PRODUCT NO.
BASE MODEL NO.
FAK103J1V3
FAK103J1V3
MARKET
USA
WIRING DIAGRAM - # A232012
OWNER'S GUIDE - # 309000816
ENERGY GUIDE - # 309367405
ELECTROLUX HOME PRODUCTS, INC
P.O.BOX 212378, AUGUSTA, GA 30917
FACTORY PARTS CATALOG
ROOM AIR CONDITIONER
VOLTS
BTU-COOLING
115
10000 BTU
Publication No.
5995367918
020309
©2002 Electrolux Home Products, Inc.
-EN/SERVICE /BLT
All rights reserved
345
ROOM AIR CONDITIONER
Model No.
FAK083J1V3
Advertisement
Table of Contents
Related Manuals for Frigidaire FAK103J1V3
Summary of Contents for Frigidaire FAK103J1V3
-
Page 1: Room Air Conditioner
PRODUCT NO. BASE MODEL NO. FAK103J1V3 FAK103J1V3 MARKET WIRING DIAGRAM - # A232012 OWNER’S GUIDE - # 309000816 ENERGY GUIDE - # 309367405 ELECTROLUX HOME PRODUCTS, INC P.O.BOX 212378, AUGUSTA, GA 30917 FACTORY PARTS CATALOG ROOM AIR CONDITIONER VOLTS BTU-COOLING... -
Page 2: Cabinet Front And Wrapper
Publication No. FAK103J1V3 5995367918 CABINET FRONT AND WRAPPER 03/02... - Page 3 Grille,rear 5304414087 Link,vertical louver 309622204 Louver,horizontal 309622504 Louver Assy,Incl-7,8,9,10 309622103 Louver,vertical 309622104 Louver,vertical ,w/handle 309622304 Filter,air ,front 309622404 Front Assy,complete ,7,8,9,10,12,43 309622609 Dial Plate 309307013 Knob,control 3015312 Screw,8-18AB x 0.500 309621804 Frame,cabinet front 309367405 Energy Guide,FAK103J1V3 Publication No. 5995367918 03/02...
- Page 4 Publication No. FAK103J1V3 5995367918 CONTROLS 03/02...
- Page 5 POS. NO 13 # 17 # # = Fast-moving Parts * = Non-Illustrated Parts FAK103J1V3 CONTROLS PART NO DESCRIPTION 309606501 Panel-mounting,controls 5303323284 Switch,selector ,7 posn,3 speed 5304409252 Control temperature 309321201 Clip,temp sensor mtg ,thermostat 5304416302 Capacitor,370 V ,40+15 uF 5303285199 Screw,Ph truss hd ,8-18 x 0.38 ,ground...
-
Page 6: Air Handling Parts
Publication No. FAK103J1V3 5995367918 AIR HANDLING PARTS 03/02... - Page 7 POS. NO 11 # # = Fast-moving Parts * = Non-Illustrated Parts FAK103J1V3 AIR HANDLING PARTS PART NO DESCRIPTION 309626001 Fan Blade 309642301 Housing,fan shroud 309646001 Motor,fan 3202975 Screw,10-16AB x 0.72 ,square drive 309625201 Blower Wheel,plastic 5303012110 Clamp,blower wheel mt...
-
Page 8: Compressor Parts
Publication No. FAK103J1V3 5995367918 COMPRESSOR PARTS 03/02... - Page 9 POS. NO 10 # 11 # 12 # 17 # 03/02 COMPRESSOR PARTS PART NO DESCRIPTION 5304414964 Compressor 5303283877 Grommet,compressor mtg ,(3) 5308006948 Nut,compressor mtg ,(3) 3200282 Gasket,terminal cover 3200281 Cover,compr terminal 5303203064 Overload Protector 5303211017 Nut,terminal cover ,compressor elec 5303317601 Start Assist Kit,compressor 309617009...
- Page 10 Publication No. FAK103J1V3 5995367918 WINDOW MOUNTING PARTS 03/02...
- Page 11 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FAK103J1V3 WINDOW MOUNTING PARTS PART NO DESCRIPTION 5303313968 Seal,frame ,top 5304407729 Seal,window stuffer 5303211056 Bracket,sash lock 5304414113 Support,mounting plate 5304411997 Screw,8-18 x 0.750 309335103 Panel,window ,crctd. plastic 3015312 Screw,8-18AB x 0.500...
-
Page 12: Wiring Diagram
Publication No. FAK103J1V3 5995367918 WIRING DIAGRAM 03/02...
