designed for high performance driving and superior brake fade resistance. You may notice occasional brake noise and elevated levels of brake dust. This is normal and does not affect system performance. 2018 Focus RS (CEW) RS, Canada/United States of America, JM5J 19A285 LAA enUSA, Edition date: 201706, First Printing...

  • Page 23: Stability Control

    Stability Control Switching the System Off USING STABILITY CONTROL Press and hold the switch for WARNINGS approximately five seconds. You will see Do not switch off stability control or a message in conjunction with an use Sport, Track or Drift mode when illuminated icon in the display.

  • Page 24: Driving Aids

    Driving Aids Sport DRIVE CONTROL Vehicle settings tuned for WARNING performance street driving. Do not use Sport, Track or Drift mode Electronic stability control and traction when using a temporary spare wheel control systems fully enabled. or after inflating a tire using the temporary mobility kit.
  • Page 25 Driving Aids The electronic stability control or all-wheel Press and hold the button for a short drive system may automatically turn off period of time. The current setting during extreme drifting maneuvers. If a appears in the information display. system turns off, the electronic stability Release the button again to change the control warning lamp illuminates or a setting.

  • Page 26: Towing

    Towing TOWING A TRAILER WARNING Your vehicle is not approved for trailer towing. Never tow a trailer with your vehicle. 2018 Focus RS (CEW) RS, Canada/United States of America, JM5J 19A285 LAA enUSA, Edition date: 201706, First Printing...

  • Page 27: Driving Hints

    Driving Hints DRIVING THROUGH WATER ENGINE OVERBOOST Your vehicle has aerodynamic devices Your vehicle has an engine overboost attached to the underbody designed to feature to allow additional torque delivery. help control airflow for superior The overboost feature controls a variety performance.

  • Page 28: Roadside Emergencies

    Roadside Emergencies TRANSPORTING THE VEHICLE If your vehicle has to be towed, we recommend that you contact a professional towing service. If you are a member of a roadside assistance program, we recommend that you contact your roadside assistance service provider. We recommend the use of flatbed equipment to transport your vehicle.

  • Page 29: Fuses

    Fuses FUSE SPECIFICATION CHART Engine Compartment Fuse Box E129925 Fuse Location Fuse Rating Protected Component 30 A Rear drive unit control. 20 A Fuel pump electronic module 2 feed. 7.5 A Exhaust valve. Relay Number Protected Component Fuel pump electronic module 2 feed. Cooling fan control 4.
  • Page 30 Fuses Luggage Compartment Fuse Box E129927 Fuse Location Fuse Rating Protected Component Fuel control relay. 15 A Damper control relay. 10 A Not used (spare). Relay Number Protected Component Fuel control module. Damper control module. 2018 Focus RS (CEW) RS, Canada/United States of America, JM5J 19A285 LAA enUSA, Edition date: 201706, First Printing...

  • Page 31: Maintenance

    Maintenance UNDER HOOD OVERVIEW E213537 Engine coolant reservoir. Engine oil dipstick. See Engine Oil Dipstick (page 28). Engine oil filler cap. Brake fluid reservoir. Battery. Engine compartment fuse box. See Fuses (page 25). Air filter. See Changing the Engine Air Filter (page 28). Washer system fluid reservoir.

  • Page 32: Engine Oil Dipstick

    Maintenance ENGINE OIL DIPSTICK E169062 Minimum. Maximum. CHANGING THE ENGINE AIR FILTER WARNING To reduce the risk of vehicle damage and personal burn injuries, do not start your engine with the air cleaner removed and do not remove it while the engine is running.

  • Page 33: Drive Belt Routing

    Maintenance 4. Wipe any dirt or debris from the air filter housing and cover to make sure no dirt gets in the engine and that you have a good seal. 5. Install a new air filter element. Note: Make sure you align the locating tab on the air filter element with the fork in the air filter housing.

  • Page 34: Track Use

    Track Use Before Track Use We recommend that you only operate your vehicle at high speeds at locations Before operating your vehicle on a track, designed to do so safely. Your vehicle has check the following: electronic controls that may reduce power or limit engine speed to help reduce •...

  • Page 35: Vehicle Care

    Vehicle Care CLEANING THE EXTERIOR Your vehicle has heat exchangers integrated with the front fascia designed to maximize performance. Do not apply a high-pressure washer directly to the heat exchangers as damage to the cooling fins could occur. Cleaning Vehicle Wrap (If Equipped) Do not wash your vehicle for the first six weeks after the application of the wrap.

  • Page 36: Wheels And Tires

    Wheels and Tires To avoid damaging the wheels: WHEELS • Maintain correct tire pressures. See Your vehicle has unique wheels. They can Tire Pressures (page 35). be more susceptible to damage from poor • When installing wheels, always use a road conditions due to their diameter, torque wrench and tighten the lug nuts width and the use of low profile tires.

  • Page 37: Tires

    Wheels and Tires • Take extra caution when operating on TIRES rough roads to avoid impacts that could cause tire damage. The tires on your vehicle are designed to optimize its performance. They are not • Inspect the tires for damage on a optimized for off-road or winter regular basis.

  • Page 38: Using Summer Tires

    Wheels and Tires Note: Always inspect the tires after storage USING SUMMER TIRES periods and before use. The original equipment tires on your vehicle are designed to optimize its performance USING WINTER TIRES in dry or wet summer road conditions. The rubber compounds used in these tires lose The original equipment tires on your vehicle flexibility and may develop surface cracks...

  • Page 39: Tire Pressures

    Wheels and Tires TIRE PRESSURES Check all tire pressures when they are cold, at least once every two weeks. Check them after the vehicle has been parked for at least three hours. Tire pressure can diminish over time and fluctuate with temperature.

  • Page 40: Capacities And Specifications

    Capacities and Specifications ENGINE SPECIFICATIONS Dimension Description Specification Engine capacity. 138.0 in³ (2,261.4 cm³) Engine bore. 3.4 in (87.5 mm) Engine stroke. 3.7 in (94 mm) Compression ratio. 9.4:1 Ignition firing order. 1-3-4-2 Ignition system. Coil on spark plug Spark plug gap. 0.030 in (0.75 mm) Maximum net power kW/RPM.

  • Page 41: Transmission Specifications

    Capacities and Specifications TRANSMISSION SPECIFICATIONS Transmission and final drive ratios 6-Speed Manual Transmission - MMT6 Gear Gear Ratio Final Drive Ratio 1st gear. 3.23 4.063 2nd gear. 1.95 4.063 3rd gear. 1.32 4.063 4th gear. 1.03 4.063 5th gear. 1.13 2.955 6th gear.

  • Page 42: Brake System Specifications

    Capacities and Specifications BRAKE SYSTEM SPECIFICATIONS Dimension Description in (mm) Brake pedal free travel. 0.4–1.2 (10–30) Front brake disc minimum thickness. 0.9 (23) Rear brake disc minimum thickness. 0.4 (9) 2018 Focus RS (CEW) RS, Canada/United States of America, JM5J 19A285 LAA enUSA, Edition date: 201706, First Printing...

  • Page 43: Steering Specifications

    Capacities and Specifications STEERING SPECIFICATIONS Wheel Alignment Dimension Description Specification Front wheel - Total Toe. 0.20° ±0.20° Rear wheel - Total Toe. 0.30° ±0.20° Turning Circle Dimension Description Specification Minimum turning circle. 39.4 ft (12 m) 2018 Focus RS (CEW) RS, Canada/United States of America, JM5J 19A285 LAA enUSA, Edition date: 201706, First Printing...

  • Page 44: Suspension Specifications

    Capacities and Specifications SUSPENSION SPECIFICATIONS Dimension Description Specification Front camber. -1.51° (±1.25°) Front caster. 4.79° (±1°) Rear camber. -0.97° (±1.25°) Front suspension. Macpherson strut. Rear suspension. Multilink. Front spring rate. 40 N/mm Rear spring rate. 44 N/mm Front stabilizer bar. 24.2 mm Rear stabilizer bar.

  • Page 45: Motorcraft Parts

    SAE/USCAR-36. We recommend that you contact an authorized dealer for spark plug replacement. We recommend that you demand the use TRANSMISSION CODE of genuine Ford and Motorcraft parts DESIGNATION whenever your vehicle requires scheduled maintenance or repair. Genuine Ford and...
  • Page 46 22.05 oz (0.625 kg) Air conditioning refrigerant compressor oil fill capacity. 4.40 fl oz (130 ml) Specifications Adding Engine Oil Only use fluid that meets Ford specifications. Quantity 0.9 qt (0.85 L) The quantity of engine oil required to raise the indicated level on the dipstick from minimum to maximum.
  • Page 47 Capacities and Specifications Name Specification PM-20 (U.S. & Canada) Motorcraft® Dual Clutch Transmission Fluid (U.S.) WSS-M2C200-D2 Huile pour boîtes embrayage double Motorcraft® (Canada) XT-11-QDC (U.S. & Canada) Motorcraft® SAE 75W-140 Synthetic Rear Axle Lubricant (U.S.) WSL-M2C192-A Lubrifiant synthétique pour pont arrière SAE 75W-140 Motorcraft® (Canada) XY-75W140-QL (U.S.) CXY-75W140-1L (Canada)

  • Page 48: Scheduled Maintenance

    Scheduled Maintenance GENERAL MAINTENANCE INFORMATION Protecting Your Investment Your vehicle is equipped with an intelligent oil life monitoring system. Under normal operating conditions, a message appears in the information display to indicate the regular oil change interval. High performance vehicles tend to be driven in such a way that the engine experiences high speed and high load.
  • Page 49 Index About This Supplement.........3 Ford Performance..........4 Fuel and Refueling...........11 Fuel Quality............11 See: Brakes..............18 Air Filter Choosing the Right Fuel........11 Fuses..............25 See: Changing the Engine Air Filter....28 All-Wheel Drive..........13 Fuse Specification Chart......25 At a Glance............5 Engine Compartment Fuse Box......25 Luggage Compartment Fuse Box....26 See: All-Wheel Drive..........13...
  • Page 50 Index Scheduled Maintenance......44 Vehicle Care............31 Seats..............10 Stability Control..........19 Steering Specifications........39 Suspension Specifications......40 Warning Lamps and Indicators....7 SVT.................3 Performance Shift Indicator........7 Washers See: Cleaning the Exterior........31 Wheels and Tires..........32 Team RS...............3 Wheels..............32 Technical Specifications Winter Tires See: Capacities and Specifications....36 See: Using Winter Tires........34 Tire Pressures..........35 Tires..............33 Tires...
