Table of Contents
Advertisement
Quick Links
PRODUCT NO.
BASE MODEL NO.
FAK083J7V3
FAK083J7V
MARKET
USA
WIRING DIAGRAM - # A232012
OWNER'S GUIDE - # 309000816
ENERGY GUIDE - # 309367404
ELECTROLUX HOME PRODUCTS, INC
P.O.BOX 212378, AUGUSTA, GA 30917
FACTORY PARTS CATALOG
ROOM AIR CONDITIONER
VOLTS
BTU-COOLING
115
8000 BTU
Publication No.
5995367900
020309
©2002 Electrolux Home Products, Inc.
-EN/SERVICE /BLT
All rights reserved
345
ROOM AIR CONDITIONER
Model No.
FAK083J7V3
Advertisement
Table of Contents
Related Manuals for Frigidaire FAK083J7V3
Summary of Contents for Frigidaire FAK083J7V3
-
Page 1: Room Air Conditioner
PRODUCT NO. BASE MODEL NO. FAK083J7V3 FAK083J7V MARKET WIRING DIAGRAM - # A232012 OWNER’S GUIDE - # 309000816 ENERGY GUIDE - # 309367404 ELECTROLUX HOME PRODUCTS, INC P.O.BOX 212378, AUGUSTA, GA 30917 FACTORY PARTS CATALOG ROOM AIR CONDITIONER VOLTS BTU-COOLING... -
Page 2: Cabinet Front And Wrapper
Publication No. FAK083J7V3 5995367900 CABINET FRONT AND WRAPPER 03/02... - Page 3 Grille,rear 5304414087 Link,vertical louver 309622504 Louver Assy,Incl-7,8,9,10 309622204 Louver,horizontal 309622103 Louver,vertical 309622104 Louver,vertical ,w/handle 309622304 Filter,air ,front 309622404 Front Assy,complete ,7,8,9,10,12,43 309622609 Dial Plate 309307013 Knob,control 3015312 Screw,8-18AB x 0.500 309621804 Frame,cabinet front 309367404 Energy Guide,FAK083J7V3 Publication No. 5995367900 03/02...
- Page 4 Publication No. FAK083J7V3 5995367900 CONTROLS 03/02...
- Page 5 POS. NO 13 # 17 # # = Fast-moving Parts * = Non-Illustrated Parts FAK083J7V3 CONTROLS PART NO DESCRIPTION 309606501 Panel-mounting,controls 5303323284 Switch,selector ,7 posn,3 speed 5304409252 Control temperature 309321201 Clip,temp sensor mtg ,thermostat 5304427231 Capacitor,370 V ,35+4 microfarad 5303285199 Screw,Ph truss hd ,8-18 x 0.38 ,ground...
-
Page 6: Air Handling Parts
Publication No. FAK083J7V3 5995367900 AIR HANDLING PARTS 03/02... - Page 7 POS. NO 11 # # = Fast-moving Parts * = Non-Illustrated Parts FAK083J7V3 AIR HANDLING PARTS PART NO DESCRIPTION 309626001 Fan Blade 309642301 Housing,fan shroud 309646002 Motor,fan 3202975 Screw,10-16AB x 0.72 ,square drive 309625201 Blower Wheel,plastic 5303012110 Clamp,blower wheel mt...
-
Page 8: Compressor Parts
Publication No. FAK083J7V3 5995367900 COMPRESSOR PARTS 03/02... - Page 9 POS. NO 10 # 11 # 12 # 16 # 17 # 03/02 COMPRESSOR PARTS PART NO DESCRIPTION 5304406829 Compressor 5303283877 Grommet,compressor mtg ,(3) 5308006948 Nut,compressor mtg ,(3) 3200282 Gasket,terminal cover 3200281 Cover,compr terminal 3202920 Overload Protector 5303211017 Nut,terminal cover ,compressor elec 5303317601 Start Assist Kit,compressor 309617003...
- Page 10 Publication No. FAK083J7V3 5995367900 WINDOW MOUNTING PARTS 03/02...
- Page 11 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FAK083J7V3 WINDOW MOUNTING PARTS PART NO DESCRIPTION 5303313968 Seal,frame ,top 5304407729 Seal,window stuffer 5303211056 Bracket,sash lock 5304414113 Support,mounting plate 5304411997 Screw,8-18 x 0.750 309335103 Panel,window ,crctd. plastic 3015312 Screw,8-18AB x 0.500...
-
Page 12: Wiring Diagram
Publication No. FAK083J7V3 5995367900 WIRING DIAGRAM 03/02...
