Setting Up Audio Streams - Genelec 4420A Quick Setup Manual

The 4420A supports automatic negotiation with the IP switch or IP power injector
to set the PoE power level. However, in some cases it may be necessary to set
the PoE power level in the switch manually.
Name Standard
PoE IEEE 802.3af-2003
PoE+ IEEE 802.3at-2009
There are several Power-over-Ethernet standards. The 4420A loudspeaker
supports the PoE+ standard but also works with the lower power PoE standard.
When the 4420A also works with lower PoE power, the duration of high SPL
output is shortened, and long continuous output signals play at smaller sound
level than when the PoE+ power level is used. Genelec recommends using PoE+
power level with 4420A.

5 SETTING UP AUDIO STREAMS

Audio stream setup is done by using Dante Controller software. Download from
https://www.audinate.com/products/software/dante-controller
4420A can receive up to two audio
channels in a stream. Assign a
channel in the Transmitters list for
each 4420A input listed in the
Receiver list.
Power to 4420A
13 W
25.5 W
