PRODUCT NO.
FAK083J7V1
WIRING DIAGRAM # - A232012
OWNERS GUIDE # - 309000816
P.O. Box 212378
Augusta, GA 30917
FACTORY PARTS CATALOG
ROOM AIR CONDITIONER
BASE MODEL NO.
FAK083J7V
Publication No.
5995338836
000413
-EN/SERVICE /REP
345
VOLTS
BTU-COOLING
115
8000
ROOM AIR CONDITIONER
Model No.
FAK083J7V1
©2000 White Consolidated Industries, Inc.
All rights reserved
Advertisement
Related Manuals for Frigidaire FAK083J7V1
Summary of Contents for Frigidaire FAK083J7V1
- Page 1 PRODUCT NO. BASE MODEL NO. FAK083J7V1 FAK083J7V WIRING DIAGRAM # - A232012 OWNERS GUIDE # - 309000816 P.O. Box 212378 Augusta, GA 30917 Publication No. 5995338836 000413 -EN/SERVICE /REP FACTORY PARTS CATALOG ROOM AIR CONDITIONER VOLTS ROOM AIR CONDITIONER Model No.
- Page 2 FAK083J7V1 CABINET FRONT AND WRAPPER P40V0105 4/00...
- Page 3 POS. NO. 4/00 FAK083J7V1 CABINET FRONT AND WRAPPER PART NO. 309622004 5303317604 5304414855 309622204 309622103 309622104 309622304 309622404 309622609 309307011 3015312 DESCRIPTION Cabinet Grille,rear Link,louver Louver,Horizontal Louver,vertical ,(4) Louver,vertical ,w/handle Filter Front,cabinet ,complete Dial plate Knob-control Screw,8-18 x 0.47 # = Functional Parts...
- Page 4 FAK083J7V1 CONTROL PARTS 4/00...
- Page 5 POS. NO. 13 # 17 # 4/00 FAK083J7V1 CONTROL PARTS PART NO. DESCRIPTION 309606501 Panel-mounting,controls 5303323284 Switch-selector 5304409252 Control-temperature 309321201 Clip-control bulb 5303303125 Capacitor,370 V ,35-5 5303303077 Strap-capacitor 309343105 Cord-electric power,type A 5303007754 Screw,.138-32 x .188 309625301 Control-vent door 309606402...
- Page 6 FAK083J7V1 AIR HANDLING PARTS 4/00...
- Page 7 POS. NO. 11 # 4/00 FAK083J7V1 AIR HANDLING PARTS PART NO. 3202975 309620501 309626001 309617704 309625201 5303012110 309624801 5303313964 309624901 309624601 DESCRIPTION Screw,10-16 x 0.72 ,square drive Housing-fan Fan Blade Motor-fan Blower Wheel,plastic Clamp-blower Housing-blower Seal,condenser ,upper Adaptor,housing-blower Back Plate,housing-blower...
- Page 8 FAK083J7V1 COMPRESSOR PARTS 4/00...
- Page 9 POS. NO. 10 # 16 # 16A # 17 # 4/00 FAK083J7V1 COMPRESSOR PARTS PART NO. 309616910 5303015945 5303015946 3201668 5304405245 5303317553 3201670 5303317601 309617003 309617307 309624101 5303001746 5303001746 309325202 5303313964 309614105 DESCRIPTION Compressor-Tec RGA5472EXA Grommet,compressor ,(3) Nut,plastic ,compressor ,(3)
- Page 10 POS. NO. 4/00 FAK083J7V1 WINDOW MOUNTING PARTS PART NO. 5303313968 5303211056 5304414856 5308013771 5303295750 5308047516 5304414858 5304414861 5304414857 5308047524 5308047558 5308047562 5303313967 5303302870 5300125233 5300507212 5300507693 5300516543 309305302 309625802 DESCRIPTION Seal,frame ,top Bracket Bracket-support Screw-wood,rnd hd ,8-15 x 0.750 Screw,8-18 x 0.750...
- Page 11 FAK083J7V1 WIRING DIAGRAM 4/00...
