Crystalline Silicon PV Module Installation Manual
1. Introduction
1.1 Purpose
1.2 Limitation of Liability
1.3 Precautions for Installation
2. Safety
2.1 General Safety
2.2 Installation Safety
3. Mechanical Installation
3.1 Installation Condition
3.2 Installation Methods
4. Electrical Installation
4.1 Installation Condition
4.2 Grounding
5. Maintenance
Chint Solar (Zhejiang) Co.,Ltd. | Add:1335 Bin´an Road, Binjiang District, Hangzhou | P.C: 310053
Tel: 0086-571-5603 1888 | Fax: 086-571-5603 2316 | Website: http://energy.chint.com/
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Astronergy CHSM60M/F-B
Summary of Contents for Astronergy CHSM60M/F-B
- Page 1 Crystalline Silicon PV Module Installation Manual 1. Introduction 1.1 Purpose 1.2 Limitation of Liability 1.3 Precautions for Installation 2. Safety 2.1 General Safety 2.2 Installation Safety 3. Mechanical Installation 3.1 Installation Condition 3.2 Installation Methods 4. Electrical Installation 4.1 Installation Condition 4.2 Grounding 5.
- Page 2 1. Introduction 1.1 Purpose This document provides detailed instructions and valuable safety information regarding the installation, electrical connection, and maintenance of following Chint Solar Crystalline Photovoltaic modules: CHSM60M(DG)/F-B CHSM60M(DGT)/F-B CHSM72M(DG)/F-B CHSM72M(DGT)/F-B CHSM60M(DG)/F-BH CHSM60M(DGT)/F-BH CHSM72M(DG)/F-BH CHSM72M(DGT)/F-BH All the instructions should be read and understood before installation. The installers should be trained and conform to all safety precautions in this guide when installing the module.
- Page 3 recommended to take the right amount of modules according to the progress of the project every day. Heavy rain and other inclement weather may have the potential to soak the packaging which can affect product reliability, such as storms, typhoons, hurricanes or other events in which they may be blown away.
-
Page 4: Installation Safety
2. Safety 2.1 General Safety 2.1.1 Consult and follow local codes and other applicable laws concerning required permitting as well as installation & inspection requirements, rules, and regulations. 2.1.2 PV modules should be installed and maintained by qualified personnel. 2.1.3 Use the same performance modules within a given series. 2.1.4 Follow all safety precautions of all components used in the system. - Page 5 2.2.7 Do not unplug the connector under load. 2.2.8 Do not work alone. 2.2.9 Wear a safety harness if working far above the ground. 2.2.10 Do not wear metallic jewelry, which can cause electric shock, while installing or troubleshooting the PV system. 2.2.11 Follow the safety regulations for any and all other system components, including wires, connectors, charging regulators, batteries, inverters, etc.
-
Page 6: Installation Methods
materials should be higher than Class A. 3.1.6 To maintain the modules’ fire performance type 3(for US market), it could be possible to achieve the Class A system fire rating, with the Class A class racking system. Installation Methods 3.2.1 Bolting through the mounting holes ①... - Page 7 Figure 5 3.2.2 Clamping on the frame surface 3.2.2.1 Double glass module During the installation of bifacial modules, the frame and mounting rack should maintain parallel, as shown in figure 6 and figure 7. Figure 6 Chint Solar (Zhejiang) Co.,Ltd. | Add:1335 Bin´an Road, Binjiang District, Hangzhou | P.C: 310053 Tel: 0086-571-5603 1888 | Fax: 086-571-5603 2316 | Website: http://energy.chint.com/...
- Page 8 Figure 7 Remark: 1) The length of supporting bars must be longer than the length of module frame, otherwise please confirm with our product team to get approval. 2) As for above figure 6, the solid red rectangles indicate primary clamp installation positions and the center positions of long frames where clamps can be added for additional support.
- Page 9 5) Each aluminum clamp is equipped with a M8 bolt, a plain washer, a spring washer and a M8 nut, to fasten the module: a) Place the module on the two supporting bars (not provided). The bars should be made with stainless material and treated with an anti-corrosion process (e.g., anodic oxidation treatment) or aluminum profile.
-
Page 10: Electrical Installation
4 Electrical Installation 4.1 Installation Condition 4.1.1 The electrical characteristics are within ±10% of the indicated values of Isc. Voc and Pmpp under the standard test conditions (irradiance of 1000 W/m , AM1.5 spectrum, cell temperature of 25℃. 4.1.2 The IEC & UL standard maximum system voltage for the bifacial module series is 1500V. 4.1.3 Connect quantity of modules that match the voltage specifications of the inverters used in system. -
Page 11: Maintenance
4.2 Grounding (n) Grounding the aluminum frame with copper wire 4.2.1 The grounding requirements must be checked in accordance with the applicable regulations and standards before work is started. 4.2.2 Use the marked 5.5 mm grounding holes to ground the anodized frame. Use one M5 nut, two M5 cut washers, one M5 plain washer, one M5 spring washer, and one M5 bolt and the copper wire. - Page 12 5.2 If snow is present, a soft-bristled brush with soft bristles may be used to clean the surface of the modules. Regular electrical and mechanical inspection by a licensed professional will keep the system safe and operating at maximum efficiency. 5.4 Recommended PV module Clean-up period To get high output performance, PV module needs to be cleaned-up periodically as below: ①...
- Page 13 CHINT SOLAR (ZHEJIANG) Co., Ltd. Add: 1335 Bin’an Rd, Binjiang District, Hangzhou, China 310053 Tel: 86-571-5603 1888 Fax: 86-571-5603 2333 http://energy.chint.com/ Chint Solar (Zhejiang) Co.,Ltd. | Add:1335 Bin´an Road, Binjiang District, Hangzhou | P.C: 310053 Tel: 0086-571-5603 1888 | Fax: 086-571-5603 2316 | Website: http://energy.chint.com/...
