PRODUCT NO.
FAK083J7V2
WIRING DIAGRAM - # A232012
OWNER'S GUIDE - # 309000825
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O.BOX 212378, AUGUSTA, GA 30917
FACTORY PARTS CATALOG
BASE MODEL NO.
MARKET
FAK083J7V
USA
Publication No.
5995349908
-EN/SERVICE /DJH
ROOM AIR CONDITIONER
BTU-COOLING
8000BTU
ROOM AIR CONDITIONER
010215
345
©2001 White Consolidated Industries, Inc.
All rights reserved
Model No.
FAK083J7V2
Advertisement
Related Manuals for Frigidaire FAK083J7V2
Summary of Contents for Frigidaire FAK083J7V2
-
Page 1: Room Air Conditioner
PRODUCT NO. BASE MODEL NO. FAK083J7V2 FAK083J7V WIRING DIAGRAM - # A232012 OWNER’S GUIDE - # 309000825 ELECTROLUX HOME PRODUCTS NORTH AMERICA P.O.BOX 212378, AUGUSTA, GA 30917 FACTORY PARTS CATALOG ROOM AIR CONDITIONER MARKET BTU-COOLING 8000BTU ROOM AIR CONDITIONER FAK083J7V2 Publication No. - Page 2 Publication No. FAK083J7V2 5995349908 CABINET FRONT AND WRAPPER 08/01...
- Page 3 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FAK083J7V2 CABINET FRONT AND WRAPPER PART NO DESCRIPTION 309622004 Cabinet,sleeve ,complete assy 5303317604 Grille,rear 5304414087 Link-vertical louver 309622204 Louver horizontal 309622504 Louver Horizontal assy 309622103 Louver-vertical,4 309622104 Louver-vertical w/handle,(1) 309622304...
- Page 4 Publication No. FAK083J7V2 5995349908 CONTROLS 08/01...
- Page 5 POS. NO 13 # 17 # # = Fast-moving Parts * = Non-Illustrated Parts FAK083J7V2 CONTROLS PART NO DESCRIPTION 309606501 Panel-mounting,controls 5303323284 Switch-selector 5304409252 Control temperature 309321201 Clip-control bulb 5303303125 Capacitor,370 V ,35+5 microfarad 5303303077 Strap-capacitor 309343105 Cord-service 309625301 Door-ventilator,assembly...
- Page 6 Publication No. FAK083J7V2 5995349908 AIR HANDLING PARTS 08/01...
- Page 7 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FAK083J7V2 AIR HANDLING PARTS PART NO DESCRIPTION 309625201 Blower Wheel,plastic 309620501 Housing-fan 309626001 Fan Blade 309617704 Motor-fan 309112101 Clamp-blower 5303012110 Clamp-blower 309624801 Housing-blower 309624601 Plate-scroll,housing-blower 5303313964 Seal,condenser ,upper 309624901 Adapter,housing-blower Publication No.
- Page 8 Publication No. FAK083J7V2 5995349908 COMPRESSOR PARTS 08/01...
- Page 9 POS. NO 10 # 11 # 12 # 16 # 17 # # = Fast-moving Parts * = Non-Illustrated Parts FAK083J7V2 COMPRESSOR PARTS PART NO DESCRIPTION 5304406829 Compressor,san 806-551-42 5303015945 Grommet,compressor ,(3) 5303015946 Nut,plastic ,compressor ,(3) 3200282 Gasket-cover 3200281 Cover-terminal...
- Page 10 Publication No. 5995349908 POS. NO 08/01 FAK083J7V2 WINDOW MOUNTING PARTS PART NO DESCRIPTION 5303313968 Seal,frame ,top 5304407729 Seal-window frame,stuffer 5303211056 Bracket 5304414113 Bracket support,NSC1403 GREY 5308047516 Panel-window,plastic 5304414118 Frame,expander slide 5304414119 Divider frame 309313602 Assy frame slide 5304414112 Retainer,window panel...
- Page 11 FAK083J7V2 Publication No. 5995349908 WIRING DIAGRAM # = Fast-moving Parts 08/01 * = Non-Illustrated Parts...
