Page 1 2019 RANGER Owner’s Manual owner.ford.com ford.ca October 2018 First Printing Litho in U.S.A. KB3J 19A321 AA...
Page 2 No part of this publication may be reproduced, transmitted, stored in a retrieval system or translated into any language in any form by any means without our written permission. Errors and omissions excepted. © Ford Motor Company 2018 All rights reserved. Part Number: 201809 20180919152353...
Page 4: Table Of Contents
Table of Contents Introduction Supplementary Restraints System About This Manual ..........7 Principle of Operation .........39 Symbols Glossary ..........7 Driver and Passenger Airbags ....40 Data Recording ..........9 Front Passenger Sensing System ....41 Perchlorate ............11 Side Airbags ............43 Replacement Parts Recommendation ................11 Safety Canopy ...........44 Special Notices ..........12...
Page 5 Table of Contents Horn ..............65 Hints on Controlling the Interior Climate ................110 Heated Windshield ........113 Wipers and Washers Heated Rear Window ........113 Windshield Wipers ........66 Heated Exterior Mirrors .......113 Autowipers ............66 Cabin Air Filter ..........113 Windshield Washers ........67 Remote Start ..........114 Lighting Seats General Information ........68...
Page 6 Table of Contents Fuel and Refueling Trail Control Safety Precautions ........136 About Trail Control ........168 Fuel Quality ............136 Switching Trail Control On and Off ..168 Fuel Filler Funnel Location .......137 Setting the Trail Control Speed .....168 Running Out of Fuel ........137 Cancelling the Set Speed ......168 Refueling ............139 Trail Control Indicator ........168...
Page 7 Table of Contents Towing the Vehicle on Four Wheels ..211 Opening and Closing the Hood .....245 Under Hood Overview ......246 Driving Hints Engine Oil Dipstick ........247 Breaking-In .............213 Engine Oil Check .........247 Economical Driving ........213 Oil Change Indicator Reset .....248 Cold Weather Precautions .......214 Engine Coolant Check ......249 Off-Road Driving ..........214...
Page 8 Accessories Bulb Specification Chart ......310 Accessories ............417 Audio System Ford Protect General Information ........312 Ford Protect ..........419 Audio Unit - Vehicles Without: SYNC .................312 Scheduled Maintenance Audio Unit - Vehicles With: SYNC ..314 General Maintenance Information ..421 Audio Unit - Vehicles With: SYNC 3 ..316 Normal Scheduled Maintenance ..424...
Page 9 Ranger (TFG) Canada/United States of America, enUSA, Edition date: 201809, First-Printing...
Page 10: Introduction
Introduction ABOUT THIS MANUAL Thank you for choosing Ford. We recommend that you take some time to get to know your vehicle by reading this manual. The more that you know about your vehicle, the greater the safety and pleasure you will get from driving it.
Page 11 Introduction Brake system Flammable E231160 E270480 Cabin air filter Front airbag E67017 Front fog lamps Check fuel cap Fuel pump reset Child safety door lock or unlock Fuse compartment Child seat lower anchor Hazard flashers Child seat tether anchor Heated rear window Cruise control E71340 Windshield defrosting system...
Page 12: Data Recording
In order to properly diagnose and service your vehicle, Ford Motor Company See Service Manual (Ford of Canada in Canada), and service E231158 and repair facilities may access or share among them vehicle diagnostic...
Page 13 For Canada which crashes and injuries occur. only, for more information, please review the Ford of Canada privacy policy at Note: Event data recorder data is www.ford.ca, including our U.S. data recorded by your vehicle only if a storage and use of service providers in non-trivial crash situation occurs;...
Page 14: Perchlorate
Introduction the information if they have access to Ford or its vendors to receive this the vehicle or the event data recorder. information, do not activate the Ford Motor Company and Ford of service. For more information, see Canada do not access event data...
Page 15: Special Notices
ACTIVE AIRBAG in front of it, of protection is to use genuine Ford DEATH or SERIOUS INJURY to the CHILD replacement collision parts.
Page 16: Mobile Communications Equipment
Do not use this vehicle as an primary responsibility is the safe ambulance. operation of your vehicle. We Your vehicle does not have the Ford recommend against the use of any Ambulance Preparation Package. hand-held device while driving and encourage the use of voice-operated Using a Slide-In Camper systems when possible.
Page 17: Mobile Communications Equipment
Introduction Using mobile communications equipment is becoming increasingly important in the conduct of business and personal affairs. However, you must not compromise your own or others’ safety when using such equipment. Mobile communications can enhance personal safety and security when appropriately used, particularly in emergency situations.
Page 18: Environment
You should play your part in protecting the environment. Correct vehicle usage and the authorized disposal of waste, cleaning and lubrication materials are significant steps toward this aim. For details about Ford Motor Company's sustainability progress and initiatives visit: Web Address www.sustainability.ford.com...
Page 19: At A Glance
At a Glance INSTRUMENT PANEL OVERVIEW E266455 Direction indicators. See Air vents. Direction Indicators (page 72). Multi-function display. See Lighting control. See Lighting General Information (page Control (page 68). 87). Hood release lever. See Windshield wipers. See Wipers Opening and Closing the and Washers (page 66).
Page 20: Child Safety
Child Safety GENERAL INFORMATION (CPST) to make sure that you properly install the child restraint in your vehicle See the following sections for directions and that you consult your pediatrician to on how to properly use safety restraints make sure you have a child restraint for children.
Page 21: Installing Child Restraints
Child Safety Recommendations for Safety Restraints for Children Child Child size, height, weight, or age Recommended restraint type Use a child safety seat Infants or Children weighing 40 lb (18 kg) or less (sometimes called an toddlers (generally age four or younger). infant carrier, convertible seat, or toddler seat).
Page 22 Child Safety Use a child restraint (sometimes called an • Keep the buckle release button infant carrier, convertible seat, or toddler pointing up and away from the child seat) for infants, toddlers, or children restraint, with the tongue between the weighing 40 lb (18 kg) or less (generally child restraint and the release button, age four or younger).
Page 23 Child Safety E142529 E142531 2. Pull down on the shoulder belt and 4. Insert the belt tongue into the proper then grasp the shoulder belt and lap buckle (the buckle closest to the belt together. direction the tongue is coming from) for that seating position until you hear a snap and feel the latch engage.
Page 24 Child Safety Try to pull the seatbelt out of the retractor to make sure the retractor is in the automatic locking mode (you should not be able to pull more belt out). If the retractor is not locked, unbuckle the belt and repeat Steps 5 and 6.
Page 25 Child Safety SuperCrew WARNING: Depending on where you secure a child restraint, and depending on the child restraint design, you may block access to certain seatbelt buckle assemblies and LATCH lower anchors, rendering those features potentially unusable. To avoid risk of injury, make sure occupants only use seating positions where they are able to be properly restrained.
Page 26 Child Safety used at this seating position provided that the child restraint manufacturer's instructions permit use with the anchor spacing stated. Do not attach a child restraint to any lower anchor if an adjacent child restraint is attached to that anchor. Each time you use the child restraint, check that the seat is properly attached to the lower anchors and tether anchor, if...
Page 27 Child Safety For SuperCrew vehicles, the tether anchors are anchor brackets behind the seat on the rear edge of the seat cushion. For SuperCab vehicles, the tether anchors in your vehicle are loops of webbing above the seat backrest. The rear seat in the SuperCab has two straps along the top of the seat backrest E277518 that function as both routing loops for the...
Page 28 Child Safety Route the child restraint tether strap There are two loops of webbing just above over the back of the seat and under the the back of the rear seat (along the bottom head restraint. edge of the rear window). Use these loops as both routing loops and anchor loops for Note: For vehicles with adjustable head up to two child restraint tether straps.
Page 29: Booster Seats
Child Safety If your child restraint system has a tether strap, and the child restraint manufacturer recommends its use, we also recommend its use. BOOSTER SEATS WARNING: Do not put the shoulder section of the seatbelt or allow the child to put the shoulder section of E142595 the seatbelt under their arm or behind their back.
Page 30 Child Safety If your backless booster seat has a • High back booster seats removable shield, remove the shield. If a If, with a backless booster seat, you cannot vehicle seating position has a low seat find a seating position that adequately backrest or no head restraint, a backless supports your child's head, a high back booster seat may place your child's head...
Page 31: Child Restraint Positioning
Child Safety E142597 If the booster seat slides on the vehicle seat upon which it is being used, placing a WARNING: Always carefully rubberized mesh sold as shelf or carpet follow the instructions and warnings liner under the booster seat may improve provided by the manufacturer of any this condition.
Page 32 Child Safety WARNING: Properly secure child WARNING: Do not put the restraints or booster seats when they are shoulder section of the seatbelt or allow not in use. They could become projectiles the child to put the shoulder section of in a sudden stop or crash.
Page 33: Child Safety Locks
Child Safety Note: The child restraint must rest tightly against the vehicle seat upon which it is installed. It may be necessary to lift or remove the head restraint. See Seats (page 115). CHILD SAFETY LOCKS EQUIPPED) When these locks are set, the rear doors cannot be opened from the inside.
Page 34: Seatbelts
Seatbelts PRINCIPLE OF OPERATION WARNING: Each seating position in your vehicle has a specific seatbelt assembly made up of one buckle and WARNING: Always drive and ride one tongue designed to be used as a pair. with your seatback upright and the lap Use the shoulder belt on the outside belt snug and low across the hips.
Page 35: Fastening The Seatbelts
Seatbelts The seatbelt system consists of: • Lap and shoulder seatbelts. • Shoulder seatbelt with automatic locking mode, (except driver seatbelt). • Height adjuster at the front outermost seating positions (if equipped). • Seatbelt pretensioner at the front outermost and rear outermost seating positions.
Page 36 Seatbelts Using Seatbelts During Pregnancy All safety restraints in the vehicle are combination lap and shoulder belts. The driver seatbelt has the first type of locking mode, and the front outboard passenger WARNING: Always ride and drive and rear seat seatbelts have both types of with your seatback upright and properly locking modes described as follows: fasten your seatbelt.
Page 37: Seatbelt Height Adjustment
Seatbelts How to Use the Automatic Locking Mode E142591 Buckle the combination lap and E131388 shoulder belt. To adjust the shoulder belt height: 2. Grasp the shoulder portion and pull downward until you pull the entire belt 1. Pull the locking button and slide the out.
Page 38: Seatbelt Reminder
Seatbelts Conditions of operation Then The driver seatbelt is not buckled before The seatbelt warning lamp illuminates and the ignition switch is turned to the on posi- the indicator chime sounds for a few tion... seconds. The driver seatbelt is buckled while the The seatbelt warning lamp and indicator warning lamp is illuminated and the indic- chime turn off.
Page 39 Seatbelts Seatbelt Status Note: The driver and front passenger warnings switch on and off independently. When you perform this procedure for one seating position, do not buckle the other position as this terminates the process. Read Steps 1 - 4 before starting the procedure.
Page 40: Child Restraint And Seatbelt Maintenance
Seatbelts CHILD RESTRAINT AND SEATBELT MAINTENANCE WARNING: Only use extensions provided free of charge by Ford Motor Inspect the vehicle seatbelts and child Company dealers. The dealer will provide safety seat systems periodically to make an extension designed specifically for...
Page 41: Personal Safety System
Personal Safety System The Personal Safety System provides an improved overall level of frontal crash protection to front seat occupants and is designed to help further reduce the risk of airbag-related injuries. The system is able to analyze different occupant conditions and crash severity before activating the appropriate safety devices to help better protect a range of occupants in a variety...
Page 42: Supplementary Restraints System
Supplementary Restraints System PRINCIPLE OF OPERATION WARNING: Several airbag system components get hot after inflation. To avoid risk of injury, do not touch them WARNING: Airbags do not inflate after inflation. slowly or gently, and the risk of injury from a deploying airbag is the greatest WARNING: If the airbag has close to the trim covering the airbag deployed, the airbag will not function...
Page 43: Driver And Passenger Airbags
Supplementary Restraints System properly restrained or are otherwise out of position at the time of airbag deployment. Thus, it is extremely important that occupants be properly restrained as far away from the airbag module as possible while maintaining vehicle control. Routine maintenance of the airbags is not required.
Page 44: Front Passenger Sensing System
Supplementary Restraints System After all occupants have adjusted their FRONT PASSENGER SENSING seats and put on seatbelts, it is very SYSTEM important that they continue to sit properly. Properly seated occupants sit upright, lean against the seat back, and center themselves on the seat cushion, WARNING: Even with advanced with their feet comfortably extended on restraints systems, properly restrain...
Page 45 Supplementary Restraints System Note: When you first switch the ignition on, • When the front passenger sensing the passenger airbag status indicator off system enables the front passenger and on lamps illuminate for a short period frontal airbag (may inflate), the to confirm they are functional.
Page 46: Side Airbags
Supplementary Restraints System • Objects hanging off the seat backrest. • Wait at least two minutes and verify that the airbag readiness light in the • Objects stowed in the seat backrest instrument cluster is no longer map pocket. illuminated. •...
Page 47: Safety Canopy
Supplementary Restraints System Crash sensors and monitoring system with readiness indicator. WARNING: Do not attempt to See Crash Sensors and Airbag E67017 service, repair, or modify the Indicator (page 45). supplementary restraint system or associated components. Failure to The design and development of the side follow this instruction could result in airbag system included recommended personal injury or death.
Page 48: Crash Sensors And Airbag Indicator
Supplementary Restraints System The system consists of the following: • Safety Canopy curtain airbags above WARNING: To reduce risk of injury, the trim panels over the front and rear do not obstruct or place objects in the side windows identified by a label or deployment path of the airbag.
Page 49: Airbag Disposal
Supplementary Restraints System Your vehicle has a collection of crash and The fact that the seatbelt pretensioners occupant sensors which provide or front airbags did not activate for all information to the restraints control occupants in a crash does not mean that module.
Page 50: Keys And Remote Controls
Keys and Remote Controls Note: Make sure to lock your vehicle before GENERAL INFORMATION ON leaving it unattended. RADIO FREQUENCIES Note: If you are in range, the remote control still operates if you press any button This device complies with Part 15 of the unintentionally.
Page 51 Keys and Remote Controls E277016 Press the button to release the key blade. Press and hold the button to fold the key blade back in when not in use. E279948 The remote control operates the power locks. The remote control must be in your vehicle to use the push button start.
Page 52 Keys and Remote Controls A message appears in the information display when the remote control battery is low. See General Information (page 87). Integrated Keyhead Transmitter The remote control uses one coin-type three-volt lithium battery. Press the button to release the key blade before beginning the procedure.
Page 53 Keys and Remote Controls E151800 Note: Do not touch the battery contacts or the printed circuit board with the screwdriver. 4. Insert a screwdriver as shown to release the battery. E279949 Push the release button and pull the key blade out. E151801 5.
Page 54 Keys and Remote Controls E218402 3. Insert a suitable tool, for example a screwdriver, in the position shown and carefully remove the battery. 4. Install a new battery with the + facing upward. E218401 5. Reinstall the battery housing cover 2.
Page 55 Keys and Remote Controls Remote Start (If Equipped) Status Solid green Remote start WARNING: To avoid exhaust successful fumes, do not use remote start if your vehicle is parked indoors or in areas that Solid red Remote stop are not well ventilated. successful Blinking red Request failed or...
Page 56: Replacing A Lost Key Or Remote Control
Keys and Remote Controls The parking lamps remain on and your PASSIVE KEY BACKUP vehicle will run for 5, 10 or 15 minutes, POSITION depending on the setting. Extending the Engine Running Time To extend the engine running time duration of your vehicle during remote start, repeat steps 1 and 2 while the engine is running.
Page 57: Mykey
MyKey Standard Settings PRINCIPLE OF OPERATION Not every vehicle includes the features MyKey allows you to program keys with listed below. If your vehicle has this restricted driving modes to promote good equipment, then you cannot change the driving habits. You can program the following settings when using a MyKey: restrictions to all keys except one.
Page 58: Creating A Mykey
MyKey Note: Not every feature applies to every • Various vehicle speed reminders so vehicle in every market. When they are MyKey drivers know when their vehicle available for your vehicle, then they appear speed approaches the limits. Warnings in your information display, providing appear in your information display and choices to switch them on or off, or to select a tone sounds when the MyKey drivers...
Page 59: Clearing All Mykeys
MyKey 4. When prompted, hold the OK button 2. Access the main menu in the until you see a message informing you information display and then scroll to label this key as a MyKey. The through the menus to begin clearing programmed restrictions apply when your MyKey programming.
Page 60: Using Mykey With Remote Start Systems
If you choose to install a remote if an additional MyKey has been start system, see an authorized dealer for programmed. a Ford-approved remote start system. MYKEY – TROUBLESHOOTING Condition Potential Causes I cannot create a MyKey.
Page 61 MyKey Condition Potential Causes The key system has been reset. No MyKey functions with the trans- An admin transmitter is present at vehicle start. mitter. There are no MyKeys programmed to your vehicle. See Creating a MyKey (page 55). Ranger (TFG) Canada/United States of America, enUSA, Edition date: 201809, First-Printing...
Page 62: Doors And Locks
Doors and Locks With the ignition off, press and hold both LOCKING AND UNLOCKING the lock and unlock buttons on the remote control for three seconds to change You can use the power door lock control between driver door or all door unlock or the remote control to lock and unlock mode.
Page 63 Doors and Locks You can still lock your vehicle with the key in the ignition by either: • Using the keyless entry keypad with the driver door closed. • Pressing the lock button on the transmitter even if the doors are not closed.
Page 64 Doors and Locks Enabling or Disabling Autounlock To enable or disable autounlock, see an authorized dealer. Ranger (TFG) Canada/United States of America, enUSA, Edition date: 201809, First-Printing...
Page 65: Security
Security PASSIVE ANTI-THEFT ANTI-THEFT ALARM SYSTEM Alarm System Principle of Operation Perimeter Alarm The system prevents someone from The perimeter alarm is a deterrent against starting the engine with an incorrectly unauthorized access to your vehicle coded key. through the doors, luggage compartment and the hood.
Page 66: Steering Wheel
Steering Wheel ADJUSTING THE STEERING WHEEL WARNING: Do not adjust the steering wheel when your vehicle is moving. Note: Make sure that you are sitting in the correct position. See Sitting in the Correct Position (page 115). E279962 3. Lock the steering column. AUDIO CONTROL Type One E279960...
Page 67: Voice Control
Steering Wheel Type Two Press to access the next media selection. E265044 Press to change the media source. E100027 Press to access the settings menu on the SYNC screen. E142607 Press to access the home screen. E272621 VOICE CONTROL E272251 The controls are on the steering wheel.
Page 68: Information Display Control
Steering Wheel Type Two Use the controls to adjust the information display. Navigate through the screen and press OK to select. See General Information (page 87). HORN E270945 E200996 See Using Adaptive Cruise Control (page 177). INFORMATION DISPLAY CONTROL E205893 E201420 Ranger (TFG) Canada/United States of America, enUSA, Edition date: 201809, First-Printing...
Page 69: Wipers And Washers
Wipers and Washers Intermittent Wipe WINDSHIELD WIPERS Push the lever up or down to operate the windshield wiper. E270969 E242320 Shortest wipe interval. Intermittent wipe. Longest wipe interval. Use the rotary control to adjust the intermittent wipe interval. E248785 Speed Dependent Wipers Single wipe.
Page 70: Windshield Washers
Wipers and Washers Note: If streaks or smears appear on the windshield, clean the windshield and the wiper blades. If that does not resolve the issue, install new wiper blades. Note: If you switch autolamps and autowipers on, the headlamps turn on when the windshield wipers continuously operate.
Page 71: Lighting
Lighting GENERAL INFORMATION LIGHTING CONTROL Condensation in the Exterior Front Lamps and Rear Lamps Exterior front lamps and rear lamps have vents to accommodate normal changes in air pressure. Condensation can be a natural by-product of this design. When moist air enters the lamp assembly through the vents, there is a possibility that condensation can occur when the temperature is cold.
Page 72: Autolamps
Lighting Flashing the Headlamp High Beam The headlamps remain on for a period of time after you switch the ignition off. Use the information display controls to adjust the period of time that the headlamps remain on. Note: If you switch the autolamps on, you cannot switch the high beams on until the system turns the low beams on.
Page 73: Daytime Running Lamps
Lighting Vehicles With Front Fog Lamps DAYTIME RUNNING LAMPS WARNING: The daytime running lamps system does not activate the rear lamps and may not provide adequate lighting during low visibility driving conditions. Make sure you switch the headlamps on, as appropriate, during all low visibility conditions.
Page 74: Automatic High Beam Control
Lighting If the daytime running lamps are off in the Once the system is active, the high beams information display, the lamps stay off in turn on if: all switch positions. • The ambient light level is low enough. • There is no traffic in front of your AUTOMATIC HIGH BEAM vehicle.
Page 75: Front Fog Lamps
Lighting Automatic High Beam Indicator Push the lever up or down to switch the direction indicators on. The indicator illuminates to Note: Tap the lever up or down to make the confirm when the system is direction indicators flash three times. ready to assist.
Page 76: Ambient Lighting
Lighting If you set the switch to the all on position Select the settings option on the with the ignition switched off, the courtesy feature bar. lamp illuminates. It goes off after a short time to prevent your vehicle battery from Select ambient lighting.
Page 77: Windows And Mirrors
Windows and Mirrors Driver Door Switches (Double Cab) POWER WINDOWS WARNING: Do not leave children or pets unattended in your vehicle. Failure to follow this instruction could result in personal injury or death. WARNING: When closing the power windows, verify they are free of obstruction and make sure that children and pets are not in the proximity of the window openings.
Page 78 Windows and Mirrors Driver Door Switches (Single and Front and Rear Passenger Door Stretch Cab) Switches E131467 Press the switch to open the window. Lift the switch to close the window. Opening and Closing the Driver Side Window Automatically E131469 Press or lift the switch to the second action point and release it.
Page 79 Windows and Mirrors Safety Mode Note: In vehicles without global opening and closing, you cannot operate the rear Note: The anti-trap function is not active windows from driver side when you press during this procedure. the safety switch. In certain vehicles, you cannot operate front passenger windows If the system detects a malfunction, it as well.
Page 80: Exterior Mirrors
Windows and Mirrors If you disconnect the battery, you must reset the bounce-back memory separately for each window. Lift and hold the switch until you fully close the window. 2. Release the switch. 3. Lift the switch again for one second. 4.
Page 81: Interior Mirror
Windows and Mirrors Power-Folding Mirrors INTERIOR MIRROR The power folding mirrors operate with the Manual Dimming Mirror ignition on. Note: The mirrors no longer operate if you switch the ignition off. WARNING: Do not adjust the mirrors when your vehicle is moving. This could result in the loss of control of your vehicle, serious personal injury or death.
Page 82: Sun Visors
Windows and Mirrors SUN VISORS E138666 Rotate the sun visor toward the side window and extend it rearward for extra shade. Illuminated Vanity Mirror (If Equipped) E162197 Lift the cover to switch the lamp on. Ranger (TFG) Canada/United States of America, enUSA, Edition date: 201809, First-Printing...
Page 83: Instrument Cluster
Instrument Cluster GAUGES Type 1 and 2 E271817 Information Display Tachometer Odometer Information Display (Type 2 shown Type 1 similar) Located in the bottom of the information display. Registers the accumulated Speedometer distance your vehicle has traveled. Fuel Gauge Compass Engine Coolant Temperature Gauge Displays the vehicle’s heading direction.
Page 84 Instrument Cluster Vehicle Settings and Personalization Note: Do not restart the engine until the cause of overheating has been resolved. See General Information (page 87). Fuel Gauge Engine Coolant Temperature Gauge The fuel gauge indicates about how much fuel is in the fuel tank. The arrow adjacent to the fuel pump WARNING: Do not remove the symbol indicates on which side of your...
Page 85: Warning Lamps And Indicators
Instrument Cluster Type 3 E272460 Vehicle Settings and Personalization Left Information Display See General Information (page 87). Speedometer Right Information Display. See WARNING LAMPS AND General Information (page 87). INDICATORS Left Information Display The following warning lamps and indicators alert you to a vehicle condition Odometer that may become serious.
Page 86 Instrument Cluster Battery Note: Some warning indicators appear in the information display and operate the It illuminates when you switch same as a warning lamp but do not the ignition on. illuminate when you start your vehicle. If it illuminates when the engine Adaptive Cruise Control Indicator is running this indicates a malfunction.
Page 87 Instrument Cluster Cruise Control Indicator Four-Wheel Drive Indicators (If Equipped) Equipped) It illuminates when you switch the system on. Illuminates when four-wheel E71340 drive low is engaged. See Using Cruise Control E181780 (page 176). Illuminates when four-wheel drive high is engaged. Direction Indicator E181779 Flashes when the left or right...
Page 88 Instrument Cluster Low Tire Pressure Warning Lamp Service Engine Soon It illuminates when your tire If it illuminates when the engine pressure is low. If the lamp is running this indicates a remains on with the engine malfunction. The On Board running or when driving, check your tire Diagnostics system has detected a pressure as soon as possible.
Page 89: Audible Warnings And Indicators
Instrument Cluster Tow Haul Indicator Door Ajar (If Equipped) Sounds when the driver's door is ajar, or It illuminates when you switch when any door is ajar while the vehicle is the system on. traveling over 3 mph (5 km/h). E271981 Trail Control Seatbelt Reminder...
Page 90: Information Displays
Information Displays Information Display Controls GENERAL INFORMATION (Type 1 and Type 2) WARNING: Driving while distracted can result in loss of vehicle control, crash and injury. We strongly recommend that you use extreme caution when using any device that may take your focus off the road.
Page 91 Information Displays Trip 1 and 2 Digital Speedo Distance to E Trip Odometer Trip Timer Average Fuel Outside Temp. All Values Type 2 • Digital Speedometer - Shows the speed your vehicle is traveling. • Distance to E - Shows the approximate distance your vehicle can travel before running out of fuel.
Page 92 Information Displays Fuel Economy All Values Auto StartStop Type 2 • Distance to Empty - Shows the approximate distance your vehicle can travel before running out of fuel. • Inst Fuel Economy - Shows a visual graph of your instantaneous fuel economy along with your Avg MPG since the function was last reset.
Page 93 Information Displays Driver Assist Tire Monitor Tire Pressure Trailer Sway Type 2 Settings Vehicle Auto Engine Off Easy Entry/Exit Lighting Enter the submenu and select your setting Locks Enter the submenu and select your setting Neutral Hold OK to Initialize Neutral Tow Oil Life oil Life XXX% - Hold OK to Reset Reset...
Page 94 Information Displays Settings Volume Limiter Clear Hold OK to Clear All MyKeys MyKeys Display Distance Enter the submenu and select your setting Setup Temper- Enter the submenu and select your setting ature Tire Pres- Enter the submenu and select your setting sure Language Enter the submenu and select your setting...
Page 95 Information Displays Display Mode Distance to Empty Tach and Gauges Off Road Digital Speedometer Tire Pressure Average Speed Note: Some options may appear slightly Trip 1 & 2 different or not at all if the items are optional. You can access the menu using the information display control.
Page 96 Information Displays Fuel Economy Fuel Economy Fuel History Auto StartStop • Fuel Economy - Shows a visual graph of your instantaneous fuel economy, average fuel economy and distance to empty. • Fuel History - Shows a bar chart of your fuel history from the past 30 min, average fuel economy and distance to empty.
Page 97 Information Displays Driver Assist Lane Keeping Enter the submenu and select your setting Pre-Collision Enter the submenu and select your setting Tire Monitor Tire Monitor Note: Some items are optional and may Settings not appear. In this mode, you can configure different driver setting choices.
Page 98: Information Messages
Information Displays Settings Clear MyKeys Hold OK to Clear All MyKeys Display Measurement Enter the submenu and select your setting Setup Units Temperature Enter the submenu and select your setting Gauge Display Enter the submenu and select your setting Tire Pressure Enter the submenu and select your setting Language Enter the submenu and select your setting...
Page 99 Information Displays Adaptive Cruise Control Message Action Adaptive Cruise A radar malfunction is preventing the adaptive cruise control Malfunction from engaging. See Using Cruise Control (page 176). Adaptive Cruise Not A condition exists such that the adaptive cruise cannot func- Available tion properly.
Page 100 Information Displays Battery and Charging System Message Action Check Charging System The charging system needs servicing. If the warning stays on or continues to come on, contact an authorized dealer as soon as possible. Low Battery Features The battery management system detects an extended low- Temporarily Turned Off voltage condition.
Page 101 Information Displays Message Action Cross Traffic Not Avail- The blind spot information system and cross traffic alert able Sensor Blocked See system sensors are blocked. See Blind Spot Information Manual System (page 190). Cross Traffic System A fault with the system has occurred. Contact an authorized Fault dealer as soon as possible.
Page 102 Information Displays Drivetrain Message Action To Engage Locking The electronic locking differential requests a certain speed Differential Slow to XX requirement to engage. mph/km/h To Engage Locking The electronic locking differential requests the accelerator Differential Release to be released in order to engage. Accelerator Pedal Check Locking Differen- An electronic locking differential (ELD) system fault is...
Page 103 Information Displays Keys and Intelligent Access Message Action To START Press Brake A reminder to press the brake while starting the vehicle. No Key Detected The system does not detect a key in your vehicle. Restart Now or Key is You pressed the StartStop button to switch off the engine Needed and your vehicle does not detect your intelligent access key...
Page 104 Information Displays Lane Keeping System Message Action Lane Keeping Sys. The system has malfunctioned. Contact an authorized dealer Malfunction Service as soon as possible. Required Front Camera Tempor- The system has detected a condition that has caused the arily Not Available system to be temporarily unavailable.
Page 105 Information Displays MyKey Message Action MyKey not Created You cannot program a MyKey. MyKey Active Drive MyKey is active. Safely Speed Limited to XX When switching on your vehicle and MyKey is in use, displays MPH/km/h that the MyKey speed limit is on. Near Vehicle Top Speed MyKey is in use and the MyKey speed limit is on and the vehicle speed is approaching 81 mph (130 km/h).
Page 106 Information Displays Park Aid Message Action Check Front Park Aid The system has detected a condition that requires service. Contact an authorized dealer. See Front Parking Aid (page 171). Check Rear Park Aid The system has detected a condition that requires service. Contact an authorized dealer.
Page 107 Information Displays Remote Start Message Action To Drive: Press Start A reminder to push the start button to drive your vehicle after Button a remote start. Seats Message Action Memory Recall Not A reminder that memory seats are not available while driving. Permitted While Driving Memory {0} Saved Shows where you have saved your memory setting.
Page 108 Information Displays Traction Control Message Action Traction Control Off The status of the traction control system after you switched it off. Traction Control On The status of the traction control system after you switched it on. Trail Control Message Action Reduce Speed To Enter Trail You must reduce your vehicle speed to use trail control.
Page 109 Information Displays Trailer Message Action Trailer Connected A correct trailer connection is sensed during a given ignition cycle. Trailer Disconnected A trailer connection becomes disconnected, either intentionally or unintentionally, and has been sensed during a given ignition cycle. Trailer Sway Reduce Speed The trailer sway control has detected trailer sway.
Page 110 Information Displays Message Action Shift Delayed Pull Forward May display when there is a Transfer case gear tooth blockage while shifting to or from 4L or to the neutral state. 4x4 Temporarily Disabled Displays when the system turns off the clutch due to excessive stress.
Page 111: Climate Control
Climate Control Setting the Temperature MANUAL CLIMATE CONTROL Directing the Airflow Press and release the button to direct airflow to the windshield air vents and de-mister. Press and release the button to direct airflow to the instrument panel air vents. Press and release the button to direct airflow to the footwell air vents.
Page 112: Automatic Climate Control
Climate Control Note: Recirculated air flows through the Note: You can control some of the climate instrument panel air vents, air conditioning features through the touchscreen. turns on and the blower motor adjusts to Setting the Temperature the highest speed. Press and release + or - on the left-hand Switching Maximum Defrost On side of the climate control to set the...
Page 113: Hints On Controlling The Interior Climate
Climate Control Note: In certain conditions such as The left-hand and right-hand settings set maximum defrost, the air conditioning to HI, air flows through the windshield air compressor may continue to operate even vents, and the blower motor adjusts to the though you switch off the air conditioning.
Page 114: Ranger (Tfg) Canada/United States Of America, Enusa, Edition Date: 201809, First-Printing
Climate Control Note: To reduce humidity build-up inside Automatic Climate Control your vehicle, do not drive with the system Note: Adjusting the settings when your switched off or with recirculated air always vehicle interior is extremely hot or cold is switched on.
Page 115: Ranger (Tfg) Canada/United States Of America, Enusa, Edition Date: 201809, First-Printing
Climate Control Recommended Settings for Heating Manual climate control Automatic climate control Adjust the fan speed to the center Press AUTO. setting. Adjust the temperature control to the Adjust the temperature control to the midway point of the hot settings. desired setting.
Page 116: Heated Windshield
Climate Control Defogging the Side Windows in Cold Weather Manual climate control Automatic climate control Direct air to the windshield using the air Press the defrost button. distribution buttons. Press A/C. Adjust the temperature control to the desired setting. Use 72°F (22°C) as a starting point, then adjust the setting as necessary.
Page 117: Remote Start
Climate Control Automatic Settings You can locate the cabin air filter behind the glove box. If Auto is on, the system sets the interior Note: Make sure you have a cabin air filter temperature to 72°F (22°C) and heats or installed at all times.
Page 118: Seats
Seats We recommend that you follow these SITTING IN THE CORRECT guidelines: POSITION • Sit in an upright position with the base of your spine as far back as possible. • Do not recline the seat backrest so that WARNING: Sitting improperly, out your torso is more than 30°...
Page 119 Seats Rear Seat Center Head Restraint WARNING: The head restraint is a safety device. Whenever possible it should be installed and properly adjusted when the seat is occupied. Failure to adjust the head restraint properly could reduce its effectiveness during certain impacts. Note: Adjust the seat backrest to an upright driving position before adjusting the head restraint.
Page 120: Manual Seats
Seats Installing the Head Restraint MANUAL SEATS (IF EQUIPPED) Align the steel stems into the guide sleeves and push the head restraint down until it locks. WARNING: Do not adjust the driver seat or seat backrest when your Folding the Head Restraint vehicle is moving.
Page 121: Power Seats
Seats Adjusting the Recliner POWER SEATS (IF EQUIPPED) WARNING: Do not adjust the driver seat or seat backrest when your vehicle is moving. This may result in sudden seat movement, causing the loss of control of your vehicle. WARNING: Do not place cargo or any objects behind the seatback before returning it to the original position.
Page 122: Rear Seats
Seats Adjusting the Driver Seat Height Adjusting the Lumbar E273890 E273887 Adjusting the Recliner REAR SEATS (IF EQUIPPED) Folding the Seat Cushion E275421 E273885 Ranger (TFG) Canada/United States of America, enUSA, Edition date: 201809, First-Printing...
Page 123 Seats E275422 E275423 Place the passenger side seat buckles Push the seat cushion down. behind the elastic strap on the seat 2. Remove the seatbelt buckles from backrest. behind the elastic strap on the seat 2. Place the driver side seat buckle behind backrest.
Page 124: Heated Seats
Seats cause burns even at low temperatures, especially if used for long periods of time. Do not place anything on the seat that may block the heat, such as a blanket or cushion. This can cause the heated seat to overheat. Do not puncture the seat with pins, needles or other pointed objects.
Page 125: Garage Door Opener
Garage Door Opener UNIVERSAL GARAGE DOOR OPENER HomeLink Wireless Control System WARNING: Make sure that the garage door and security device are free from obstruction when you are programming. Do not program the E188211 system with the vehicle in the garage. The universal garage door opener replaces WARNING: Do not use the system the common hand-held garage door...
Page 126 Garage Door Opener If the indicator light flashes rapidly, press and hold for two seconds and release the programmed HomeLink button. Repeat the "press/hold/release" sequence up to three times to complete the programming process. If your device still does not operate, you must program your garage door.
Page 127 Garage Door Opener E188212 E188213 3. Press and hold the function button you Press and hold the outer two function want to program for 2 seconds, then buttons simultaneously for release. Repeat this step. Depending approximately 10 seconds until the on your brand of garage door opener, indicator light above the buttons you may need to repeat this sequence...
Page 128 Garage Door Opener FCC and RSS-210 Industry Canada Compliance This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired...
Page 129: Auxiliary Power Points
Auxiliary Power Points 12 Volt DC Power Point USB Port and Power Point Locations USB Ports and Power Points may be in the WARNING: Do not plug optional following locations: electrical accessories into the cigar • On the lower instrument panel. lighter socket.
Page 130 Auxiliary Power Points • Measuring devices, which process precise data, such as medical equipment or measuring equipment. • Other appliances requiring an extremely stable power supply such as microcomputer-controlled electric blankets or touch-sensor lamps. E247586 When the indicator light on the power point •...
Page 131: Storage Compartments
Storage Compartments GLOVE COMPARTMENT The glove box is on the passenger side of the instrument panel. Open the glove box using the latch handle. E277291 Audio input and or USB port. Cup holders. Coin storage. Auxiliary power point (if equipped). USB charger (if equipped).
Page 132: Rear Seat Armrest
Storage Compartments 2. Lift the handle in the direction shown. REAR SEAT ARMREST 3. Slide it in the direction shown to EQUIPPED) remove the under seat storage cover. E131745 Push the armrest into the seatback to store it. 2. Pull the strap to open the armrest. UNDER SEAT STORAGE Super Cab E188672...
Page 133: Starting And Stopping The Engine
Starting and Stopping the Engine If you disconnect the battery, your vehicle GENERAL INFORMATION may exhibit some unusual driving characteristics for approximately 5 mi (8 km) after you reconnect it. This is WARNING: Extended idling at high because the engine management system engine speeds can produce very high must realign itself with the engine.
Page 134: Push Button Ignition Switch
Starting and Stopping the Engine Switching the Ignition Off Press the push button ignition switch again without your foot on the brake or clutch Turn the key to position 0. pedal to switch the ignition off. Note: The system may not function if the Switching the Ignition to passive key is close to metal objects or Accessory Mode...
Page 135 Starting and Stopping the Engine Failure to Start - Vehicles with Stopping the Engine When Your Manual Transmission Vehicle is Moving - Vehicles with (If Equipped) Manual Transmission (If Equipped) The system does not function if: • The passive key frequencies are jammed.
Page 136 Starting and Stopping the Engine Press and hold the push button ignition Within 10 seconds of switching the engine switch until the engine stops, or press off, fully press the brake or clutch pedal it three times within two seconds. and press the push button ignition switch.
Page 137: Unique Driving Characteristics
Unique Driving Characteristics Enabling Auto-Start-Stop AUTO-START-STOP The system is automatically enabled every The system helps reduce fuel consumption time you start your vehicle if the following by automatically shutting off and restarting conditions are met: the engine while your vehicle is stopped. •...
Page 138 Unique Driving Characteristics Automatic Engine Restart If your vehicle is in an Auto-Start-Stop state and you shift the transmission to Any of the following conditions will result reverse without pressing the brake, a in an automatic restart of the engine: message telling you to press the brake appears.
Page 139: Fuel And Refueling
Fuel and Refueling • Avoid inhaling fuel vapors. Inhaling fuel SAFETY PRECAUTIONS vapor can lead to eye and respiratory tract irritation. In severe cases, excessive or prolonged breathing of WARNING: Do not overfill the fuel fuel vapor can cause serious illness and tank.
Page 140: Fuel Filler Funnel Location
Fuel and Refueling Some fuel stations, particularly those in • Fuels containing the octane booster high altitude areas, offer fuels posted as additive, methylcyclopentadienyl regular unleaded gasoline with an octane manganese tricarbonyl (MMT). rating below 87. The use of these fuels •...
Page 141 Fuel and Refueling Use the following guidelines to avoid When refueling the vehicle fuel tank from electrostatic charge build-up, which can a fuel container, do the following: produce a spark, when filling an Fully open the fuel filler door. ungrounded fuel container: 2.
Page 142: Refueling
Fuel and Refueling REFUELING Refueling System Overview E206911 E267248 Left-hand side. To open the fuel Fuel filler door. filler door, press the center rear edge of the fuel filler door and Fuel tank filler valve. then release. Fuel tank filler pipe. Right-hand side.
Page 143 Fuel and Refueling WARNING: The fuel system may be under pressure. If you hear a hissing sound near the fuel filler inlet, do not refuel until the sound stops. Otherwise, fuel may spray out, which could cause serious personal injury. WARNING: Do not pry open the fuel tank filler valve.
Page 144: Fuel Consumption
Fuel and Refueling 3. Apply the parking brake. 4. Fully open the fuel filler door. 5. Check the fuel tank filler valve for any debris that may be restricting its movement. 6. Remove any debris from the fuel tank filler valve. Fully insert a fuel pump nozzle or the E206912 fuel filler funnel provided with your...
Page 145 Fuel and Refueling Filling the Fuel Tank Keep a record for at least one month and record the type of driving, for example city For consistent results when refueling: or highway. This provides an accurate estimate of your vehicle’s fuel economy •...
Page 146: Engine Emission Control
Engine Emission Control Tampering With a Noise Control EMISSION LAW System Federal laws prohibit the following acts: WARNING: Do not remove or alter • Removal or rendering inoperative by the original equipment floor covering or any person other than for purposes of insulation between it and the metal floor maintenance.
Page 147: Catalytic Converter
Never work around or attempt your vehicle and to its emissions system. to repair any part of the exhaust system If you use anything other than Ford, until it has cooled. Use special care when Motorcraft or Ford-authorized parts for working around the catalytic converter.
Page 148 Engine Emission Control Illumination of the service engine soon Your vehicle has run out of fuel—the indicator, charging system warning light or engine may misfire or run poorly. the temperature warning light, fluid leaks, 2. Poor fuel quality or water in the strange odors, smoke or loss of engine fuel—the engine may misfire or run power could indicate that the emission...
Page 149 Engine Emission Control Your vehicle may not pass the I/M test if the service engine soon indicator is on or not working properly (bulb is burned out), or if the OBD-II system has determined that some of the emission control systems have not been properly checked.
Page 150: Transmission
Transmission Press the button (1) on the transmission AUTOMATIC TRANSMISSION selector lever (2) to select reverse (R) or drive (D). After the transmission is in drive (D), you can then press the button (1) on WARNING: Always fully apply the the transmission selector lever (2) again parking brake and make sure you shift to select sport (S).
Page 151 Transmission SelectShift Automatic Sport Mode (S) Transmission Switch on sport mode by shifting the transmission selector lever to sport (S). In This feature gives you the ability to change sport mode the transmission selects the gears up or down as desired. optimum gear for best performance.
Page 152 Transmission Progressive Range Selection Your vehicle has a brake-shift interlock feature that prevents moving the gearshift Progressive Range Selection gives you the lever from park (P) when the ignition is on ability to lockout gears from the automatic and you do not press the brake pedal. shifting range.
Page 153 Transmission If Your Vehicle Gets Stuck In Mud or Snow Note: Do not rock your vehicle if the engine is not at normal operating temperature or damage to the transmission may occur. Note: Do not rock your vehicle for more than a minute or damage to the transmission and tires may occur, or the engine may overheat.
Page 154: Four-Wheel Drive
Four-Wheel Drive (If Equipped) 4WD Indicator Lights PRINCIPLE OF OPERATION Note: When a 4X4 system fault is present, The four-wheel drive system in your vehicle the system can typically remain in whichever is a part-time system activated using the 4X4 mode was selected prior to the fault rotary switch mounted in the center condition occurring.
Page 155 Four-Wheel Drive (If Equipped) 2H (4X2) You can move the control between 2H to 4H at a stop or when driving up to 68 mph For general on-road driving, this mode (110 km/h). The information display may provides optimal smoothness and fuel display a message indicating a 4X4 shift economy.
Page 156 Four-Wheel Drive (If Equipped) Truck and utility vehicles can differ from Four-wheel drive vehicles are specially some other vehicles. Your vehicle may be designed for driving on sand, snow, mud higher to allow it to travel over rough and rough terrain and have operating terrain without getting hung up or characteristics that are somewhat damaging underbody components.
Page 157 Four-Wheel Drive (If Equipped) It may be safer to stay on the shoulder of Driving in Special Conditions with the road and gradually slow down before Four-Wheel Drive returning to the road. You may lose control Four-wheel drive vehicles are suitable for if you do not slow down or if you too driving on sand, snow, mud and rough sharply or abruptly turn the steering wheel.
Page 158 “Tread Lightly” is an educational program designed to increase public awareness of land-use regulations and responsibilities in our nations wilderness areas. Ford Motor Be cautious of sudden changes in vehicle Company joins the U.S. Forest Service and speed or direction when you are driving in the Bureau of Land Management in mud.
Page 159 Four-Wheel Drive (If Equipped) Four-wheel drive vehicles have advantages over two-wheel drive vehicles in snow and ice but can skid like any other vehicle. Should you start to slide when driving on snowy or icy roads, turn the steering wheel in the direction of the slide until you regain control.
Page 160 Four-Wheel Drive (If Equipped) Note: Do not rock your vehicle for more We recommend that you use caution when than a minute, damage to the transmission your vehicle has either a high load or device and tires may occur or the engine may such as ladders or luggage racks.
Page 161: Rear Axle
Rear Axle Note: You can use the system in any drive ELECTRONIC LOCKING mode 2H, 4H or 4L. DIFFERENTIAL (IF EQUIPPED) Note: When you engage the system, the Electronic Stability Program (ESP) functions Note: Do not operate the system on sealed such as Stability Control, Traction Control, roads.
Page 162: Brakes
Brakes Anti-lock Brake System GENERAL INFORMATION This system helps you maintain steering Note: Occasional brake noise is normal. If control during emergency stops by keeping a metal-to-metal, continuous grinding or the brakes from locking. continuous squeal sound is present, the This lamp momentarily brake linings may be worn-out and an illuminates when you switch the...
Page 163: Parking Brake
Brakes Note: If the system activates, the brake Press the foot brake pedal firmly. pedal may pulse and may travel further. 2. Pull the parking brake lever up to its Maintain pressure on the brake pedal. You fullest extent. may also hear a noise from the system. This To release the parking brake: is normal.
Page 164 Brakes developed sufficient torque to prevent your Vehicles with Automatic Transmission vehicle from rolling down the slope. This You cannot turn the system on or off. is an advantage when pulling away on a When you switch the ignition on, the slope, for example from a car park ramp, system automatically turns on.
Page 165: Traction Control
Traction Control (If Equipped) Switching the System Off PRINCIPLE OF OPERATION The traction control system helps avoid drive wheel spin and loss of traction. If your vehicle begins to slide, the system applies the brakes to individual wheels and, when needed, reduces engine power at the same time.
Page 166: Stability Control
Stability Control (If Equipped) If the stability control or traction control PRINCIPLE OF OPERATION system detects a fault, the following may occur: • The stability and traction control light WARNING: Vehicle modifications illuminates steadily. involving braking system, aftermarket • The stability control and traction roof racks, suspension, steering system, control systems do not enhance your tire construction and wheel and tire size...
Page 167: Using Stability Control
Stability Control (If Equipped) USING STABILITY CONTROL AdvanceTrac with Roll Stability Control (RSC The system automatically turns on each time you switch the ignition on. E72903 E277072 You can switch the electronic stability Vehicle without stability control control systems off. skidding off its intended route.
Page 168 Stability Control (If Equipped) AdvanceTrac with RSC Features Button pressed Not illuminated Enabled Enabled Enabled again after deactivation Transfer case Illuminated Disabled Disabled Enabled switched to 4WD Low Roll Stability Control is disabled in the Sand Terrain Mode. Ranger (TFG) Canada/United States of America, enUSA, Edition date: 201809, First-Printing...
Page 169: Terrain Control
Terrain Control (If Equipped) Mud/Ruts - For off-road PRINCIPLE OF OPERATION conditions. Select this mode for E225313 muddy, rutted, soft or uneven Using the Terrain Management terrain. System Sand - For off-road conditions. The terrain management system optimizes Select this mode in soft dry sand drivability and comfort by maximizing E283037 or deep gravel.
Page 170 Terrain Control (If Equipped) Note: Operating your vehicle in any of the off-road modes does not guarantee that it cannot become stuck in sand, snow or mud or other debris. It is your responsibility to assess off-road situations and determine if the terrain is passable.
Page 171: Trail Control
Trail Control The system switches off if you press the ABOUT TRAIL CONTROL button again or exceed 42 mph (68 km/h). SETTING THE TRAIL CONTROL WARNING: The system does not SPEED control speed in low traction conditions or extremely steep slopes. The system is designed to be an aid and does not Note: The buttons are on the steering relieve you of your responsibility to drive...
Page 172: Trail Control - Troubleshooting
Trail Control TRAIL CONTROL – TROUBLESHOOTING Trail Control – Information Messages Message Action Reduce Speed To Enter Trail Displays when you must reduce your vehicle speed to Control use trail control. Trail Control Not Available with Displays when you must release the park brake to use Park Brake Applied trail control.
Page 173: Parking Aids
Parking Aids Note: Certain add-on devices installed PRINCIPLE OF OPERATION around the bumper or fascia may create false alerts. For example, large trailer hitches, bike or surfboard racks, license plate WARNING: To help avoid personal brackets, bumper covers or any other device injury, always use caution when in that may block the normal detection zone reverse (R) and when using the sensing...
Page 174: Front Parking Aid
Parking Aids Obstacle Distance Indicator Equipped) The system provides obstacle distance indication through the information display. The distance indicator displays when the transmission is in reverse (R). The indicator displays: • As the distance to the obstacle decreases the indicator blocks illuminate and move towards the vehicle icon.
Page 175: Rear View Camera
Parking Aids You can switch the system off through the If the transmission is in neutral (N), the information display menu or from the system provides visual indication only pop-up message that appears once you when your vehicle is moving at 5 mph shift the transmission into reverse (R).
Page 176 Parking Aids During operation, lines appear in the Note: When towing, the camera only sees display which represent your vehicle’s path what you are towing behind your vehicle. and proximity to objects behind your This might not provide adequate coverage vehicle.
Page 177 Parking Aids The fixed and active guidelines fade in and out depending on the steering wheel position. The active guidelines do not show when the steering wheel position is straight. Always use caution while reversing. Objects in the red zone are closest to your vehicle and objects in the green zone are farther away.
Page 178 Parking Aids Manual Zoom WARNING: When manual zoom is on, the full area behind your vehicle may not show. Be aware of your surroundings when using the manual zoom feature. Note: Manual zoom is only available when the transmission is in reverse (R). Note: Only the centerline shows when you enable manual zoom.
Page 179: Cruise Control
Cruise Control (If Equipped) The indicator appears in the PRINCIPLE OF OPERATION information display. E71340 Cruise control lets you maintain a set speed without keeping your foot on the Setting the Cruise Speed accelerator pedal. You can use cruise control when your vehicle speed is greater Drive to the speed you prefer.
Page 180: Using Adaptive Cruise Control
Cruise Control (If Equipped) Resuming the Set Speed WARNING: Do not use tire sizes Press to resume the set speed. other than those recommended because this can affect the normal operation of the system. Failure to do so may result Switching Cruise Control Off in a loss of vehicle control, which could result in serious injury.
Page 181 Cruise Control (If Equipped) The indicator, current gap setting and set speed appear in the information display. E164805 E266656 A vehicle graphic illuminates if there is a The adaptive cruise controls are on the vehicle detected in front of you. steering wheel.
Page 182 Cruise Control (If Equipped) When a vehicle ahead of you enters the same lane or a slower vehicle is ahead in the same lane, the vehicle speed adjusts to maintain a preset gap distance. A vehicle graphic illuminates in the instrument cluster.
Page 183 Cruise Control (If Equipped) Resuming the Set Speed When you press the accelerator pedal, you override the set speed and gap distance. Press and release the button. Use the accelerator pedal normally to intentionally exceed E144529 the set speed limit. Your vehicle speed returns to the previously set speed and gap setting.
Page 184 Cruise Control (If Equipped) Switching Adaptive Cruise Control Press and release the button when the system is in standby mode, or switch the ignition off. E265297 Note: You erase the set speed and gap setting when you switch the system off. Detection Issues WARNING: On rare occasions, detection issues can occur due to the...
Page 185 Cruise Control (If Equipped) Blocked Sensor Optimal system performance requires a clear view of the road by the windshield-mounted camera. Optimal performance may not occur if: • The camera is blocked. • There is poor visibility or lighting conditions. • There are bad weather conditions.
Page 186 Cruise Control (If Equipped) Cause Action Water, snow or ice on the surface of the Do not use the system in these conditions road may interfere with the radar signals. because it may not detect any vehicles ahead. You are in a desert or remote area with no Wait a short time or switch to normal cruise other vehicles and no roadside objects.
Page 187: Driving Aids
Driving Aids Note: The system may not operate correctly DRIVER ALERT (IF EQUIPPED) if you modify the ride height. PRINCIPLE OF OPERATION Note: Keep the windshield free from obstructions. For example, bird droppings, insects, snow or ice. WARNING: You are responsible Note: If the camera is blocked or if the for controlling your vehicle at all times.
Page 188: Lane Keeping System
Driving Aids System Warnings The status bar travels from left to right as the calculated alertness level decreases. Note: The system does not issue warnings As the meter approaches the rest icon, the below approximately 40 mph (64 km/h). color turns from green to yellow to red. The warning system has two stages.
Page 189 Driving Aids WARNING: In cold and severe weather conditions the system may not function. Rain, snow and spray can all limit sensor performance. WARNING: The system will not operate if the sensor cannot track the road lane markings. WARNING: The sensor may E249505 incorrectly track lane markings as other structures or objects.
Page 190 Driving Aids Press the button on the direction indicator stalk to switch the system on or off. System Settings The system has optional setting menus available. The system stores the last known selection for each of these settings. You do not need to readjust your settings each time you switch the system on.
Page 191 Driving Aids System Display • Your vehicle is under the activation speed. • Your vehicle is in a dynamic maneuver. • The road has no or poor lane markings in the camera field-of-view. • The camera is obscured or unable to detect the lane markings due to environmental, traffic or vehicle conditions.
Page 192 Driving Aids Why is the feature not available when I can see the lane markings on the road? Driving at high speeds in curves. The last alert warning or aid intervention occurred a short time ago. Ambiguous lane markings, for example in construction zones. Rapid transition from light to dark, or from dark to light.
Page 193: Blind Spot Information System
Driving Aids Note: The system does not prevent contact BLIND SPOT INFORMATION with other vehicles. It is not designed to SYSTEM (IF EQUIPPED) detect parked vehicles, pedestrians, animals or other infrastructures. Using the Blind Spot Information WARNING: Do not use the blind System spot information system as a replacement for using the interior and...
Page 194 Driving Aids Blind Spot Information System When the system detects a vehicle, an with Trailer Tow alert indicator illuminates in the exterior (If Equipped) mirror on the side the approaching vehicle is coming from. If you turn the direction indicator on for that side of your vehicle, the alert indicator flashes.
Page 195 Driving Aids Setting up a Blind Spot Trailer The trailer length is the distance between the trailer hitch ball and the rear of the trailer. The maximum length that the system can support is 33 ft (10 m). • Enter length of trailer: Toggling up or down using the menu buttons increases or decreases the measurement by 3 ft (1 m).
Page 196: Cross Traffic Alert
Driving Aids Switching the System On and Off or add a new trailer. If you ignore the request or if you exit the screen, a message You can switch the system off using the appears stating the system has turned off information display.
Page 197 Driving Aids Using the Cross Traffic Alert obstructed. Slowly reversing helps increase System the coverage area and effectiveness. The system turns on when you start the The system is designed to detect vehicles engine and you shift into reverse (R). The that approach with a speed up to 37 mph system turns off when you shift out of (60 km/h).
Page 198 Driving Aids E142441 Blocked Sensors Zone coverage also decreases when parking at narrow angles. The sensor on the left-hand side is mostly obstructed and zone coverage on that side is severely reduced. System Lights, Messages and Audible Alerts E280125 The system uses radar sensors that are in the tail lamp on each side of your vehicle.
Page 199: Steering
Driving Aids If the sensors are blocked, a message may Note: The system turns on each time you appear in the information display when switch the ignition on and you shift into you shift into reverse (R). See Information reverse (R). If you temporarily switch the Messages (page 95).
Page 200: Pre-Collision Assist
Driving Aids system. If this should occur, you will neither lose the ability to steer the vehicle WARNING: The system may fail manually nor will it cause permanent or operate with reduced function during damage. Typical steering and driving cold and severe weather conditions. maneuvers will allow the system to cool Snow, ice, rain, spray and fog can and steering assist will return to normal.
Page 201 Driving Aids Active Braking: Active braking may activate if the system determines that a collision is imminent. The system may help E156130 the driver reduce impact damage or avoid the crash completely. If your vehicle is rapidly approaching another stationary vehicle, a vehicle Note: If you perceive Pre-Collision Assist traveling in the same direction as yours, or alerts as being too frequent or disturbing,...
Page 202 Driving Aids Speed Sensitivity Graphics Distance Gap Time Gap 62 mph Normal Grey >82 ft (25 m) >0.9sec (100 km/h) 62 mph 56–82 ft Normal Yellow 0.6sec - 0.9sec (100 km/h) (17–25 m) 62 mph Normal <56 ft (17 m) <0.6sec (100 km/h) Blocked Sensors...
Page 203 Driving Aids the Pre-Collision Assist system does not moving vehicles reduces. The following respond to pedestrians or stationary table lists possible causes and actions for vehicles and the system performance on when this message displays. Cause Action Clean the grille surface in front of the radar The surface of the radar in the grille is dirty or remove the object causing the obstruc- or obstructed in some way.
Page 204: Load Carrying
Load Carrying LOAD LIMIT Tire and Loading Label Information Example: Vehicle Loading - with and without a Trailer This section guides you in the proper loading of your vehicle, trailer, or both. Keep your loaded vehicle weight within its design rating capability, with or without a trailer.
Page 205 Load Carrying is the maximum payload for your The total load on each axle must vehicle as built by the assembly never exceed its Gross Axle plant. If you install any additional Weight Rating. equipment on your vehicle, you GVWR (Gross Vehicle Weight must determine the new payload.
Page 206 Load Carrying be used for safe control of towed vehicles and for trailers where the WARNING: Exceeding the Gross Combined Weight of the Safety Compliance Certification towing vehicle plus the trailer label vehicle weight limits can exceed the Gross Vehicle Weight adversely affect the Rating of the towing vehicle.
Page 207 Load Carrying Steps for determining the Helpful examples for calculating correct load limit: the available amount of cargo and luggage load capacity 1. Locate the statement "The combined weight of occupants Suppose your vehicle has a and cargo should never exceed 1400-pound (635-kilogram) cargo XXX kg or XXX lb."...
Page 208: Roof Racks And Load Carriers
Load Carrying - 1200 = - 240 pounds. No, you do handle differently than unloaded not have enough cargo capacity vehicles. Take extra precautions, to carry that much weight. In such as slower speeds and metric units, the calculation would increased stopping distance, be: 635 kilograms - (2 x 99 when driving a heavily loaded...
Page 209 Load Carrying Note: Exceeding the maximum load rating of the load retaining fixtures may lead to vehicle damage. Note: The number of tie down points may vary depending on your vehicle model. E131643 Load Rating of the Tie Down Points: 661 lb (300 kg).
Page 210: Tailgate
Tailgate MANUAL TAILGATE Note: Do not exceed the maximum permissible tailgate load of 485 lb (220 kg). Note: Vehicles with a tow bar or rear bumper should not have the tailgate lowered without the support cables in place. Note: Make sure that you keep a firm grip on the tailgate to prevent it from dropping down.
Page 211: Towing
Towing Note: Your vehicle includes trailer TOWING A TRAILER stability control if it has an electronic stability program (ESP). WARNING: Do not exceed When towing a trailer: the GVWR or the GAWR • Obey country specific specified on the certification regulations for towing a trailer.
Page 212: Trailer Sway Control
Ford does not recommend disabling this feature except in situations where speed vehicle and could result in engine reduction may be detrimental (such as...
Page 213 Towing Light Duty Trailer Hitch. Heavy Duty Trailer Hitch. Towing Capacities If your vehicle has a light duty trailer hitch, the maximum towing capacity is 3,500 lb (1,588 kg). If your vehicle has a heavy duty trailer hitch, use the chart that follows to find your towing capacity.
Page 214: Towing The Vehicle On Four Wheels
Towing Trailer Nose Weight Variant Minimum Nose Maximum Nose Weight Weight 10% of the towed Light Duty Trailer Hitch 350 lb (159 kg) weight Heavy Duty Trailer 10% of the towed 750 lb (340 kg) Hitch weight Recreational Towing TOWING THE VEHICLE ON Note: Put your climate control system in FOUR WHEELS recirculated air mode to prevent exhaust...
Page 215 Towing 5. Enable Neutral Tow by selecting Settings in the information display WARNING: Shifting the transfer menu. case to its neutral position for 6. Then select Vehicle. recreational towing may cause the vehicle to roll, even if the transmission is Then select Neutral Tow and follow in park (P).
Page 216: Driving Hints
Driving Hints • Close the windows for high-speed BREAKING-IN driving. Tires • Drive at reasonable speeds (traveling at 55 mph [88 km/h] uses 15% less New tires need to be run-in for fuel than traveling at 65 mph [105 approximately 300 mi (500 km). During km/h]).
Page 217: Cold Weather Precautions
Driving Hints • To maximize the fuel economy, drive Before taking your vehicle off-roading, a with the tonneau cover installed (if basic vehicle inspection should be done to equipped). make sure that the vehicle is in top working condition. • Using fuel blended with alcohol may lower fuel economy.
Page 218 Even if your local law the hill, DO NOT attempt to turn back does not prohibit alcohol use while down the slope. Place the vehicle in driving off-road, Ford strongly low range and slowly back down in recommends against drinking if you reverse.
Page 219: Driving Through Water
Driving Hints After Off-Road Driving Note: Driving through standing water can cause vehicle damage. It is important to complete a full vehicle Note: Engine damage can occur if water inspection after off-road driving. Some enters the air filter. items to check include: Before driving through standing water, •...
Page 220 Driving Hints To remove the floor mat, reverse the installation procedure. WARNING: Pedals that cannot Note: Regularly check the floor mats to move freely can cause loss of vehicle make sure they are secure. control and increase the risk of serious personal injury.
Page 221: Roadside Emergencies
• Towing — independent service ROADSIDE ASSISTANCE contractors, if not prohibited by state, local or municipal law, shall tow Ford Vehicles Sold in the United States: eligible vehicles to an authorized dealer Getting Roadside Assistance within 35 mi (56 km) of the...
Page 222: Hazard Flashers
Vehicles Sold in Canada: Getting FUEL SHUTOFF Roadside Assistance To fully assist you should you have a vehicle concern, Ford Motor Company of WARNING: If your vehicle has Canada, Limited offers a complimentary been involved in a crash, have the fuel roadside assistance program.
Page 223: Jump Starting The Vehicle
Roadside Emergencies Connecting the Jumper Cables 4. You can attempt to start the vehicle by pressing the brake pedal and START/STOP, or press START/STOP without pressing the brake pedal. WARNING: Do not attach the 5. If the vehicle does not start, repeat cables to fuel lines, engine rocker covers, steps 1 through 4.
Page 224 Roadside Emergencies Removing the Jumper Cables 2. Connect the other end of the positive (+) cable to the positive (+) terminal Remove the jumper cables in the reverse of the assisting battery. order that they were connected. 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery.
Page 225: Transporting The Vehicle
Roadside Emergencies Towing an all-wheel or four-wheel drive TRANSPORTING THE VEHICLE vehicle requires that all wheels be off the ground, such as using a wheel lift and dollies or flatbed equipment. This prevents damage to the transmission, all-wheel or four-wheel drive system and vehicle. If your vehicle becomes inoperable without access to wheel dollies, a car-hauling trailer or a flatbed transport vehicle, you...
Page 226: Customer Assistance
Mailing address perform a repair after taking your vehicle to the authorized dealer. Repairs will be Customer Relationship Centre made using Ford or Motorcraft® parts, or Ford Motor Company of Canada, Limited remanufactured or other parts that are P.O. Box 2000 authorized by Ford.
Page 227: In California (U.s. Only)
In some states within the United States, conform the vehicle to its applicable you must directly notify Ford in writing express warranties if, within the first 18 before pursuing remedies under your months of ownership of a new vehicle or...
Page 228: The Better Business Bureau (Bbb) Auto Line Program (U.s. Only)
BBB AUTO LINE During mediation, a representative of the 3033 Wilson Boulevard, Suite 600 BBB will contact both you and Ford Motor Arlington, Virginia 22201 Company to explore options for settlement of the claim. If an agreement is not reached...
Page 229: Utilizing The Mediation/Arbitration Program (Canada Only)
Before exporting your vehicle to a foreign Canadian dealers. In those cases where country, contact the appropriate foreign you continue to feel that the efforts by Ford embassy or consulate. These officials can of Canada and the authorized dealer to...
Page 230 (VIN) and new dealership’s Sales Manager, Service address with Ford Global Trade Services Manager or Customer Relations Manager. by emailing, expcso@ford.com. If you require additional assistance or clarification, please contact the respective Customer Relationship Center as previously listed.
Page 231: Ordering Additional Owner's Literature
NHTSA cannot become involved (Items in this catalog may be purchased by credit card, check or money order.) in individual problems between you, your dealer, or Ford Motor Obtaining a French Owner’s Company. Manual To contact NHTSA, you may call French Owner’s Manual can be obtained...
Page 232: Reporting Safety Defects (Canada Only)
REPORTING SAFETY DEFECTS injury or death, you should immediately (CANADA ONLY) inform Transport Canada and Ford of Canada. If you believe that your vehicle has a defect Transport Canada Contact Information Website http://www.tc.gc.ca/eng/motorvehiclesafety/reporting-defects-motor-...
Page 233: Fuses
Fuses Engine Compartment Fuse Box FUSE BOX LOCATIONS Left-Hand Drive E264973 E206157 Pre-fuse box. Engine compartment fuse box. WARNING: Always disconnect the Passenger compartment fuse battery before servicing high current box. fuses. High current fuse box. WARNING: To reduce risk of Note: The passenger compartment fuse electrical shock, always replace the box is on the right-hand side for right-hand...
Page 234: Fuse Specification Chart
Fuses High Current Fuse Box The fuse box is behind the access cover on (If Equipped) the outermost side of the steering column. FUSE SPECIFICATION CHART Engine Compartment Fuse Box WARNING: Always disconnect the battery before servicing high current fuses. WARNING: To reduce risk of E206158 electrical shock, always replace the...
Page 235 Fuses E190797 Fuse or Relay Fuse Rating Protected Component Number Not used. Starter motor solenoid relay. Rain sensor. Blower motor relay. Auxiliary power point 3 - console rear. Trailer park lamp relay. Powertrain control module. Cannister vent solenoid. Fuel vapor shutoff valve. Canister purge valve.
Page 236 Fuses Fuse or Relay Fuse Rating Protected Component Number Variable cam timing valve 1 and 2. Heated oxygen sensors. Powertrain control module relay. Auxiliary power point 1 - instrument panel. Ignition coils. A/C control drive. Transaxle warmer. Auxiliary water pump. Aspirator valve control.
Page 237 Fuses Fuse or Relay Fuse Rating Protected Component Number Not used (spare). Not used. Powertrain control module. USB charge port. 7.5A Not used. Not used. Fuel pump relay. A/C clutch relay. Trailer reverse lamp. Not used (spare). Not used. Heated exterior mirror. Trailer right turn and stop lamp relay.
Page 238 Fuses Fuse or Relay Fuse Rating Protected Component Number Transmission control module. Oil pump. Wiper park heater. Not used. Not used. Rear differential lock. Not used. Not used. 4WD motor no. 1 relay. M-type fuse. Micro 2 fuse. Micro 3 fuse. Power Distribution Box - Bottom There are fuses on the bottom of the fuse box.
Page 239 Fuses 2. Raise the rear side of the fuse box from 3. Move the fuse box toward the rear side the cradle. of the engine compartment and rotate as shown. 4. Pivot the rear side of the fuse box to access the bottom side.
Page 240 Fuses E190798 Fuse or Relay Number Fuse Rating Protected Component Trailer left turn and stop. Not used. Not used. Not used. Fuel pump control module. Not used. Body control module 1 - lighting. Trailer right turn and stop. Trailer brakes. Ranger (TFG) Canada/United States of America, enUSA, Edition date: 201809, First-Printing...
Page 241 Fuses Fuse or Relay Number Fuse Rating Protected Component Heated driver seat. Four wheel drive. Body control module 2 - lighting. Rear window defroster. Anti-lock brake system valves. Passenger power seat. Trailer park lamps. Not used. Trailer module. Driver power seat. Not used.
Page 242 Fuses Fuse or Relay Number Fuse Rating Protected Component Not used. Trailer module. M-type fuse. LPJ-type fuse. Battery Mounted Fuse Link E200936 Fuse Number Fuse Rating Protected Component 225A Alternator. 125A Electronic power assist steering. High Current Fuse Box E206158 Ranger (TFG) Canada/United States of America, enUSA, Edition date: 201809, First-Printing...
Page 243 Fuses Fuse Number Fuse Rating Protected Component Not used. 125A Body control module. Voltage quality module (supplies rear lamp blind spot, rear view camera, head up display, 4x4 switch, image processing module and adaptive cruise control radar). Busbar through to power distribution box. Passenger Compartment Fuse Box The fuse box is below and outboard of the steering column behind the access cover.
Page 244 Fuses Fuse or Relay Fuse Rating Protected Component Number Not used (spare). Branded audio amplifier. Not used (spare). Not used (spare). Security horn Telematics. Not used (spare). Not used (spare). Electronic control panel. 7.5A Climate control. Instrument cluster. Steering column control module. 7.5A Data link connector.
Page 245 Fuses Fuse or Relay Fuse Rating Protected Component Number Not used (spare). Inverter. Door lock switch. Central locking system. Driver door power window. Not used (spare). Not used (spare). Branded audio amplifier. Not used (spare). Not used (spare). Not used (spare). Radio transceiver module.
Page 246: Changing A Fuse
Fuses CHANGING A FUSE Fuses WARNING: Always replace a fuse with one that has the specified amperage rating. Using a fuse with a E217331 higher amperage rating can cause severe wire damage and could start a fire. If electrical components in the vehicle are not working, a fuse may have blown.
Page 247 Fuses Callout Fuse Type M Case J Case J Case Low Profile Ranger (TFG) Canada/United States of America, enUSA, Edition date: 201809, First-Printing...
Page 248: Maintenance
Maintenance Check Monthly GENERAL INFORMATION • Engine oil level. See Engine Oil Check (page 247). WARNING: Switch the ignition off • Engine coolant level. See Engine and apply the parking brake. Coolant Check (page 249). • Pipes, hoses and reservoirs for leaks. WARNING: Do not touch the •...
Page 249: Under Hood Overview
Maintenance E201861 E271769 5. The hood strut automatically supports 2. Slightly lift the hood. the hood. 3. Move the catch to the left for vehicles with left hand drive. Move the catch to Closing the Hood the right for vehicle with right hand Lower the hood and allow it to drop drive.
Page 250: Engine Oil Dipstick
Maintenance E276868 Engine coolant reservoir. See ENGINE OIL DIPSTICK Engine Coolant Check (page 249). Engine oil dipstick. See Engine Oil Dipstick (page 247). Engine oil filler cap. See Engine Oil Check (page 247). Brake fluid reservoir. See Brake Fluid Check (page 250). Engine compartment fuse box.
Page 251: Oil Change Indicator Reset
100%. Remaining Life Remove the filler cap. 2. Add oil that meets Ford specifications. {00}% See Capacities and Specifications (page 306). 3. Replace the filler cap. Turn it until you feel a strong resistance.
Page 252: Engine Coolant Check
WARNING: Undiluted coolant is flammable and may ignite if spilled on a hot exhaust. We do not recommend the use of recycled engine coolant since a Ford-approved recycling process is not yet available. Do not mix different colors or types of E170684 coolant in your vehicle.
Page 253: Automatic Transmission Fluid Check
Maintenance Note: Add a 50/50 mixture of antifreeze Do not use supplemental transmission and water or prediluted engine coolant that fluid additives, treatments or cleaning meets the correct specification. agents. The use of these materials may affect transmission operation and result Note: Use fluids which meet the in damage to internal transmission specifications or requirements defined.
Page 254: Power Steering Fluid Check
Only use fluid that meets Ford and navigation system. A message may be specifications. See Capacities and shown in the information displays to alert Specifications (page 302).
Page 255: Changing The 12V Battery
Maintenance A connection at the negative battery terminal can cause inaccurate WARNING: Keep batteries out of measurements of the battery condition reach of children. Batteries contain and potential incorrect system operation. sulfuric acid. Avoid contact with skin, When a battery replacement is required, eyes or clothing.
Page 256 If a replacement battery is required, we or arcing. recommend you use a Ford replacement Note: Make sure the battery cable terminals battery that matches the electrical are fully tightened. requirements of your vehicle.
Page 257: Checking The Wiper Blades
Maintenance Pull the wiper blade and arm away CHECKING THE WIPER from the glass. BLADES E279825 2. Squeeze the blade's lock pin and tab E222238 on the bottom of the arm to release Run the tip of your fingers over the edge of the wiper blade.
Page 258 Maintenance E142592 E142465 4. On the wall or screen you will observe 8 ft (2.4 m) a flat zone of high intensity light Ground to the center of the located at the top of the beam pattern. headlamp high beam bulb If the top edge of the flat zone of high intensity light is not on the horizontal 25 ft (7.6 m)
Page 259: Removing A Headlamp
Maintenance 5. Use a suitable tool, for example a Replacing the High Beam Headlamp screwdriver or socket wrench, to turn Bulb the adjuster clockwise or counterclockwise to adjust the vertical aim of the headlamp. The horizontal edge of the brighter light should touch the horizontal reference line.
Page 260 Maintenance Approach Lamp and Side Direction 5. Install the new bulb in reverse order. Indicator (If Equipped) Replacing the Front Park and Direction Indicator Bulb Make sure the lamps are off. 2. Turn the bulb holder counterclockwise and remove it. 3.
Page 261 Maintenance Replacing LED Fog Lamp Bulbs Equipped) If an LED fails have your vehicle checked as soon as possible. Contact an authorized dealer. Rear Lamps (If Equipped) Type 1 Tail, Brake, Reversing, and Direction Indicator E284593 Brake and rear park bulb. Rear direction indicator bulb.
Page 262 Maintenance Replacing LED Brake, Rear, Direction License Plate Lamp Indicator and Reverse Lamp Bulbs If an LED fails have your vehicle checked as soon as possible. Contact an authorized dealer. Type 2 Tail, Brake, Reversing Lamp and Direction Indicator E133686 Make sure the lamps are off.
Page 263: Changing The Engine Air Filter
Maintenance 2. Remove the four screws and move the lamp assembly away from the vehicle to expose the bulb sockets. 3. Remove the bulb socket by rotating it counterclockwise and pulling it out of the lamp assembly. 4. Pull the bulb straight out of the socket. 5.
Page 264: Vehicle Care
Vehicle Care GENERAL INFORMATION CLEANING PRODUCTS Materials Your dealer has many quality products available to clean your vehicle and protect For best results, use the following products its finishes. or products of equivalent quality: Name Specification Motorcraft® Bug and Tar Remover, ZC-42 (U.S. & Canada) Motorcraft®...
Page 265 Vehicle Care • Dry your vehicle with a chamois or soft Note: Do not use chrome cleaner, metal terry cloth towel to eliminate water cleaner or polish on wheels or wheel covers. spotting. Exterior Plastic Parts • Immediately remove fuel spillages, bird droppings, insect deposits and road tar.
Page 266: Waxing
Vehicle Care When washing: WAXING • Take care when using a power washer Regular waxing is necessary to protect your to clean the engine. The high-pressure car's paint from the elements. We fluid could penetrate the sealed parts recommend that you wash and wax the and cause damage.
Page 267: Cleaning The Interior
Vehicle Care To clean the windshield and wiper blades: For fabric, carpets, cloth seats and seats equipped with side airbags: • Clean the windshield with a non-abrasive glass cleaner. When • Remove dust and loose dirt with a cleaning the interior of the windshield, vacuum cleaner.
Page 268: Cleaning Leather Seats
Vehicle Care Clean the instrument panel and cluster 5. Remove the soaked cloth, then with a lens with a clean, damp and soft cloth, clean, damp cloth, use a rubbing then use a clean, dry and soft cloth to dry motion for 60 seconds on the soiled these areas.
Page 269: Repairing Minor Paint Damage
3. Remove tar and grease with a bug and against rust and damage. tar remover. We recommend that you use Ford approved bug and tar remover Body if available. • Wash your vehicle thoroughly to 4.
Page 270 Vehicle Care • Cover interior trim to prevent fading. Note: It is necessary to reset memory features if battery cables are disconnected. • Keep all rubber parts free from oil and solvents. Brakes Engine • Make sure the brakes and parking brake release fully.
Page 271: Body Styling Kits
Vehicle Care • Check fluid levels (including coolant, oil and gas) to make sure there are no leaks, and fluids are at recommended levels. • If you remove the battery, clean the battery cable ends and check for damage. Contact an authorized dealer if you have any concerns or issues.
Page 272: Wheels And Tires
Wheels and Tires Utility vehicles and trucks handle GENERAL INFORMATION differently than passenger cars in the various driving conditions that are Notice to utility vehicle and truck encountered on streets, highways and owners off-road. Utility vehicles and trucks are not designed for cornering at speeds as high as passenger cars any more than low-slung WARNING: Utility vehicles have a...
Page 273 Wheels and Tires How your vehicle differs from • Higher - to allow higher load carrying other vehicles capacity and to allow it to travel over rough terrain without getting hung up Sport utility vehicles and trucks can differ or damaging underbody components. from some other vehicles in a few •...
Page 274: Tire Care
Wheels and Tires Tire Quality Grades apply to new As a result of the above dimensional differences, Sport utility vehicles and pneumatic passenger car tires. trucks often will have a higher center of They do not apply to deep tread, gravity and a greater difference in center winter-type snow tires, of gravity between the loaded and...
Page 275 Wheels and Tires Traction AA A B C test wheel. Sustained high temperature can cause the material of the tire to degenerate and reduce tire life, and excessive WARNING: The traction temperature can lead to sudden grade assigned to this tire is tire failure.
Page 276 Wheels and Tires *Standard load: A class of B-pillar: The structural member P-metric or Metric tires designed at the side of the vehicle behind to carry a maximum load at set the front door. pressure. For example: For *Bead area of the tire: Area of P-Metric tires 35 psi (2.4 bar) and the tire next to the rim.
Page 277 Wheels and Tires Information on P Type Tires B. 215: Indicates the nominal width of the tire in millimeters from sidewall edge to sidewall edge. In general, the larger the number, the wider the tire. C. 65: Indicates the aspect ratio which gives the tire's ratio of height to width.
Page 278 Wheels and Tires Note: You may not find this the last four numbers represent information on all tires because it the week and year the tire was is not required by federal law. built. For example, the numbers 317 mean the 31st week of 1997. After 2000 the numbers go to four Letter mph ( km/h)
Page 279 Wheels and Tires *Treadwear: The treadwear door-latch post, or the door edge grade is a comparative rating that meets the door-latch post, based on the wear rate of the tire next to the driver's seating when tested under controlled position), or Tire Label located on conditions on a specified the B-pillar or the edge of the government test course.
Page 280 Wheels and Tires LT type tires have some additional information beyond those of P type tires. These differences are described below. A. LT: Indicates a tire, designated by the Tire and Rim Association, that is intended for service on light trucks.
Page 281 Wheels and Tires C. 80: Indicates the aspect ratio You are strongly urged to buy a which gives the tire's ratio of reliable tire pressure gauge, as height to width. Numbers of 70 or automatic service station gauges lower indicate a short sidewall. may be inaccurate.
Page 282 Wheels and Tires Tire Label (affixed to either the the manufacturer’s recommended door hinge pillar, door-latch post, cold inflation pressure which can or the door edge that meets the be found on the Safety door-latch post, next to the Compliance Certification Label driver's seating position), or Tire (affixed to either the door hinge Label located on the B-pillar or...
Page 283 Wheels and Tires Note: If you are checking tire Note: Some spare tires operate at pressure when the tire is hot, (for a higher inflation pressure than the example, driven more than 1 mile other tires. For T type mini-spare [1.6 kilometers]), never bleed or tires, see the Dissimilar spare wheel reduce air pressure.
Page 284 Wheels and Tires it needs to be repaired or replaced. When the tire tread wears down For your safety, tires that are to the same height as these wear damaged or show signs of bars, the tire is worn out and must excessive wear should not be used be replaced.
Page 285 Use of any tire or wheel four numbers represent the week not recommended by Ford can and year the tire was built. For affect the safety and example, the numbers 317 mean performance of your vehicle, the 31st week of 1997.
Page 286 20 psi system is malfunctioning. Your (1.38 bar) greater than the replacement tire might be maximum pressure, a Ford incompatible with your tire dealer or other tire service pressure monitoring system, or professional should do the some component of the system mounting.
Page 287 Wheels and Tires Safety Practices If you feel a sudden vibration or ride disturbance while driving, or you suspect your tire or vehicle has been damaged, immediately WARNING: If your vehicle reduce your speed. Drive with is stuck in snow, mud or sand, do caution until you can safely pull not rapidly spin the tires;...
Page 288: Using Snow Chains
Wheels and Tires Tire Rotation Rotating your tires at the recommended interval (as indicated in the Scheduled Maintenance chapter) will help WARNING: If the tire label your tires wear more evenly, shows different tire pressures for providing better tire performance the front and rear tires and the vehicle has a tire pressure and longer tire life.
Page 289 • LT265/65 R17 109T. rating as those originally provided by Ford. Use of any tire or wheel not Only use S-Class snow chains, 0.6 in recommended by Ford can affect the (15 mm) chain links.
Page 290: Tire Pressure Monitoring System
Wheels and Tires them to the proper pressure. Driving on a TIRE PRESSURE MONITORING significantly under-inflated tire causes the SYSTEM tire to overheat and can lead to tire failure. Under-inflation also reduces fuel efficiency and tire tread life, and may affect the vehicle’s handling and stopping ability.
Page 291 Wheels and Tires Understanding Your Tire Pressure 2. This device must accept any Monitoring System interference received, including interference that may cause undesired operation. Note: Changes or modifications not expressively approved by the party responsible for compliance could void the user's authority to operate the equipment.
Page 292 Wheels and Tires When You Believe Your System is Not your tires need air. It can also warn you in Operating Properly the event the system is no longer capable of functioning as intended. See the The main function of the tire pressure following chart for information concerning monitoring system is to warn you when your tire pressure monitoring system:...
Page 293: Changing A Road Wheel
Wheels and Tires When Inflating Your Tires CHANGING A ROAD WHEEL WARNING: Do not use the tire WARNING: If the tire pressure pressure displayed in the information monitor sensor becomes damaged it display as a tire pressure gauge. Failure may not function. to follow this instruction could result in personal injury or death.
Page 294 • Comfort and noise. and wheels that were originally provided • Ground clearance and parking at curbs. by Ford. • Winter weather driving capability. A dissimilar spare wheel and tire assembly is defined as a spare wheel and tire •...
Page 295 Wheels and Tires WARNING: Do not work on your WARNING: Never place anything vehicle when the jack is the only support. between the vehicle jack and your If the vehicle slips off the jack, you or vehicle. someone else could be seriously injured. WARNING: It is recommended WARNING: Do not attempt to that the wheels of the vehicle be...
Page 296 Wheels and Tires WARNING: It is recommended that the wheels of the vehicle be chocked, and that no person should remain in a vehicle that is being jacked. WARNING: No person should place any portion of their body under a vehicle that is supported by a jack.
Page 297 Wheels and Tires Do not use the jack if it is visibly damaged 3. Remove the cover. or does not operate freely. Replace the damaged jack with a jack specified for use on your vehicle if you detect these conditions. SuperCab Note: Pay close attention to the orientation of the jack and tool kit bag, because it needs...
Page 298 Wheels and Tires 4. Remove the tools. Spare Wheel Note: If the spare wheel is not the same type and size as your vehicle road wheel, drive the shortest distance possible. Note: Do not fit more than one spare wheel on your vehicle at any one time.
Page 299 Wheels and Tires E283035 E133590 2. Insert the jack handle into the guide 3. Pass the bracket and cable through the hole. Turn counterclockwise until the wheel opening. wheel rests on the ground, and there is Jacking and Lifting Points slack in the cable.
Page 300 Wheels and Tires E271586 A. Emergency use only. WARNING: Make sure that the Removing a Road Wheel vehicle jack is vertical to the jacking point and the base is flat on the ground. WARNING: Park your vehicle in WARNING: Never place anything such a position that neither the traffic between the vehicle jack and your nor you are hindered or endangered.
Page 301 Wheels and Tires Assemble the jack handle. Note: Assemble the three handles to jack WARNING: Have the lug nuts the rear of the vehicle. checked for tightness and the tire pressure checked as soon as possible. 2. Ensure screwthread on the jack is adequately lubricated before use.
Page 302 Wheels and Tires Note: If the spare wheel is different in size 3. Fully insert the jack handle into the or construction to the road wheels, replace guide hole and turn the jack handle it as soon as possible. clockwise until the tire raises to its stowed position underneath your Stowing the Flat Tire vehicle and securely seated.
Page 303: Technical Specifications
Wheels and Tires E278126 Place the tools inside the tool bag. 2. Place the jack on the foam block and pull the top of the jack up, to align the 2. Install the tool bag on the plastic bin jack load rest hole with the hole of the by passing them through the D-ring floor bracket.
Page 304 Wheels and Tires Wheel Lug Nut Torque Specifications WARNING: When you install a wheel, always remove any corrosion, dirt or foreign materials present on the mounting surfaces of the wheel or the surface of the wheel hub, brake drum or brake disc that contacts the wheel. Make sure to secure any fasteners that attach the rotor to the hub so they do not interfere with the mounting surfaces of the wheel.
Page 305: Capacities And Specifications
Capacities and Specifications ENGINE SPECIFICATIONS Engine 2.3L EcoBoost Cubic inches. Required fuel. Minimum 87 octane Firing order. 1-3-4-2 Ignition system. Coil on plug Spark plug gap. 0.027 - 0.031 in (0.70 - 0.80 mm) Compression ratio. 10:1 Drivebelt Routing 2.3L EcoBoost Engine E276823 Short, narrow width drivebelt is on first pulley groove closest to...
Page 306 Capacities and Specifications Component Part Number Air filter element. FA-1943 Oil filter. FL-910-S Battery. BAGM-48H6-610 BAGM-94RH7-800 Spark plugs. SP-550 Cabin air filter. FP-88 Windshield wiper blade. WW-2615 (driver side) WW-1615 (passenger side) We recommend Motorcraft replacement parts available at your authorized dealer or at fordparts.com for scheduled maintenance.
Page 307: Vehicle Identification Number
Capacities and Specifications VEHICLE IDENTIFICATION VEHICLE CERTIFICATION NUMBER LABEL E167469 The National Highway Traffic Safety E133363 Administration Regulations require that a Safety Compliance Certification Label be The vehicle identification affixed to a vehicle and prescribe where number is on the left-hand side the Safety Compliance Certification Label of the instrument panel.
Page 308: Transmission Code Designation
Capacities and Specifications The transmission code is on the Safety TRANSMISSION CODE Compliance Certification Label. The DESIGNATION following table shows the transmission code along with the transmission description. E167814 Description Code Ten-speed automatic transmission 10R80 Ranger (TFG) Canada/United States of America, enUSA, Edition date: 201809, First-Printing...
Page 309: Capacities And Specifications
Capacities and Specifications CAPACITIES AND SPECIFICATIONS Capacities WARNING: The air conditioning refrigerant system contains refrigerant under high pressure. Only qualified personnel should service the air conditioning refrigerant system. Opening the air conditioning refrigerant system can cause personal injury. Item Capacity Engine oil (with oil filter).
Page 310 Capacities and Specifications Specifications Materials Name Specification Motor oil (U.S.): WSS-M2C946-B1 Motorcraft® SAE 5W-30 Premium Synthetic Blend Motor XO-5W30-Q1SP Motor oil (Canada): WSS-M2C946-B1 Motorcraft® SAE 5W-30 Super Premium Motor Oil CXO-5W30-LSP12 Engine coolant (U.S.): WSS-M97B44-D2 Motorcraft® Orange Prediluted Antifreeze/Coolant VC-3DIL-B Engine coolant (Canada): WSS-M97B44-D2 Motorcraft®...
Page 311 Capacities and Specifications Name Specification Motorcraft® MERCON® LV Automatic Transmission Fluid MERCON® LV CXT-10-LV12 Windshield washer fluid (U.S.): WSS-M14P19-A Motorcraft® Premium Windshield Wash Concentrate with Bitterant ZC-32-B2 Windshield washer fluid (Canada): WSS-M14P19-A Motorcraft® Premium Quality Windshield Washer Fluid CXC-37-(A, B, D, F) A/C refrigerant (U.S.): WSS-M17B21-A R-1234yf Refrigerant...
Page 312 Capacities and Specifications We recommend Motorcraft® motor oil for An oil that displays this symbol conforms your vehicle. If Motorcraft® oil is not to current engine, emission system and available, use motor oils of the fuel economy performance standards of recommended viscosity grade that meet ILSAC.
Page 313: Bulb Specification Chart
Capacities and Specifications E240523 BULB SPECIFICATION CHART Bulb Specification Power (Watts) Headlamp low beam. H11LL Headlamp high beam. HB3LL Headlamps. Front park/direction indicator bulb W21/5W 21/5 (Clear). Front park/direction indicator bulb 7444NA 28/8 (Amber). Front side marker bulb. Front fog lamp bulb. Front fog lamps.
Page 314 Capacities and Specifications Bulb Specification Power (Watts) Reverse lamp bulb - type 1. W21W Rear direction/park/stop lamp 3157K 26.9 bulb. Reverse lamp bulb - type 2. 3157K 26.9 License plate lamp. Center high mounted brake lamp. 12.8 Center high mounted brake lamp. Cargo lamp bulb.
Page 315: Audio System
Audio System • AM: 530-1710 kHz GENERAL INFORMATION • FM: 87.9-107.9 MHz Radio Frequencies and Reception Note: Listening to loud audio for long Factors periods of time could damage your hearing. AM and FM frequencies are established by the Federal Communications Commission (FCC) and the Canadian Radio and Telecommunications Commission (CRTC).
Page 316 Audio System Accessing the Phone Features Changing Radio Stations Press and release the button to access the phone features of the system. E265037 Accessing the Sound Settings Press and release the button to access settings for Treble, E265271 Midrange, Bass, Fade and Balance.
Page 317: Audio Unit - Vehicles With: Sync
Audio System Accessing the Apps Menu Press and release the function buttons below the display to select different Press and release the button to functions of the audio system depending access the apps menu. Follow on which mode you are in. E249410 the on-screen prompts to make your selection.
Page 318 Audio System Accessing the Sound Settings Listening to the Radio Press and release the button to Press and release the button to access settings for Treble, listen to the radio or change the Midrange, Bass, Fade and radio frequency band. Balance.
Page 319: Audio Unit - Vehicles With: Sync 3
Audio System Using the Display Control hand-held device while driving and encourage the use of voice-operated Use the up and down arrow buttons to systems when possible. Make sure you select the various settings. When you make are aware of all applicable local laws your selection, press the left and right that may affect the use of electronic arrow buttons to change the settings.
Page 320: Connecting A Bluetooth Device - Vehicles Without: Sync
Audio System Changing Radio Stations Using Seek, Fast Forward and Reverse In radio mode, select a frequency band and press and release either button. The system stops at the first station it finds in that direction. In satellite radio mode, press and release to select the next or previous satellite radio station.
Page 321: Radio
Audio System Note: Remove the antenna mast before RADIO entering a car wash. Make sure you firmly screw in the mast when reattaching it to Antenna maintain optimum radio reception. SATELLITE RADIO (IF EQUIPPED) SiriusXM® Satellite Radio broadcasts a variety of music, news, sports, weather, traffic and entertainment satellite radio channels.
Page 322 SiriusXM satellite radio system includes at any time, with or without notice to you. hardware and a limited subscription term, Ford Motor Company shall not be which begins on the date of sale or lease responsible for any such programming of your vehicle.
Page 323: Audio Input Jack
Audio System Message Condition Action No Signal The signal is lost from the The signal is blocked. When SiriusXM satellite or Siri- you move into an open area, usXM tower to your vehicle the signal should return. antenna. Updating… Update of channel No action required.
Page 324: Usb Port
Audio System The auxiliary input jack allows you to USB PORT (IF EQUIPPED) connect and play music from your portable music player through your vehicle speakers. You can use any portable music player designed for use with headphones. Your WARNING: Driving while audio extension cable must have male distracted can result in loss of vehicle connectors at each end.
Page 325: Media Hub
Audio System Note: This only works when connected via Bluetooth. See Connecting a Bluetooth Device (page 317). Note: When using voice pass through use the language set on the device. MEDIA HUB (IF EQUIPPED) WARNING: Driving while distracted can result in loss of vehicle control, crash and injury.
Page 326: Sync
SYNC support is available at your regional • Do not leave playing devices in your Ford website. See SYNC vehicle during extreme conditions as it Troubleshooting (page 332). could cause them damage. See your device's manual for further information.
Page 327: Using Voice Recognition
SYNC module. Ford Motor These voice commands are always Company and Ford of Canada will not available. You can say them at any time. access the system data for any purpose other than as described absent consent, a...
Page 328 SYNC (If Equipped) System Interaction and Feedback Helpful Hints • Make sure the interior of your vehicle is The system provides feedback through as quiet as possible. Wind noise from audible tones, prompts, questions and open windows and road vibrations may spoken confirmations depending on the prevent the system from correctly situation and the chosen level of...
Page 329: Using Sync With Your Phone
SYNC (If Equipped) To adjust this setting press the voice button, when prompted say: Voice Command Action and Description Voice Settings Then any of the following: Phone Confirmation Off When enabled, this feature will prompt you to confirm any voice initiated call command prior to the call being placed.
Page 330: Sync Applications And Services
SYNC (If Equipped) When prompted on your cell phone’s display, confirm that the PIN provided Voice Command by SYNC matches the PIN displayed ___ List of Commands on your cell phone. Your phone is now paired and the display indicates that Help the pairing was successful.
Page 331 SYNC (If Equipped) 911 Assist Note: Every phone operates differently. While SYNC 911 Assist works with most cellular phones, some may have trouble using this feature. WARNING: Unless the 911 Assist setting is set on before a crash, the If a crash deploys an airbag (excluding system will not dial for help which could knee airbags and rear inflatable safety delay response time, potentially...
Page 332 911 operator, and supported smartphone devices and then the occupant(s) in your vehicle are troubleshooting tips please visit the Ford able to talk with the operator. Be prepared website to provide your name, phone number and...
Page 333 SYNC (If Equipped) To Access Using the SYNC Menu Menu Action and Description Item Press the Mobile Apps button to access the menu on-screen. Then select: Mobile available applications and Apps select a particular app. Menu Action and Description Item Note: If you cannot find a compatible SYNC Find Scroll through the list of...
Page 334: Using Sync With Your Media Player
E142599 connected device. or tune to a radio station. When prompted, Data is sent to Ford in the United States say a command. See the following table through the connected device. The for example commands. Not all...
Page 335: Sync Troubleshooting
SYNC (If Equipped) Use your regional Ford website at any time Command to check your phone's compatibility, register your account and set preferences Sirius Channel ___ as well as access a customer representative via an online chat (during certain hours).
Page 336 SYNC (If Equipped) Phone issues Issue Possible cause(s) Possible solution(s) Try pushing your phonebook contacts to SYNC by using the Add Contacts feature. If the missing contacts are stored on your SIM card, try moving them to the device memory. Remove any pictures or The system says Phonebook special ring tones associ-...
Page 337 SYNC (If Equipped) Phone issues Issue Possible cause(s) Possible solution(s) This is a phone-dependent Go to the website to review feature. your phone's compatibility. Text messaging is not Try turning off the device, working on SYNC. This may be a possible resetting the device or phone malfunction.
Page 338 SYNC (If Equipped) USB and media issues Issue Possible cause(s) Possible solution(s) Make sure you correctly connect the device to SYNC, The device is not connected. and that you have pressed play on your device. Your music files may not contain the correct artist, Make sure that all song song title, album or genre...
Page 339 SYNC (If Equipped) Voice command issues Issue Possible cause(s) Possible solution(s) Say the song or artist exactly as listed. If you say "Play Artist Prince", the system does not play music by Prince and the Revolution You may be saying the or Prince and the New name differently than the Power Generation.
Page 340 SYNC (If Equipped) Voice command issues Issue Possible cause(s) Possible solution(s) The system works better if The system may not be you list full names, such as reading the name the same "Joe Wilson" rather than way you are saying it. "Joe".
Page 341 Possible solution(s) login on the app on the phone before using them with AppLink. Also, some may have a "Ford SYNC" setting, so check the app's settings menu on the phone. Closing and restarting apps may help SYNC find the application if you cannot discover it inside the vehicle.
Page 342 Force close or uninstall the a limited number of apps you do not want SYNC bluetooth ports apps can to find. If the app has a "Ford I can only see some of the use to connect. If you have SYNC" setting, disable that...
Page 343: General Information
SYNC (If Equipped) Getting to Know Your System GENERAL INFORMATION The SYNC 3 system allows you to interact with a variety of features using the touchscreen and voice commands. By WARNING: Driving while integrating with your Bluetooth enabled distracted can result in loss of vehicle phone, the touchscreen provides easy control, crash and injury.
Page 344 SYNC (If Equipped) Item Menu Item Action and Description Status Bar This bar displays icons and messages pertaining to current system activities including climate settings, voice commands and phone functions such as text messages. Home This button is available on the main screens. Pressing it takes you to the home screen view.
Page 345 SYNC (If Equipped) E270077 Callout Item Description Driver Temper- This shows the temperature the driver selects through ature the climate control system. Heated steering When you activate the heated steering wheel option wheel on the touch screen, this icon displays. It only displays when there is not a physical button for the heated (If equipped) steering wheel.
Page 346 SYNC (If Equipped) Callout Item Description Download This icon appears when SYNC 3 receives a software update. Pressing the icon shows more details about the new software. Wi-Fi This icon appears if a Wi-Fi network is connected. Wi-Fi in Range An available Wi-Fi network is within range.
Page 347 SYNC (If Equipped) Feature Bar Item Functions Apps Connect and control SYNC 3 compatible apps running on your iphone or android device. Also, access built-in additional features such as SiriusXM Traffic and Travel Link (if equipped). If your vehicle is a hybrid, plug-in hybrid, or electric this is also where your settings and power information is located.
Page 348 SYNC (If Equipped) Option Information View current route, next turn, time to your destination (depending on cluster level), distance to destination (depending on cluster level), and ability to cancel route. If you do not have an active navigation route programed, the compass is shown.
Page 349 SYNC (If Equipped) 911 Assist PHONE ACCEPT: Press to answer a call (If Equipped) or switch between calls. PHONE REJECT: Press to end a call or reject an incoming call. WARNING: Unless the 911 Assist setting is set on before a crash, the Note: On some models, SEEK NEXT may system will not dial for help which could be combined with PHONE REJECT and...
Page 350 SYNC during a crash, SYNC Website will search for and try to connect to a previously paired cell phone; SYNC will www.owner.ford.com then attempt to call the emergency www.syncmyride.ca services. www.syncmaroute.ca Before making the call: •...
Page 351 SYNC (If Equipped) 911 Assist May Not Work If • Do not attempt to service or repair the system. Have an authorized dealer • Your cellular phone or 911 Assist check your vehicle. hardware sustains damage in a crash. • Do not operate playing devices if the •...
Page 352 You can also schedule specific times to remotely start Website your vehicle so it’s ready to hit the road as www.owner.ford.com soon as you are. FordPass is available www.syncmyride.ca through a free download via the Apple App Store® or Google Play .
Page 353 To use the USB update you need to log into your owner account and visit the SYNC Menu Item software update page. Settings Website Wi-Fi www.owner.ford.com Available You can then select your www.syncmyride.ca Wi-Fi Wi-Fi network. You may www.syncmaroute.ca Networks...
Page 354 SYNC (If Equipped) Customer Assistance If you would like to switch this feature The SYNC support team is available to on later, select: help you with any questions you are not Menu Item able to answer on your own. Monday-Saturday, 8:30am-8:00pm EST. Settings United States: 1-800-392-3673.
Page 355: Home Screen
SYNC 3 module. Ford Motor Company, parties acting with lawful authority. Other Ford of Canada and The Lincoln Motor parties may seek to access the information Company do not access the system data independently of Ford Motor Company,...
Page 356: Using Voice Recognition
SYNC (If Equipped) Item Tile Home screen display If your vehicle does not have navigation, this space contains the compass. Phone The name of the connected phone appears on the screen. The status of the phone features also appear. This includes signal strength, battery charge, text messaging and roaming.
Page 357 SYNC (If Equipped) Voice Command Action and Description Phone List of Commands Navigation List of Commands Next Page You can use this command to view the next page of options on any screen where multiple pages of choices are given. Previous Page You can use this command to view the previous page of options on any screen where multiple pages of choices are given.
Page 358 SYNC (If Equipped) Voice command Description Play Podcast ___ Play Song ___ Play Audiobook ___ Browse ___ For USB audio only, you can say the name of an artist, album, or a genre to browse by that selec- tion. Your system must finish indexing before this option is available.
Page 359 SYNC (If Equipped) Press the voice button and say a command similar to the following: Voice command Description Call ___ Allows you to call a specific contact from your phonebook such as "Call Jenny". Call ___ at ___ Allows you to call a specific contact from your phonebook at a specific location such as "Call Jenny at Home".
Page 360 SYNC (If Equipped) Navigation Voice Commands point of interest. Equipped) ___ is a dynamic listing, meaning that for navigation voice commands it can be a POI Setting a Destination category or a major brand name, where major brand name is a chain with more You can use any of the following than 20 locations commands to set a destination or find a...
Page 361 SYNC (If Equipped) Voice command Description Where Am I Provides current location. Zoom in Allows you to zoom in on the map. Zoom out Allows you to zoom out from the map. Mobile App Voice Commands (If Equipped) The following voice commands are always available: Voice command Description Mobile Apps...
Page 362 SYNC (If Equipped) You can say the following commands to access SiriusXM Traffic and Travel Link: Voice command Description Show Traffic Displays a list of traffic incidents. Show Weather Map Displays the current weather map. Show Fuel Prices Displays a list of fuel prices. Show 5 Day Fore- Displays the 5 day weather forecast.
Page 363: Entertainment
SYNC (If Equipped) To disable this automatic fan speed reduction feature during voice sessions, press and hold the climate control AC and Recirculated air buttons simultaneously, release and then increase fan speed within 2 seconds. To re-enable this feature, repeat the above sequence.
Page 364 SYNC (If Equipped) Sources Note: Your vehicle may allow you to save presets from different audio sources on the Press this button to select the source of same page. media you want to listen to. You can access these options using the touchscreen or voice commands.
Page 365 SYNC (If Equipped) There are two preset banks available for SiriusXM satellite radio is a AM and three banks for FM. To access subscription-based satellite radio service additional presets, tap the preset button. that broadcasts a variety of music, sports, The indicator on the preset button shows news, weather, traffic and entertainment which bank of presets you are currently...
Page 366 SYNC (If Equipped) Menu Item Action and Description Replay Replay audio on the current channel. You can replay approx- imately 45 minutes of audio as long as you remain tuned to the current station. Changing stations erases the previous audio. Live When you are in replay mode, you are not able to select a different preset until you...
Page 367 SYNC (If Equipped) Troubleshooting Tips Message Cause Action Acquiring Signal Radio requires more than two No action required. This seconds to produce audio for message should disappear the selected channel. shortly. Satellite antenna fault There is an internal module or If this message does not clear system failure present.
Page 368 SYNC (If Equipped) HD Radio technology is the digital The HD logo is grey when acquiring a digital evolution of analog AM/FM radio. Your station, and then changes to orange when system has a special receiver that allows digital audio is playing. When this logo is it to receive digital broadcasts (where available, you may also see Title and Artist available) in addition to the analog...
Page 369 SYNC (If Equipped) HD Radio Reception and Station Troubleshooting Potential Reception Issues Reception area If you are listening to a multicast station and you are on the fringe of the reception area, the station may mute due to weak signal strength. If you are listening to HD1, the system changes back to the analog broadcast until the digital broadcast is available again.
Page 370 SYNC (If Equipped) Potential Station Issues Issues Cause Action Cannot access HD2 or The previously stored multicast No action required. The station HD3 multicast channel preset or direct tune is not is not available in your current when recalling a preset available in your current recep- location.
Page 371 SYNC (If Equipped) Button Function For MP3 CDs, this button allows you to toggle through repeat off, repeat one track (a small number one displays), and repeat current folder (a small folder displays). Shuffle Select the shuffle symbol to have the audio on the disk play in random order.
Page 372 SYNC (If Equipped) Button Function Playlists Artist Albums Songs Genres Podcasts Audio books Composers A-Z Jump This button allows you to choose a specific letter to view within the category you are browsing. Explore Device If available, this allows you to browse the folders and files on your USB device.
Page 373: Climate
SYNC (If Equipped) Supported USB file systems include: FAT, CLIMATE exFAT, and NTFS. Climate is optional for your vehicle. SYNC 3 is also able to organize the media from your USB device by metadata tags. Touch the climate button on the Metadata tags, which are descriptive touchscreen to access your climate control software identifiers embedded in the...
Page 374 SYNC (If Equipped) Callout Item Description Left-hand front Touch up or down to adjust the temperature. seat temper- ature: Heated steering Touch the heated steering wheel icon to switch the wheel: heated steering wheel on and off (if equipped). Defrost A pop up appears on the screen to display the defrost options.
Page 375 SYNC (If Equipped) Callout Item Description DUAL This button lights up when the passenger controls are active. To switch the dual zone operation off and link the passenger temperature to the driver temperature, touch the DUAL button to switch it off. Right-hand front Touch up or down to adjust the temperature.
Page 376: Phone
SYNC (If Equipped) 4. Confirm that the six-digit number PHONE appearing on your phone matches the six-digit number on the touchscreen. 5. The touchscreen indicates when the WARNING: Driving while pairing is successful. distracted can result in loss of vehicle 6.
Page 377 SYNC (If Equipped) Phone Menu Other features, such as text messaging using Bluetooth and automatic phonebook This menu becomes available after pairing download, are phone-dependent features. a phone. E251249 Item Menu Item Action and Description Recent Displays your recent calls. Call List You can place a call by selecting an entry from this list.
Page 378 SYNC (If Equipped) Item Menu Item Action and Description Phone Displays the name of your phone and takes you to the Settings phone settings options. From this menu, you can pair subsequent devices, set ring tones and alerts. Change Gives you access to the list of paired or connected Device Bluetooth devices allowing you to change or select a device.
Page 379 SYNC (If Equipped) To call a number in your contacts, To accept the call, select: select: Menu Item Menu Item Action and Description Accept Contacts You can then select the Note: You can also accept the call by name of the contact you pressing the phone button on the steering want to call.
Page 380 SYNC (If Equipped) Item Item Privacy Transfer the call to End Call Immediately end a the cell phone or phone call. You can back to SYNC 3. also press the button on the Text Messaging steering wheel. Note: Downloading and sending text Keypad Press this to access messages using Bluetooth are cell...
Page 381: Navigation
SYNC (If Equipped) 2. Follow the prompts on the To disable this feature from the touchscreen. Settings screen, select: 3. Follow the prompts that appear on your phone to allow access to Apple Menu Item CarPlay. Android Auto Preferences After completing the setup, your phone connects to CarPlay automatically when Your device is listed if SYNC detects plugged into a USB port.
Page 382 SYNC (If Equipped) 3D city models are complete 3D models Re-center the map by pressing of entire city areas including navigable this icon whenever you scroll the roads, parks, rivers and rendered buildings. map away from your vehicle’s 3D landmarks and city models appear in current location.
Page 383 SYNC (If Equipped) Button Button Start Destination Mode To set a destination, press: Menu Item Description Destination Enter a navigation destination in any of the following formats: Search Street Address (number, street, city, state) For example "12 Mainstreet Dearborn MI" Partial Address (number, street) if searching in current state (number, street and zip code (or postal code in Canada)) if searching...
Page 384 SYNC (If Equipped) Menu Item Description If you do not give an exact destination, a menu displays with your possible selections. Previous Destina- Collections of your last 40 navigation destinations display here. tions You can select any option from the list to select it as your destination. Delete Select this option to remove all previous destinations.
Page 385 SYNC (If Equipped) Menu Item Description Fuel Hotel See All Press to view additional categories. Once you have selected a category, follow the menus to find what you are looking for. Inside of these categories you can search by: Nearby Along Route Near Destination In a City...
Page 386 SYNC (If Equipped) Menu Item Action and Description During Route guidance, you can press the maneuver arrow icon on the map if you want the system to repeat route guidance instructions. When the system repeats the last guidance instruction, it updates the distance to the next guidance instruction, since it detects that the vehicle is moving.
Page 387 SYNC (If Equipped) Button When a route is not active, a list of nearby traffic incidents displays (if any are present). When a route is active, you can choose to display a list of traffic nearby or on the route. Navigation Press this button to adjust your preferences.
Page 388 SYNC (If Equipped) Menu Item Add Waypoint The waypoint list then appears and you are able to re-order all of your waypoints by selecting the menu icon on the right hand side of the location. You can select up to five waypoints.
Page 389: Apps
SYNC (If Equipped) For restaurants, cityseeker can provide The system calculates a reasonable information such as star rating, average efficient route based on available speed cost, review, handicap access, hours of limits, traffic, and road conditions. You may operation, and website address. know a local short cut that is more efficient at a given time than the route provided by For hotels, cityseeker can provide...
Page 390 Some apps will work automatically with no The connected device sends data to Ford setup. Other apps will want you to configure in the United States. The information is your personal settings and personalize your...
Page 391 SYNC 3. by SiriusXM Traffic and Travel Link. Note: If you disable group permissions, Note: Neither Sirius nor Ford is responsible apps will still be enabled to work with SYNC for any errors or inaccuracies in the SiriusXM 3 unless you deactivate All Apps in the Traffic and Travel Link services or its use in settings menu.
Page 392: Settings
SYNC (If Equipped) Menu Item Action and Description Traffic on Route Touch these buttons to identify traffic incidents on your route, near your vehicle’s current location or near any of your favorite Traffic Nearby places, if programmed. Fuel Prices Touch this button to view fuel prices at stations close to your vehicle’s location or on an active navigation route.
Page 393 SYNC (If Equipped) Sound Settings Speed Adjusts the amount the audio system volume increases with speed, Compensated or turns the feature off. Vol. Occupancy Mode Optimizes the sound based on the location of the listeners. Sound Settings Stereo Surround Your vehicle might not have all of these features. Media Player This button is available when a media device such as a Bluetooth Stereo or USB...
Page 394 SYNC (If Equipped) Menu Item Action and Description Gracenote® Data- This allows you to view the version level of the Gracenote Database. base Info Device Informa- This allows you to view the manufacturer and model number of your tion media device. Update Media Erase the stored in media information in order to re-index.
Page 395 To check your phone’s website: compatibility, see your phone’s manual or visit the website. Website owner.ford.com Alternatively, to add a phone, select: www.syncmyride.ca Menu Item www.syncmaroute.ca Add Phone Once you have paired a device you can Then select: adjust the following options.
Page 396 SYNC (If Equipped) Menu Item Action and Description Disconnect Make Primary Allows you to select this device to be your preferred device. Delete Removes the selected device from the system. Pressing the info icon next to the device name allows you to see phone and device information Menu Item Action and Description...
Page 397 SYNC (If Equipped) Menu Item Action and Description Text Messaging You can then select: No Alert No sound plays when a message comes to your phone. (Silence) You can select one of the three available notification sounds. Voice Readout When enabled, a voice prompt alerts you when you receive a new message.
Page 398 SYNC (If Equipped) Menu Item Action and Description FM HD Radio Activation of this feature allows you to listen to HD radio broadcasts. AM HD Radio (Dependent on current radio source, If Avail- able) Radio Text This feature is available when FM Radio is your active media source. Activate this feature to have the system display radio text.
Page 399 SYNC (If Equipped) Map Preferences Menu Item Action and Description Map Preferences Then select any of the following: 3D City Model When this option is active, the system shows 3D renderings of build- ings. Breadcrumbs When enabled, your vehicle’s previously traveled route displays with white dots.
Page 400 SYNC (If Equipped) Menu Item Second Level Messages, Actions and Descriptions Dynamic Route Enable or disable considering traffic information when planning a Guidance route. The system can find a faster route based on heavy traffic flow information or detect a Road Closed incident and find a detour route if possible.
Page 401 SYNC (If Equipped) Note: Standard data rates will apply. We are not responsible for any additional charges you may receive from your service provider, when your vehicle sends or receives data through the connected device. This includes any additional charges incurred due to driving in areas when roaming out of a home network.
Page 402 SYNC (If Equipped) Menu Item Action and Description Request Update All Apps Grant or deny permissions to all apps at once. There may also Grant or deny an individual app particular permissions. App permis- be SYNC 3 sions are organized into groups. By pressing the info book icon, you enabled apps can see which signals are included in each group.
Page 403 SYNC (If Equipped) Menu Item Action and Description Wi-Fi Enable this option to connect to Wi-Fi for SYNC 3 vehicle software updates. Available This provides you with a list of available Wi-Fi networks within range. Networks Clicking on a network from the list allows you to connect or disconnect from that network.
Page 404 SYNC (If Equipped) Ambient Lighting Note: Data you share, e.g. the Vehicle (If Equipped) Identification Number (VIN), SIM Card ID, Tap a color once to active ambient lighting. and data plan usage, between us and the This sets the color to the highest intensity. vehicle network carrier is used to provide the Vehicle Hotspot service in accordance You can drag the colors up and down to...
Page 405 SYNC (If Equipped) Onboard Modem Serial Number (ESN) shows you the ESN number for your system. You need this number for certain Selecting this button on the settings menu registrations such as Satellite Radio. Display To make adjustments using the touchscreen, select: Menu Item Action and Description Display Off...
Page 406: Sync 3 Troubleshooting
Note: If the system is locked and you refer to the tables below. cannot remember the PIN, please contact To check your cell phone's compatibility, the Customer Relationship Center. refer to the regional Ford or Lincoln United States: 1-800-392-3673 website. Canada: 1-800-565-3673 Cell phone issues...
Page 407: Sync
SYNC (If Equipped) Cell phone issues Issue Possible cause Possible solution During a call, I To restart your system, shut down the cannot hear the engine, open and close the door, and then The system may need to other person lock the door and wait for 2-3 minutes.
Page 408 SYNC (If Equipped) Cell phone issues Issue Possible cause Possible solution Switch the auto download setting off. This is a cell phone- Check your cell phone's compatibility. dependent feature. Possible cell phone Try switching your cell phone off, resetting malfunction. it or removing the battery, then try again.
Page 409 SYNC (If Equipped) USB and Bluetooth Stereo issues Issue Possible cause Possible solution Disconnect the device from SYNC 3. Try switching your device off, resetting it or removing the battery, then reconnect it to SYNC 3. Make sure you are using the manufacturer's Possible device malfunc- cable.
Page 410 SYNC (If Equipped) USB and Bluetooth Stereo issues Issue Possible cause Possible solution The file format is not Convert the file to a supported format. See supported by SYNC 3. Entertainment (page 360). The device needs to be Update media index. See Settings (page re-indexed.
Page 411 SYNC (If Equipped) Wi-Fi Access Point issues Issue Possible cause Possible solution Disconnecting Weak signal probably Position the vehicle close to the access after successful due to distance from the point with the front of the vehicle facing the connection. access point, obstruction access point direction and remove or high interference.
Page 412 SYNC (If Equipped) Wi-Fi Access Point issues Issue Possible cause Possible solution SYNC 3 is not SYNC 3 does not SYNC 3 currently does not provide an seen when currently provide a access point. searching for access point. Wi-Fi networks from your phone or other devices.
Page 413 AppLink. Also, some may have a "Ford SYNC" setting, so check the app's settings menu on the phone. Closing and restarting apps may help SYNC 3 find the application if you cannot discover it inside the vehicle.
Page 414 Some Android devices Force close or uninstall the apps you do not have a limited number of want SYNC 3 to find. If the app has a "Ford I can only see Bluetooth ports that SYNC" setting, disable that setting in the some of the apps can use to connect.
Page 415 SYNC (If Equipped) Voice command issues Issue Possible cause Possible solution Review the cell phone voice commands and the media voice commands at the beginning of their respective sections. You may be using the SYNC 3 does wrong voice commands. Refer to the audio display during an active not understand voice session to find a list of voice...
Page 416 SYNC (If Equipped) Voice command issues Issue Possible cause Possible solution SYNC 3 applies the phonetic pronunciation rules of the selected language to the The SYNC 3 contact names stored on your cell phone. voice control system is having You may not be saying Helpful Hint: You can select your contact trouble recog- the name exactly as it...
Page 417 SYNC (If Equipped) Personal Profiles Issue Possible cause and solution Personal Profiles have not been set up. An invalid profile name was entered. A memory button was not selected when prompted. I cannot create a profile. The vehicle’s ignition was not On and in Park or was shifted out of Run or Park while creating a profile.
Page 418 SYNC (If Equipped) Personal Profiles Issue Possible cause and solution The keyfob being used is not linked to a profile. The wrong keyfob is being used. A button other than unlock or remote start is being pressed on a linked keyfob. The Personal Profile was deleted.
Page 419 5 seconds the screen will go black. Allow 1-2 minutes for the system reset to complete. You may then resume using the SYNC 3 system. For additional assistance with SYNC 3 troubleshooting, refer to the regional Ford or Lincoln website. Ranger (TFG) Canada/United States of America, enUSA, Edition date: 201809, First-Printing...
Page 420: Accessories
• Bed mats. Ford Accessories are available for your • Bed rug*. vehicle through an authorized Ford dealer. Ford Motor Company will repair or replace • Bed trays. any properly authorized dealer-installed • Bluetooth speakers* . Ford Original Accessory found to be •...
Page 421 Ford Licensed • If you or an authorized Ford dealer add Accessories, and does not design or test any non-Ford electrical or electronic these accessories to Ford Motor accessories or components to your Company engineering requirements.
Page 422: Ford Protect
If you bring your car into your dealer for Vehicle Limited Warranty coverage. When service, we’ll give you a loaner to use for you visit your Ford Dealer, Insist on Ford the day. Protect extended service plans! Extended Rental Benefits...
Page 423 To learn This information is subject to change. For more, call our Ford Protect extended more information; visit your local Ford of service plan specialists at 800-367-3377. Canada dealer or www.ford.ca to find the...
Page 424: Scheduled Maintenance
If you do not use Ford authorized parts they you sell or trade it. Keep all receipts for may not meet our specifications and completed maintenance with your vehicle.
Page 425 When the oil change message appears in Additives and Chemicals the information display, it is time for an oil This owner's manual and the Ford change. Make sure you perform the oil Workshop Manual list the recommended change within two weeks or 500 mi additives and chemicals for your vehicle.
Page 426 Scheduled Maintenance Check Every Month Engine oil level. Function of all interior and exterior lights. Tires (including spare) for wear and proper pressure. Windshield washer fluid level. Fuel and water separator. Drain if necessary (or if indicated by the information display). Holes and slots in the tail pipe to make sure they are functional and clear of debris.
Page 427: Normal Scheduled Maintenance
Scheduled Maintenance Multi-Point Inspection Accessory drive belt(s) Hazard warning system operation Battery performance Horn operation Engine air filter Radiator, cooler, heater and air conditioning hoses Exhaust system Suspension components for leaks or damage Exterior lamps operation Steering and linkage Tires (including spare) for wear and proper Fluid levels ;...
Page 428 Scheduled Maintenance Intelligent Oil-Life Monitor Normal Maintenance Intervals At Every Oil Change Interval as Indicated by the Information Display Change engine oil and filter. Rotate tires, inspect tire wear and measure tread depth. Perform a multi-point inspection, recommended. Inspect the automatic transmission fluid level (if equipped with dipstick). Consult your dealer for requirements.
Page 429: Special Operating Conditions Scheduled Maintenance
Scheduled Maintenance Other Maintenance Items Replace spark plugs. Every 100,000 mi (160,000 km) Inspect accessory drive belt or belts. Change automatic transmission fluid and filter. Change front axle fluid. Four-wheel drive vehicles. Every 150,000 mi Change rear axle fluid. (240,000 km) Change transfer case fluid.
Page 430 Scheduled Maintenance Towing a Trailer or Using a Car-top Carrier As required Change engine oil and filter as indicated by the information display and perform services listed in the Normal Sched- uled Maintenance chart. Inspect frequently, service Inspect and lubricate U-joints. as required See axle maintenance items under Exceptions.
Page 431: Scheduled Maintenance Record
SCHEDULED MAINTENANCE useful life. Ford Motor Company, however, urges you to have all recommended RECORD maintenance services performed at the specified intervals and to record all vehicle service.
Page 432 Scheduled Maintenance Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Ranger (TFG) Canada/United States of America, enUSA, Edition date: 201809, First-Printing...
Page 433 Scheduled Maintenance Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Ranger (TFG) Canada/United States of America, enUSA, Edition date: 201809, First-Printing...
Page 434 Scheduled Maintenance Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Ranger (TFG) Canada/United States of America, enUSA, Edition date: 201809, First-Printing...
Page 435 Scheduled Maintenance Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Ranger (TFG) Canada/United States of America, enUSA, Edition date: 201809, First-Printing...
Page 436 Scheduled Maintenance Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Ranger (TFG) Canada/United States of America, enUSA, Edition date: 201809, First-Printing...
Page 437 Scheduled Maintenance Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Ranger (TFG) Canada/United States of America, enUSA, Edition date: 201809, First-Printing...
Page 438 Scheduled Maintenance Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Ranger (TFG) Canada/United States of America, enUSA, Edition date: 201809, First-Printing...
Page 439 Scheduled Maintenance Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Ranger (TFG) Canada/United States of America, enUSA, Edition date: 201809, First-Printing...
Page 440 Scheduled Maintenance Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Ranger (TFG) Canada/United States of America, enUSA, Edition date: 201809, First-Printing...
Page 441 Scheduled Maintenance Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Ranger (TFG) Canada/United States of America, enUSA, Edition date: 201809, First-Printing...
Page 442: Appendices
Appendices ELECTROMAGNETIC COMPATIBILITY WARNING: Keep antenna and power cables at least 4 in (10 cm) from any electronic modules and airbags. WARNING: Do not place objects Note: We test and certify your vehicle to or mount equipment on or near the meet electromagnetic compatibility airbag cover, on the side of the seatbacks legislation (UNECE Regulation 10 or other...
Page 443 Appendices E239122 Truck E239121 Ranger (TFG) Canada/United States of America, enUSA, Edition date: 201809, First-Printing...
Page 444: End User License Agreement
("DEVICES") that Check that electromagnetic fields include software licensed or owned by generated inside your vehicle cabin by the Ford Motor Company and its affiliates transmitter installed do not exceed ("FORD MOTOR COMPANY"). Those applicable human exposure requirements.
Page 445 SOFTWARE, except and/or services provide by or through and only to the extent that such activity FORD MOTOR COMPANY or its third is expressly permitted by applicable party software and service providers. law notwithstanding this limitation or...
Page 446 SOFTWARE Transfer: You may charges from your wireless service permanently transfer your rights under provider. If FORD MOTOR COMPANY this EULA only as part of a sale or or third party software and services transfer of the DEVICES, provided you...
Page 447 SOFTWARE), the accompanying printed Should you have any questions concerning materials, and any copies of the this EULA, or if you desire to contact FORD SOFTWARE, are owned by FORD MOTOR MOTOR COMPANY for any other reason, COMPANY, or its affiliates or suppliers. The please refer to the address provided in the SOFTWARE is licensed, not sold.
Page 448 Appendices SYNC® Automotive Important Safety • Distraction Hazard: Any navigation Information Read and follow features may require manual instructions: (non-verbal) setup. Attempting to perform such set-up or insert data • Before using your SYNC® system, read while driving can distract your attention and follow all instructions and safety and could cause an accident or other information provided in this end user...
Page 449 "AS IS" AND “AS AVAILABLE”, WITH ALL under any circumstances;(c) The FAULTS AND WITHOUT WARRANTY OF SOFTWARE may not be compatible ANY KIND, AND FORD MOTOR COMPANY with new or different versions of an HEREBY DISCLAIMS ALL WARRANTIES operating system, third party software,...
Page 450 Eastern District of Michigan. You hereby litigate any dispute in small claims court consent to submit to the personal in your county of residence or FORD jurisdiction of a court in the State of MOTOR COMPANY’S principal place of Michigan located in Wayne County and...
Page 451 AAA’s and arbitrator’s fees and forum will be conducted solely on an expenses. If you reject FORD MOTOR individual basis. Neither you nor FORD COMPANY’S last written settlement MOTOR COMPANY, will seek to have any...
Page 452 Appendices 1. Safe and Lawful Use filing, AAA, and arbitrator’s fees and expenses. It will not seek its attorney’s You acknowledge that devoting attention fees or expenses from you in any to the TeleNav Software may pose a risk arbitration. Fees and expenses are not of injury or death to you and others in counted in determining how much a situations that otherwise require your...
Page 453 Appendices 2. Account Information distribute, sublicense or otherwise transfer the TeleNav Software to You agree: (a) when registering the others, except as part of your TeleNav Software, to provide TeleNav with permanent transfer of the TeleNav true, accurate, current, and complete Software;...
Page 454 Appendices is dependent on the accuracy of REASON WHATSOEVER (INCLUDING, navigation, as the maps or functionality WITHOUT LIMITATION, ALL DAMAGES of the TeleNav Software are not REFERENCED HEREIN AND ALL intended to support such high risk DIRECT OR GENERAL DAMAGES IN applications, especially in more remote CONTRACT, TORT (INCLUDING geographical areas.
Page 455 Appendices to the exclusive jurisdiction of the conferred by implication, statute, courts of the County of Santa Clara, inducement, estoppel or otherwise, and California. The United Nations TeleNav and its suppliers and licensors Convention on Contracts for the hereby reserve all of their respective rights International Sale of Goods shall not other than the licenses explicitly granted apply.
Page 456 Appendices HERE holds a non-exclusive license from the United States Postal Service® to The headings in this Agreement are for publish and sell ZIP+4® information. convenience of reference only, will not be ©United States Postal Service® 2014. deemed to be a part of this Agreement, Prices are not established, controlled or and will not be referred to in connection approved by the United States Postal...
Page 457 Appendices Restrictions. Except where you have been PARTICULAR PURPOSE OR specifically licensed to do so by Telenav, NON-INFRINGEMENT. Some States, and without limiting the preceding Territories and Countries do not allow paragraph, you may not use this Data (a) certain warranty exclusions, so to that with any products, systems, or applications extent the above exclusion may not apply installed or otherwise connected to or in...
Page 458 Appendices export laws, rules or regulations prohibit HERE from complying with any of its NOTICE OF USE obligations hereunder to deliver or CONTRACTOR (MANUFACTURER/ distribute Data, such failure shall be excused and shall not constitute a breach SUPPLIER) NAME: HERE of this Agreement.
Page 459 Appendices 2. Copyright Notice: In connection with B. Canada Data. The following provi- each copy of all or any portion of the sions apply to the Data for Canada, Data for the Territory of Canada, Client which may include or reflect data from shall affix in a conspicuous manner the third party licensors (“Third Party following copyright notice on at least...
Page 460 Appendices either express or implied, arising by II. Mexico. The following provision applies law or otherwise, including but not to the Data for Mexico, which includes limited to, effectiveness, complete- certain data from the Instituto Nacional ness, accuracy or fitness for a de Estadística y Geografía (“INEGI”): particular purpose.
Page 461 Appendices A. Third Party Notices. Any and all copies V. Europe Territory of the Data and/or packaging relating thereto shall include the respective Third A. Use of Certain Traffic Codes in Europe Party Notices set forth below and used as described below corresponding to 1.
Page 462 Appendices is conditioned on Client’s obtaining prior Austria “© Bundesamt für Eich- written consent from Kartografie a.s.; und Vermessungswesen” (c) such license for selling or distributing Croatia with respect to Data for the Territory of Cyprus, Switzerland is conditioned on Client’s Estonia, obtaining a permit from Bundesamt für Latvia,...
Page 463 CARRIER AND END USER IS NOT A THIRD of the Data and/or packaging relating PARTY BENEFICIARY OF ANY thereto shall include the respective Third AGREEMENT BETWEEN FORD AND Party Notices set forth below and used UNDERLYING CARRIER. END USER as described below corresponding to...
Page 464 TO, DIRECTLY OR INDIRECTLY, SERVICES PROVIDED BY THE UNDERLYING CARRIER (iv) END USER UNDERSTANDS THAT OR ANY PERSON’S USE THEREOF, FORD AND THE UNDERLYING CARRIER INCLUDING CLAIMS ARISING IN WHOLE CANNOT GUARANTY THE SECURITY OF OR IN PART FROM THE ALLEGED...
Page 465 Appendices rigCustomer Remedies view it, and (ii) save it, provided that you do not remove any copyright notices that NAV2 and its suppliers’ entire liability and appear and do not modify the Data in any your exclusive remedy shall be, at NAV2’s way.
Page 466 Appendices Governing Law. FOR ANY LOSS OF PROFIT, REVENUE, CONTRACTS OR SAVINGS, OR ANY The above terms and conditions shall be OTHER DIRECT, INDIRECT, INCIDENTAL, governed by the laws of the People’s SPECIAL OR CONSEQUENTIAL DAMAGES Republic of China, without giving effect to ARISING OUT OF YOUR USE OF OR (i) its conflict of laws provisions, or (ii) the INABILITY TO USE THIS INFORMATION,...
Page 467 Appendices ("Gracenote Servers"), and to perform including any copyrighted material or other functions. You may use Gracenote music file information. You agree that Data only by means of the intended End Gracenote may enforce its respective User functions of this device. This device rights, collectively or separately, under this may contain content belonging to agreement against you, directly in each...
Page 468 Appendices Taiwan Territory IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A Note: In accordance with the management PARTICULAR PURPOSE, TITLE, AND approach of low-power radio wave NON-INFRINGEMENT. NEITHER radiation motors: GRACENOTE WARRANTS THE RESULTS THAT WILL BE OBTAINED BY YOUR USE Article 12: For approved and certified OF THE GRACENOTE SOFTWARE OR ANY low-power radiation motor models,...
Page 469 Appendices By using SUNA Products and/or Services, 5. Service Continuity and Reception of you will be deemed to have accepted and the SUNA Traffic Channel agreed to be bound by the terms and We will use reasonable endeavours to conditions fully detailed at: provide the SUNA Traffic Channel 24 hours a day, 365 days a year.
Page 470: Type Approvals
Appendices European Union EU TYPE APPROVALS Radio Frequency Certifications for Tire Pressure Monitoring Sensor(s) Argentina E207818 Ghana E207816 Brazil E253824 Jordan E253823 Malaysia E197509 Canada IC: 850K-11545917 E253822 IC: 2546A-FP3 Mexico E253812 Ranger (TFG) Canada/United States of America, enUSA, Edition date: 201809, First-Printing...
Page 471 Appendices Philippines E253813 Moldova E198001 Russia E197811 E253816 Morocco Serbia E207821 Oman E197844 Singapore E253817 E253820 Ranger (TFG) Canada/United States of America, enUSA, Edition date: 201809, First-Printing...
Page 472 Appendices South Africa United Arab Emirates E198002 E207817 South Korea United States of America FCC ID: OUC11545917 FCC ID: MRXFP3 Radio Frequency Certifications for Mid Range Radar E253819 Argentina Taiwan E269659 E203679 Ukraine E253818 Ranger (TFG) Canada/United States of America, enUSA, Edition date: 201809, First-Printing...
Page 473 Appendices Ghana South Africa E269662 E269664 Jordan United Arab Emirates E269660 E269663 Radio Frequency Certifications for Morocco Passive Anti-Theft System Argentina E269661 E274065 Ranger (TFG) Canada/United States of America, enUSA, Edition date: 201809, First-Printing...
Page 474 Appendices Brazil Ghana E269675 E269674 Canada Jamaica IC: 850K-11545917 Djibouti E274067 Jordan E274068 E269666 Ranger (TFG) Canada/United States of America, enUSA, Edition date: 201809, First-Printing...
Page 475 Appendices Malaysia Pakistan E269673 E275754 Morocco Serbia E269670 E269672 Paraguay Singapore E274066 E269676 Ranger (TFG) Canada/United States of America, enUSA, Edition date: 201809, First-Printing...
Page 476 Appendices South Africa United States of America FCC ID: OUC11545917 Vietnam E269667 Ukraine E269677 Radio Frequency Certifications for Radio Transceiver Module Canada IC: 3659A-F03AM315RX IC: 3659A-F04AM902TRX Djibouti E269671 United Arab Emirates E272192 E269668 Ranger (TFG) Canada/United States of America, enUSA, Edition date: 201809, First-Printing...
Page 477 Appendices Jamaica Pakistan E272193 E269684 Jordan E287633 Paraguay E272194 Morocco E272195 E269683 Ranger (TFG) Canada/United States of America, enUSA, Edition date: 201809, First-Printing...
Page 478 Appendices Serbia United Arab Emirates E269681 E272196 South Africa United States of America FCC ID: LTQF03AM315RX FCC ID: LTQF04AM902TRX Radio Frequency Certifications for Blind Spot Information System Canada RSS-310 compliant, per FCC Test report no.: 1-8707/14-01-03 Ghana E269685 Ukraine E269695 E269682 Ranger (TFG) Canada/United States of America, enUSA, Edition date: 201809, First-Printing...
Page 479 Appendices Malaysia United States of America FCC ID: OAYSRR3B Vietnam E269697 South Africa E269693 Radio Frequency Certifications for Wireless Charging United Arab Emirates E269696 United Arab Emirates E272903 E269694 Ranger (TFG) Canada/United States of America, enUSA, Edition date: 201809, First-Printing...
Page 480 Appendices China South Korea E273475 E291427 Radio Frequency Certifications for Radio Frequency Certifications for SYNC 3 Cruise Control Module Brazil Canada IC: 3432A-0065TR United States of America FCC ID: L2C0065TR Radio Frequency Certifications for Body Control Module E252722 Canada IC: 7812A-A2C738448 Model # : M : A2C750526 Model # : M : A2C750561 United States of America...
Page 481 Appendices IC: 3248A-A08TAA United States IC: 3248A-A08TDA FCC ID: NT8-16UP375AHU China E291429 E291430 United States of America FCC ID : M3N-A2C931423 FCC ID : M3N-A2C931426 FCC ID : N5F-A08TAA FCC ID : N5F-A08TDA Radio Frequency Statement for Audio Unit Canada IC: 3043A-UP375AHU Ranger (TFG) Canada/United States of America, enUSA, Edition date: 201809, First-Printing...
Page 482 Index Apps..............386 ..................386 SiriusXM Traffic and Travel Link....388 At a Glance............16 See: Four-Wheel Drive........151 Audible Warnings and Indicators.....86 Door Ajar..............86 Front and Rear Park Aid........86 Headlamps On............86 Key in Ignition............86 See: Climate Control.........108 Keyless Warning Alert........86 About This Manual...........7 Lane Departure Warning........86 About Trail Control........168 Parking Brake On..........86 Seatbelt Reminder..........86...
Page 483 Index Using the Display Control........316 SelectShift Automatic Using the Number Block........316 Transmission...........148 Audio Unit - Vehicles Without: Transmission Selector Lever SYNC..............312 Positions............147 Automatic Transmission Fluid Accessing the Clock Settings......312 Check............250 Accessing the Media Source Menu....312 Auto-Start-Stop...........134 Accessing the Menu...........312 Accessing the Phone Features......313 Disabling Auto-Start-Stop......135 Accessing the Sound Settings.......313 Enabling Auto-Start-Stop.......134...
Page 484 Index Cancelling the Set Speed......168 Checking MyKey System Status....56 Capacities and Specifications....306 MyKey Distance............56 Alternative Engine Oil for Extremely Cold Number of Admin Keys........57 Climates............309 Number of MyKeys..........56 Checking the Wiper Blades.....254 Specifications.............307 Cargo Lamps............73 Child Restraint and Seatbelt Car Wash Maintenance..........37 Child Restraint Positioning......28 See: Cleaning the Exterior.......261...
Page 485 Index System Errors............196 End User License Agreement....441 System Lights, Messages and Audible VEHICLE SOFTWARE END USER LICENSE Alerts..............195 AGREEMENT (EULA) ........441 Engine Coolant Check.......249 System Limitations..........196 Using the Cross Traffic Alert System..194 Adding Coolant..........249 Cruise Control..........64 Engine Emission Control......143 Engine Immobilizer Principle of Operation........176 Cruise control See: Passive Anti-Theft System.....62...
Page 486 Ford Protect...........419 General Maintenance Information..421 Ford Protect Extended Service Plan Multi-Point Inspection........423 (CANADA ONLY)..........420 Owner Checks and Services......422 Ford Protect Extended Service Plans (U.S. Protecting Your Investment......421 Only)..............419 Why Maintain Your Vehicle?......421 Four-Wheel Drive...........151 Why Maintain Your Vehicle at Your Principle of Operation........151...
Page 487 Index Home Screen..........352 Combining Seatbelt and LATCH Lower Hood Lock Anchors for Attaching Child See: Opening and Closing the Hood..245 Restraints............23 Horn..............65 Front Seat Tether Strap Attachment (SuperCab)............24 Rear Seat Tether Strap Attachment (SuperCab)............25 Ignition Switch..........130 Use of Inboard Lower Anchors from the Starting the Engine..........131 Outermost Seating Positions (Center Switching the Ignition Off.........131...
Page 488 Index Lighting..............68 Manual Tailgate..........207 General Information...........68 Lowering the Tailgate........207 Load Carriers Media Hub............322 Message Center See: Roof Racks and Load Carriers....205 Load Carrying..........201 See: Information Displays.........87 Load Limit............201 Mirrors Special Loading Instructions for Owners of See: Windows and Mirrors........74 Mobile Communications Equipment..13 Pick-up Trucks and Utility-type Motorcraft Parts..........302 Vehicles............205...
Page 489 Index Opening and Closing the Driver Side Window Automatically........75 Resetting the Memory of the Electric Parking Aids............170 Windows - Vehicle with One Touch Principle of Operation........170 Up/Down on Driver Side only.....76 Parking Brake..........160 Safety Mode............76 All Vehicles............160 Safety Switch for the Rear Windows....75 Vehicles With Automatic Pre-Collision Assist........197 Transmission...........160...
Page 490 Index Rear Seats............119 Roadside Assistance........218 Folding the Seat Backrest.......120 Vehicles Sold in Canada: Getting Roadside Folding the Seat Cushion.........119 Assistance............219 Unfolding the Seat Backrest......121 Vehicles Sold in the United States: Getting Unfolding the Seat Cushion......120 Roadside Assistance........218 Rear View Camera........172 Vehicles Sold in the United States: Using Camera guidelines..........173 Roadside Assistance........218...
Page 491 Index Navigation............395 SYNC 3............340 Phone..............391 General Information.........340 SYNC 3 Troubleshooting.....403 Radio..............394 SYNC Applications and Services..327 Sound..............389 Valet Mode............403 911 Assist...............328 Vehicle..............401 SYNC Mobile Apps..........329 SYNC ............323 Voice Control............402 Wi-Fi & Hotspot..........399 General Information..........323 Setting the Trail Control Speed....168 SYNC Troubleshooting......332 Side Airbags.............43 Sitting in the Correct Position....115 Snow Chains...
Page 492 Index Trail Control – Troubleshooting....169 Hilly Condition Usage........180 Trail Control – Information Overriding the Set Speed.........179 Messages............169 Resuming the Set Speed........180 Trailer Sway Control........209 Setting the Adaptive Cruise Speed....178 Transmission Code Designation....305 Setting the Gap Distance.........179 Transmission...........147 Switching Adaptive Cruise Control Transporting the Vehicle......222 Off................181 Type Approvals..........467...
Page 493 Index Audio Voice Commands.........354 Blind Spot Monitor..........83 Climate Voice Commands......355 Brake System Warning Lamp......83 Initiating a Voice Session........324 Cruise Control Indicator........84 Mobile App Voice Commands......358 Direction Indicator..........84 Navigation Voice Commands......357 Door Ajar Warning Lamp........84 Phone Voice Commands........355 Electronic Locking Differential......84 SiriusXM Traffic and Travel Link Voice Engine Coolant Temperature Warning Commands.............358...

Ford Ranger 2019 Owner's Manual

Introduction

Environment

At a Glance

Child Safety

Seatbelts

Personal Safety System?

Supplementary Restraints System

Keys and Remote Controls

Mykey

Doors and Locks

Security

Steering Wheel

Wipers and Washers

Lighting

Windows and Mirrors

Instrument Cluster

Information Displays

Climate Control

Seats

Garage Door Opener

Auxiliary Power Points

Storage Compartments

Starting and Stopping the Engine

Unique Driving Characteristics

Fuel and Refueling

Engine Emission Control

Transmission

Four-Wheel Drive

Rear Axle

Brakes

Traction Control

Stability Control

Terrain Control

Trail Control

Parking Aids

Cruise Control

Driving Aids

Load Carrying

Tailgate

Towing

Driving Hints

Roadside Emergencies

Customer Assistance

Fuses

Maintenance

Vehicle Care

Wheels and Tires

Capacities and Specifications

Audio System

Sync

Sync™ 3

Accessories

Ford Protect

Scheduled Maintenance

Quick Links

Troubleshooting

Related Manuals for Ford Ranger 2019

Summary of Contents for Ford Ranger 2019
