- Page 1 User Manual 1/2.8" HD Camera, Day&Night, 3840x2160, Infrared, WDR, 2.7-13.5mm, 12/24V, IP67 MCB-68V2713M0A...
-
Page 3: Safety Precaution
ULTRA CLEAR RESOLUTION CAMERA Safety Precaution To prevent electric shocks and risk of fire hazards, do NOT use other than specific power source. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. - Page 4 ULTRA CLEAR RESOLUTION CAMERA Safety Precaution NOTICE The image used in this instruction manual are processed to help comprehension and may differ from actual video of the camera. Avoid installing areas where has shock or vibration which results in the problems. Pay attention to safety when laying the connection cable and observe that the cable is not subjected to heavy loads, kinks or damage and no moisture can get in.
-
Page 5: Table Of Contents
ULTRA CLEAR RESOLUTION CAMERA Contents p.03~04 Safety Precaution p.05 Contents p.06 Features p.07 Composition p.07 Dimensions p.08 Part Names p.09~14 Installation Instructions p.15~34 Operating Instructions p.35 Specifications... -
Page 6: Features
ULTRA CLEAR RESOLUTION CAMERA Features Key Features • 8Mega Pixel CAMERA, 3840x2160(15/12.5fps) • The best low light performance with SONY’s STARVIS sensor • Video output EX-SDI / HD-SDI / THD / CHD / AHD / CVBS(960H) Selectable • THD mode / AHD mode / CHD mode, Video Transmission Distance over Coax.;... -
Page 7: Composition
ULTRA CLEAR RESOLUTION CAMERA Composition Sunshield Plastic Anchor: 6 x 30mm (4pcs) Mounting Screw: 4 x 30mm (4pcs) Hex Wrench: 3mm (1pc) Cable Tie (2pcs) Camera unit Hinge Pin (1pc) Grommet (2pcs) Operating Mounting Video Sub-out Cable fixation plate Wiring Instruction Template Cable... -
Page 8: Part Names
ULTRA CLEAR RESOLUTION CAMERA Part Names Sunshield Junction Box TOP Junction Box BASE Bracket Body Case Hinge Pin Dual Window 2x Lock/Unlock Screw 2x Water drain Inside of Opening Cover OSD Control Joy Stick Video Sub-out Connector Video format Switch CAUTION •... -
Page 9: Installation Instructions
ULTRA CLEAR RESOLUTION CAMERA Installation Instructions Install the mount onto a strong structure such as a concrete or steel beam, etc. Use the supplied accessories when installing the mount to a structure, make sure that all the screw parts are metallic. ①... - Page 10 ULTRA CLEAR RESOLUTION CAMERA Installation Instructions ⑥ Hook up the Junction Box Top with the Junction box base by the hinge pin. ⑦ Connects the Power/Video cables from camera as illustrated. Fix the Power/Video cables from camera to junction box base using the supplied screw.
- Page 11 ULTRA CLEAR RESOLUTION CAMERA Installation Instructions ⑨ Set the camera’s orientation and tighten the lock/unlock screw using hex wrench. ⑩ If necessary, open the opening cover and connect the video sub-out cable for OSD menu setting. ⑪ After all the setting, close the opening cover and tighten with the hex wrench.
- Page 12 ULTRA CLEAR RESOLUTION CAMERA Installation Instructions Pan & Tilt adjustments • Unlock the screw on the camera bracket through using the torque wrench supplied • Set the camera’s viewing angle then lock the screw on the bracket. 1) Pan limit: Pan is limited to +/- 90°.
- Page 13 ULTRA CLEAR RESOLUTION CAMERA Installation Instructions Sunshield Assembling • After all adjustments, assemble the sunsheild with the camera unit as illustrated. ① Cover the sunsheild to the camera unit. ② Slide foward to straight the camera front case. ③ Push down the front part of sunshield until clicking sound. Make sure the sunshield is fixed with camera.
- Page 14 ULTRA CLEAR RESOLUTION CAMERA Installation Instructions Power Supply connections Camera can work with either AC24V or DC12V, dual voltage power. Primary and secondary grounds are completely isolated to avoid the possible ground-loop problems HD ANALOG EX/HD SDI AC24V/DC12V (RED) AC24V/GND (BLK) N/A (ORG) N/A (GRY)
-
Page 15: Operating Instructions
ULTRA CLEAR RESOLUTION CAMERA Operating Instructions Using OSD controller Setup menu can be accessed and controlled by OSD control joystick on the side of camera unit. Five commands are available with the joy stick. The design of OSD could be different according to the Model. OSD Control Joy Stick Cover Open... - Page 16 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions OSD menu Table MENU SUB MENU CONFIGURATION LENS MODE (INDOOOR, OUTDOOR, DEBLUR) MANUAL ZOOM / FOCUS AF MODE ZOOMPUSH, MANUAL MODE CHANGE ENABLE, DISABLE D&N FILTER SYNC ON, OFF INITIAL ON, OFF EXPOSURE BRIGHTNESS DAY 0~20 0~20 BRIGHTNESS NIT SHUTTER...
-
Page 17: Zone Num
ULTRA CLEAR RESOLUTION CAMERA Operating Instructions AUTO, AUTOext, PRESET, MANUAL (C-TEMP, R/B-GAIN) PICT. ADJUST 0~20 COLOR GAIN DAY 0~20 COLOR GAIN NIT SHARPNESS 0~10 GAMMA 0.45, 0.5, 0.55, 0.6, 0.65, 0.7, 0.75 D-WDR OFF, LOW, MIDDLE, HIGH DEFOG MODE, LEVEL OFF, ON SHADING OFF, ON... - Page 18 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions Supported resolution according to Video format. DIP Switch (EX-SDI set) ANALOG OUT THD / CVBS-SUB AHD / CVBS-SUB CHD / CVBS-SUB CVBS EX-SDI FRAME RATE(NT/PAL) [ THD MODE ] [ AHD MODE ] [ CHD MODE ] 2160P 15 /12.5 15P(O) / 12.5P(N/A) 1440P 30/25(CROP)
- Page 19 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions OSD menu Startup Press the ‘OSD menu SET key’ down to access the setup menu mode. • EXIT : Enters ‘EXIT’ menu with save current setting or without save. • RETURN : Returns to the previous menu. MENU V0.
- Page 20 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions 2. ZOOM/FOCUS 2-1. AF MODE • ZOOMPUSH: Focusing works steadily for sharp focusing on the object. In the case of a Motor driven lens, focusing resumes in about 7~8 seconds to save the lens lifetime when the focus gets lost. •...
- Page 21 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions 3. EXPOSURE 3. EXPOSURE BRIGHTNESS DAY llllllllllllllllllllll BRIGHTNESS NIT llllllllllllllllllllll SHUTTER AUTO SENS-UP llllllllllllllllllllll 3D-NR MIDDLE RETURN 3-1. BRIGHTNESS DAY Adjusts the brightness of video in DAY mode (0~20). 3-2. BRIGHTNESS NIGHT Adjusts the brightness of video in NIGHT mode (0~20). 3-3.
-
Page 22: H-Pos
ULTRA CLEAR RESOLUTION CAMERA Operating Instructions 3-6. 3D-NR DNR function improves picture quality by filtering out signal noise which is generated under the low light conditions. Sets off, low, middle or high level. 3DNR(3-dimensional noise reduction) which reduces the noise by the multi frames. - Page 23 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions 4-2. BLC (Backlight Compensation) This function is used to brighten an image in the foreground with a highly light area behind it such as sunlight, limiting the affect of silhouette. BLC has a target window for compensation and its size and position can be set by H-POS, V-POS, H-SIZE and V-SIZE.
-
Page 24: Pos0-X
ULTRA CLEAR RESOLUTION CAMERA Operating Instructions • BOX : Set area to select zones by square. WINDOW ZONE : Set the detection zone number from 0 to 3. WINDOW USE : Sets ON/OFF motion detection area which you selected. If set to ON, It can be adjusted position and size. H/V-POS : Adjusts the ROI area H, V position which you selected zone. - Page 25 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions 5. DAY & NIGHT DAY/NIGHT is used to control the setting during day-time and night-time operation. Select the mode according to the light condition and the camera types. MENU V0. XX 1. LENS 5. DAY&NIGHT 2.
- Page 26 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions 5-2. AUTO Used when DAY or NIGHT is 5. DAY&NIGHT determined by light level through the lens and DAY from/to NIGHT SMART IR FULL is switched automatically by the ANTI-SAT. llllllllllllllllllllll scene brightness. D>N THRES llllllllllllllllllllll N>D THRES llllllllllllllllllllll...
- Page 27 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions 5-4. COLOR D/N Forcibly Color mode, optimized for night condition. It is available to recognize colors of car, people and moving objects even at night. Parameters can be controllable & programmable according to circumstance. Application for bright circumstance at night such as downtown, civic area, street, mall and etc.
- Page 28 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions 6. PICT. ADJUST PICT. ADJUST AUTO COLOR GAIN DAY llllllllllllllllllllll COLOR GAIN NIT llllllllllllllllllllll SHARPNESS llllllllllllllllllllll GAMMA D-WDR MIDDLE DEFOG SHADING RETURN 6-1. AWB Automatically tracks the changes of color temperature and continuously adjusts the white balance. AUTO, AUTOext, PRESET and MANUAL modes are available.
- Page 29 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions 6-5. GAMMA Adjust gamma level of video. 6-6. D-WDR Improves the visibility for the high bright area and the dark area by compen- sating the video gain. Care should be taken to select low, middle or high level, because video may lose its quality in some environments by the over compensation.
- Page 30 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions 7. DIS (Digital Image Stabilization) 7-1. RANGE Sets the image compensation range. 10%, 20%, 30%. Higher values attempt to stabilize the image against big displacement but the field of view is narrowed. 7-2. FILTER : LOW, MIDDLE, HIGH Sets the sensitivity to initiate DIS function.
- Page 31 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions 8-4. PRIVACY Set the Privacy zones which can be enabled individually by BOX or POLYGON are available to mask the video. 8-4-1. BOX : Set area to select privacy zones by square. • ZONE NUM : Set a number to select a privacy zone from 1~10. •...
- Page 32 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions 8-5. MOTION 4 motion detection areas are available and each area is programmable in size and location. The motion can be detected the changes in the motion areas and displays the results in blocks and/or a text message. 8-5-1.
- Page 33 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions 8-5-5. MOTION OSD Sets ON or OFF to display the motion results. 8-5-6. TEXT ALARM Setting ON enables to display a text message ‘ WINDOWS MOVING!!’ or icon when the motion is detected. 9. SYSTEM Sets the system related functions.
- Page 34 ULTRA CLEAR RESOLUTION CAMERA Operating Instructions 9-1-3. TV SYSTEM Selects HDTV standards for US(60HZ) or EU(50HZ). By this selection, 2nd analog video output switches to NTSC or PAL accordingly. 9-1-4. SDI OUTPUT HD-SDI or EX-SDI is selectalbe by video format switch on OSD board only. 9-1-5.
-
Page 35: Specifications
ULTRA CLEAR RESOLUTION CAMERA Specifications NTSC ITEM Imaging Sensor Sony 1/2.8” 8.46 Mega pixel STARVIS CMOS Sensor Effective Pixels 3864 (H) × 2192 (V) approx. 8.46M Mega pixels Scan Frequency 30Hz(V), 22.5Khz(H) / Progressive 25Hz(V), 18.75Khz(H) / Progressive Video Format 3840x2160p @15/12.5fps, 2560x1440p @30/25fps, 1920x1080p @30/25fps NTSC/PAL (16:9) Video Output EX-SDI, HD-SDI, THD mode, CHD mode, AHD mode, CVBS(960H) - Page 36 Videor E. Hartig GmbH Exclusive distribution through special- ised trade channels only. Videor E. Hartig GmbH Carl-Zeiss-Straße 8 63322 Rödermark/Germany Tel. +49 (0) 6074 / 888-0 Technical changes reserved Fax +49 (0) 6074 / 888-100 www.videor.com...
