- Page 1 User Manual Stellar 2020 V2.0 04.06.20...
- Page 2 Inhaltsverzeichnis What’s in the box? Frame number Assembly Power on the bike Ampler Bikes app Maintenance Electric system support Charger safety manual Cargo adapter for Thule trailer Specifications V2.0 04.06.20...
-
Page 3: What's In The Box
What’s in the box? The bike will arrive at your doorstep in a big cardboard box. Inside this you will find: The bicycle Ownership certificate Pedals 4 mm hex key 6 mm hex key Pedals Charger Reflectors (two yellow spoke reflectors, front- and rear reflector) *Optional: ABUS Bordo Lock and the lock keys;... - Page 4 Assembly You will need • 4 mm hex key • 6 mm hex key • Pedals Adjust the handlebar 1. Take the 4 mm hex key and loosen the side bolts of the stem. Turn the handlebar to the riding position. Make sure the handlebar is aligned with the front wheel.
-
Page 5: Montage
Montage Insert the pedals 1. Unwrap the pedals. The pedals are marked with R (right) or L (left). The R pedal goes on the chainwheel side and the L pedal goes on the non-chainwheel side. 6 mm 2. Tighten the pedals with the 6 mm hex key Pedals need to be tight so make sure you put some Pedals need to be tight so make sure you put some force into it. - Page 6 3. Check the drivetrain. Pedal by hand and check if the chain or the belt drive runs freely. Shift the gears on the 10-speed bike. 4. Check your bike visually. Does everything seem alright? Remember to check your bike occasionally and view our Ampler Bikes Maintenance information. Adjust the seat height Take the 4 mm hex key and adjust the perfect seat height 1.
-
Page 7: Power On The Bike
To turn the lights ON and OFF, hold the power button for 1–2 seconds. You can turn the lights on/off also from your Ampler mobile app. The bike will remember the last setting, so the lights will be ON when you leave them on next time you power the bike. - Page 8 Boost Mode (assist mode 2). You can also change the support modes on the dashboard of your Ampler app. You can fully customise the assist modes with the Ampler Bikes app under the ‘Vehicle settings’. bike is ON...
- Page 9 (Android 4.4 onwards) in play store. Download the app, stay close to your bike, switch on the Bluetooth, pair your handy with your bike and log in. The Ampler smartphone application lets you fully customise your riding experience with the Ampler e-bike.
-
Page 10: Maintenance
3000 km or at least once a year. The actual needed maintenance interval can vary depending on your riding habits, road quality and weather conditions. Maintaining your Ampler bike is just like maintaining a regular bicycle and all professional bike shops can carry out the maintenance of our bikes. - Page 11 • When you finish cycling in the cold, make sure that the bike has time to warm up a little before you charge it. Professional maintenance Maintaining your Ampler bike is just like maintaining schedule a regular bicycle and all professional bike shops can carry out the maintenance of our bikes.
- Page 12 Maintenance If you ride often and don’t count the riding distance, make sure to take it to a professional bike shop for maintenance at least twice every season, ideally even three times • Before the start of the season • Mid-way through •...
- Page 13 2. Turn on the bike again from the power button. Torque sensor calibration Ampler bikes are pedelecs and they have sensors regulating the motor, measuring the speed of pedalling and your own input power. Therefo- re, the bike is easy to use and the motor power is controlled according to your own pedaling force.
- Page 14 Electric system support Firmware update Firmware update is done via the Ampler mobile app. If your bike is connected to the app, you will get a notification in your app about the new available Firmware. Please go to the Vehicle settings to update your Firmware.
- Page 15 The charger is designed for indoor use only. Do not expose it to rain, snow or expose the device to elevated temperatures. Only use the genuine Ampler charger designated for your Ampler e-bike. Do not use this charger for other batteries. Also, do not use other battery chargers for your Ampler e-bike.
- Page 16 Do not remove the motor torque washer from the dropout – keep it attached to the axle. 2. Attach the Ampler motor axle adapter to the frame.Use a 19 mm wrench and make sure the axle adapter is securely fastened.
-
Page 17: Specifications
Specifications Sizes Small 48 cm, Medium 55 cm Parts Frame Aluminum Alloy 6061 Fork Aluminium 1 1/8”, 12 mm thru axle Crankset Alloy 42T, 170 mm Bottom Bracket Sealed BB with a torque sensor Gear shift Shimano Deore RD-T6000 10-speed Chain Shimano/ Sram compatible 10 speed chain Brakes...
