2017 FORD FOCUS RS
Owner's Manual Supplement

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FOCUS RS 2017 and is the answer not in the manual?

Questions and answers

Related Manuals for Ford FOCUS RS 2017

Summary of Contents for Ford FOCUS RS 2017

  • Page 1 2017 FORD FOCUS RS Owner's Manual Supplement...
  • Page 2 No part of this publication may be reproduced, transmitted, stored in a retrieval system or translated into any language in any form by any means without our written permission. Errors and omissions excepted. © Ford Motor Company 2016 All rights reserved. Part Number: HM5J 19A285 DA 201611 20161118083856...

  • Page 3: Table Of Contents

    Table of Contents Introduction Towing About This Supplement.........3 Towing a Trailer..........22 SVT.................3 Driving Hints Team RS...............3 Ford Performance..........4 Driving Through Water........23 Engine Overspeed..........23 At a Glance Engine Overboost...........23 Unique Features..........5 Roadside Emergencies Instrument Cluster Transporting the Vehicle......24 Gauges..............7 Fuses Warning Lamps and Indicators....7 Fuse Specification Chart......25...
  • Page 4 Table of Contents Suspension Specifications......40 Motorcraft Parts..........41 Transmission Code Designation....41 Capacities and Specifications....41 Scheduled Maintenance General Maintenance Information..45 2017 Focus RS (CEW) RS, Canada/United States of America, HM5J 19A285 DA enUSA, Edition date: 201611, First Printing...

  • Page 5: Introduction

    Thank you for choosing Ford Performance. to you on your vehicle. If you have owned or leased a Ford Performance vehicle before, welcome back. If this is your first Ford Performance vehicle, welcome to the family. We are...

  • Page 6: Ford Performance

    Team RS officially began working together your choice. as one team in 2009. In 2015, we combined them with Ford Racing to establish Ford Performance as one team responsible for all performance and racing oriented products and activities worldwide at Ford Motor Company.

  • Page 7: At A Glance

    At a Glance UNIQUE FEATURES E215060 High-flow, dual-mode exhaust system. Powertrain Enhanced torque vectoring control. 2.3L EcoBoost engine. All-wheel drive. High-capacity intercooler. 2017 Focus RS (CEW) RS, Canada/United States of America, HM5J 19A285 DA enUSA, Edition date: 201611, First Printing...
  • Page 8 At a Glance Chassis Brembo front brake calipers. Launch control. Drive modes. Dual-mode dampers. Exterior Radiator grille. Underbody shield. Diffuser. Spoiler. Light-weight aluminum or forged aluminum wheels. Michelin Pilot Super Sport or Michelin Pilot Sport Cup 2 tires. Interior Performance shift indicator. Sony 10-speaker audio system.

  • Page 9: Instrument Cluster

    Instrument Cluster GAUGES WARNING LAMPS AND INDICATORS Performance Shift Indicator It illuminates when the powertrain reaches the optimum upshift point. It flashes when the E218767 engine is close to hitting the engine speed limiter. E215771 Oil temperature gauge. Turbocharger boost gauge. Oil pressure gauge.

  • Page 10: Information Displays

    Information Displays possible acceleration when launching from GENERAL INFORMATION a standing start. Launch Control Note: When you switch the feature on, it is only active once. You must switch the The system configures the chassis and feature on each time it is required. powertrain systems to deliver the fastest To switch the feature on, do the following: Note: Your vehicle must be completely stationary.
  • Page 11 Information Displays All-Wheel Drive Message Action and Description AWD OFF Displays when the system has been automatically disabled to protect itself. This is caused by operating the vehicle with a severely mismatched tire installed, if the system is over- heating or if there is an issue with another vehicle system preventing AWD operation.

  • Page 12: Seats

    Seats MANUAL SEATS Repeatedly push the lever down to lower the seat. WARNING Rotate the handle or move the Make sure the seat fully locks into lever to recline the seatback. place by rocking it backward and forward. E215587 Lift the handle to move the seat backward and forward.

  • Page 13: Fuel And Refueling

    Fuel and Refueling Fuels containing the octane booster FUEL QUALITY additive, methylcyclopentadienyl manganese tricarbonyl (MMT). Choosing the Right Fuel Leaded fuel (using leaded fuel is prohibited by law). The use of fuels with metallic compounds such as methylcyclopentadienyl manganese tricarbonyl (commonly known as MMT), which is a manganese-based fuel additive, will impair engine performance and affect the emission...

  • Page 14: Transmission

    Transmission MANUAL TRANSMISSION The manual transmission has a starter interlock that prevents cranking the engine unless you fully press the clutch pedal. Due to the high performance of the powertrain, a certain amount of noise from the transmission is normal. Note: During each shift, you must fully press the clutch pedal to the floor and fully release the accelerator.

  • Page 15: All-Wheel Drive

    All-Wheel Drive Using Mismatched Tires or Wheels USING ALL-WHEEL DRIVE WARNINGS Your vehicle has All-Wheel Drive with Only use replacement tires and Dynamic Torque Vectoring. This feature wheels that are of the same size, uses all four wheels to power the vehicle load index, speed rating and type as and independently controls the torque to those originally fitted to your vehicle.
  • Page 16 All-Wheel Drive Major mismatched tire or wheel sizes sharply. It may be better to strike small between the front and rear axles, for objects, for example highway reflectors, example 18 inch low profile tires on the with minor damage to your vehicle rather front axle and 20 inch high profile tires on than attempt a sudden return to the road the rear axle could cause the system to...
  • Page 17 All-Wheel Drive Note: Do not rock the vehicle if the engine has adequately cooled and the engine has is not at normal operating temperature or been restarted, the message turns off and damage to the transmission may occur. normal all-wheel drive function returns. If you do not switch the engine off, the Note: Do not rock the vehicle for more than message only turns off, when the system...
  • Page 18 All-Wheel Drive Hilly or Sloping Terrain Snow and Ice WARNING WARNING Avoid driving across or turning on If you are driving in slippery steep hilly or sloping terrain. Your conditions that require tire chains or vehicle may lose traction and slip cables, then it is critical that you drive sideways increasing the risk of rolling over.
  • Page 19 All-Wheel Drive Avoid sudden braking while driving on snow or icy roads. Although your vehicle may accelerate better than a two-wheel drive vehicle on snow and ice, stopping distances are not reduced. Make sure you allow sufficient distance for stopping. Drive slower than usual and consider using a lower gear.

  • Page 20: Brakes

    Brakes GENERAL INFORMATION Your vehicle has a braking system designed for high performance driving and superior brake fade resistance. You may notice occasional brake noise and elevated levels of brake dust. This is normal and does not affect system performance. 2017 Focus RS (CEW) RS, Canada/United States of America, HM5J 19A285 DA enUSA, Edition date: 201611, First Printing...

  • Page 21: Stability Control

    Stability Control Switching the System Off USING STABILITY CONTROL Press and hold the switch for WARNINGS approximately five seconds. You will see Do not switch off stability control or a message in conjunction with an use Sport, Track or Drift mode when illuminated icon in the display.

  • Page 22: Driving Aids

    Driving Aids Sport DRIVE CONTROL Vehicle settings tuned for WARNING performance street driving. Do not use Sport, Track or Drift mode Electronic stability control and traction when using a temporary spare wheel control systems fully enabled. or after inflating a tire using the temporary mobility kit.
  • Page 23 Driving Aids The electronic stability control or all-wheel Press and hold the button for a short drive system may automatically turn off period of time. The current setting during extreme drifting maneuvers. If a appears in the information display. system turns off, the electronic stability Release the button again to change the control warning lamp illuminates or a setting.

  • Page 24: Towing

    Towing TOWING A TRAILER WARNING Your vehicle is not approved for trailer towing. Never tow a trailer with your vehicle. 2017 Focus RS (CEW) RS, Canada/United States of America, HM5J 19A285 DA enUSA, Edition date: 201611, First Printing...

  • Page 25: Driving Hints

    Driving Hints DRIVING THROUGH WATER ENGINE OVERBOOST Your vehicle has aerodynamic devices Your vehicle has an engine overboost attached to the underbody designed to feature to allow additional torque delivery. help control airflow for superior The overboost feature controls a variety performance.

  • Page 26: Roadside Emergencies

    Roadside Emergencies TRANSPORTING THE VEHICLE If your vehicle has to be towed, we recommend that you contact a professional towing service. If you are a member of a roadside assistance program, we recommend that you contact your roadside assistance service provider. We recommend the use of flatbed equipment to transport your vehicle.

  • Page 27: Fuses

    Fuses FUSE SPECIFICATION CHART Engine Compartment Fuse Box E129925 Fuse Fuse Rating Circuit Protected Rear drive unit control. Fuel pump electronic module 2 feed. 7.5A Exhaust valve. Relay Circuit Switched Fuel pump electronic module 2 feed. Cooling fan control 5. Cooling fan control 4.
  • Page 28 Fuses Luggage Compartment Fuse Box E129927 Fuse Fuse Rating Circuit Protected Fuel control relay. Damper control relay. Active noise control. Electronic sound enhancement. Relay Circuit Switched Fuel control module. Damper control module. 2017 Focus RS (CEW) RS, Canada/United States of America, HM5J 19A285 DA enUSA, Edition date: 201611, First Printing...

  • Page 29: Maintenance

    Maintenance UNDER HOOD OVERVIEW E213537 Engine coolant reservoir. Engine oil dipstick. See Engine Oil Dipstick (page 28). Engine oil filler cap. Brake fluid reservoir. Battery. Engine compartment fuse box. See Fuses (page 25). Air filter. See Changing the Engine Air Filter (page 28). Washer system fluid reservoir.

  • Page 30: Engine Oil Dipstick

    Maintenance ENGINE OIL DIPSTICK E169062 Minimum. Maximum. CHANGING THE ENGINE AIR FILTER WARNING To reduce the risk of vehicle damage and personal burn injuries, do not start your engine with the air cleaner removed and do not remove it while the engine is running.

  • Page 31: Drive Belt Routing

    Maintenance 4. Wipe any dirt or debris from the air filter housing and cover to make sure no dirt gets in the engine and that you have a good seal. 5. Install a new air filter element. Note: Make sure you align the locating tab on the air filter element with the fork in the air filter housing.

  • Page 32: Track Use

    Track Use Before Track Use We recommend that you only operate your vehicle at high speeds at locations Before operating your vehicle on a track, designed to do so safely. Your vehicle has check the following: electronic controls that may reduce power or limit engine speed to help reduce Tire pressures.

  • Page 33: Vehicle Care

    Vehicle Care CLEANING THE EXTERIOR Washing Your Vehicle Your vehicle has heat exchangers integrated with the front fascia designed to maximize performance. Do not apply a power washer or high pressured spray nozzle directly to the heat exchangers as damage to the cooling fins could occur.

  • Page 34: Wheels And Tires

    Wheels and Tires To avoid damaging the wheels: WHEELS Maintain correct tire pressures. See Your vehicle has unique wheels. They can Tire Pressures (page 35). be more susceptible to damage from poor When installing wheels, always use a road conditions due to their diameter, torque wrench and tighten the lug nuts width and the use of low profile tires.

  • Page 35: Tires

    Wheels and Tires Take extra caution when operating on TIRES rough roads to avoid impacts that could cause tire damage. The tires on your vehicle are designed to optimize its performance. They are not Inspect the tires for damage on a optimized for off-road or winter regular basis.

  • Page 36: Using Summer Tires

    Wheels and Tires Note: Always inspect the tires after storage USING SUMMER TIRES periods and before use. The original equipment tires on your vehicle are designed to optimize its performance USING WINTER TIRES in dry or wet summer road conditions. The rubber compounds used in these tires lose The original equipment tires on your vehicle flexibility and may develop surface cracks...

  • Page 37: Tire Pressures

    Wheels and Tires TIRE PRESSURES Check all tire pressures when they are cold, at least once every two weeks. Check them after the vehicle has been parked for at least three hours. Tire pressure can diminish over time and fluctuate with temperature.

  • Page 38: Capacities And Specifications

    Capacities and Specifications ENGINE SPECIFICATIONS Dimension Description Specification Engine capacity. 138.0 in³ (2,261.4 cm³) Engine bore. 3.4 in (87.5 mm) Engine stroke. 3.7 in (94 mm) Compression ratio. 9.4:1 Ignition firing order. 1-3-4-2 Ignition system. Coil on spark plug Spark plug gap. 0.030 in (0.75 mm) Maximum net power kW/RPM.

  • Page 39: Transmission Specifications

    Capacities and Specifications TRANSMISSION SPECIFICATIONS Transmission and final drive ratios 6-Speed Manual Transmission - MMT6 Gear Gear Ratio Final Drive Ratio 1st gear. 3.23 4.063 2nd gear. 1.95 4.063 3rd gear. 1.32 4.063 4th gear. 1.03 4.063 5th gear. 1.13 2.955 6th gear.

  • Page 40: Brake System Specifications

    Capacities and Specifications BRAKE SYSTEM SPECIFICATIONS Dimension Description in (mm) Brake pedal free travel. 0.4–1.2 (10–30) Front brake disc minimum thickness. 0.9 (23) Rear brake disc minimum thickness. 0.4 (9) 2017 Focus RS (CEW) RS, Canada/United States of America, HM5J 19A285 DA enUSA, Edition date: 201611, First Printing...

  • Page 41: Steering Specifications

    Capacities and Specifications STEERING SPECIFICATIONS Wheel Alignment Dimension Description Specification Front wheel - Total Toe. 0.20° ±0.20° Rear wheel - Total Toe. 0.30° ±0.20° Turning Circle Dimension Description Specification Minimum turning circle. 39.4 ft (12 m) 2017 Focus RS (CEW) RS, Canada/United States of America, HM5J 19A285 DA enUSA, Edition date: 201611, First Printing...

  • Page 42: Suspension Specifications

    Capacities and Specifications SUSPENSION SPECIFICATIONS Dimension Description Specification Front camber. -1.51° (±1.25°) Front caster. 4.79° (±1°) Rear camber. -0.97° (±1.25°) Front suspension. Macpherson strut. Rear suspension. Multilink. Front spring rate. 40 N/mm Rear spring rate. 44 N/mm Front stabilizer bar. 24.2 mm Rear stabilizer bar.

  • Page 43: Motorcraft Parts

    SAE/USCAR-36. We recommend that you contact an authorized dealer for spark plug replacement. We recommend that you demand the use TRANSMISSION CODE of genuine Ford and Motorcraft parts DESIGNATION whenever your vehicle requires scheduled maintenance or repair. Genuine Ford and...
  • Page 44 21.16 oz (0.6 kg) Air conditioning refrigerant compressor oil fill capacity. 4.40 fl oz (130 ml) Specifications Adding Engine Oil Only use fluid that meets Ford specifications. Quantity 0.9 qt (0.85 L) The quantity of engine oil required to raise the indicated level on the dipstick from minimum to maximum.
  • Page 45 Capacities and Specifications Name Specification PM-20 (U.S. & Canada) Motorcraft® Dual Clutch Transmission Fluid (U.S.) WSS-M2C200-D2 Dual Clutch Transmission Fluid / Huile pour boîtes embrayage double (Canada) XT-11-QDC (U.S. & Canada) Motorcraft® SAE 75W-140 Synthetic Rear Axle Lubricant (U.S.) WSL-M2C192-A Motorcraft®...
  • Page 46 Capacities and Specifications Do not use supplemental engine oil additives because they are unnecessary and could lead to engine damage that may not be covered by the vehicle Warranty. E142732 If you are unable to find an engine oil that meets the specification defined by WSS-M2C931-C, it is acceptable to use a motor oil of the recommended viscosity...

  • Page 47: Scheduled Maintenance

    Scheduled Maintenance GENERAL MAINTENANCE INFORMATION Protecting Your Investment Your vehicle is equipped with an intelligent oil life monitoring system. Under normal operating conditions, a message appears in the information display to indicate the regular oil change interval. High performance vehicles tend to be driven in such a way that the engine experiences high speed and high load.
