- Page 1 Glen Dimplex Thermal Solutions Dimplex System M Compact Plus 6kW 06CHOIAOC6 06IHOIAOC6 Installation and Operating Instruction Air-to-Water Heat Pump in Integral Design Order no.: DOK4x HOIAO WxDEN EN · FD 9912...
-
Page 3: Table Of Contents
Air-to-water heat pump 6 kW English Table of contents Please read immediately...........................3 1.1 Intended use..................................... 3 1.2 Legal regulations and directives ............................3 1.3 Energy-efficient use of the heat pump..........................3 Intended use of the heat pump ........................4 2.1 Area of application.................................. 4 2.2 Operating principle................................. - Page 4 English Air-to-water heat pump 6 kW 17 Declaration of conformity ..........................33 DOK4x HOIAO WxDEN · FD 9912 www.gdts.one...
-
Page 5: Please Read Immediately
Air-to-water heat pump 6 kW English Please read immediately 1.1 Intended use 1.3 Energy-efficient use of the heat pump This device is only intended for use as specified by the manu- facturer. Any other use beyond that intended by the manufac- By operating this heat pump you are helping to protect our en- turer is prohibited. -
Page 6: Intended Use Of The Heat Pump
English Air-to-water heat pump 6 kW Intended use of the heat pump 2.1 Area of application The air-to-water heat pump is to be used exclusively for heating of heating water and domestic hot water. It can be used in new or existing heating systems. -
Page 7: Scope Of Supply
Air-to-water heat pump 6 kW English Scope of supply 3.1 Indoor unit Hydraulic systems Combination cylinder, consisting of: 26 l buffer tank and domestic hot water cylinder with 151 l capacity Domestic hot water sensor Flange with magnesium anode Drainage domestic hot water cylinder Purging Safety valve, start-to-leak pressure 2.5 bar Expansion vessel (18 l) -
Page 8: Outdoor Unit
English Air-to-water heat pump 6 kW 3.2 Outdoor unit Evaporator Expansion valve Switch box Connection for refrigerant line DOK4x HOIAO WxDEN · FD 9912 www.gdts.one... -
Page 9: Transport
Air-to-water heat pump 6 kW English Transport 4.1 Outdoor unit To remove the refrigeration circuit, remove the side plate at the bottom right. A pallet should be used to transport the heat pump to its final The casing panels must be dismantled in the order outlined be- installation location. -
Page 10: Removing The Refrigeration Circuit
English Air-to-water heat pump 6 kW 4.3 Removing the refrigeration circuit To make transport easier, the refrigeration circuit can be dis- mantled and transported separately. Removing it enables the indoor unit to be transported horizontally. The following connections must be disconnected: Disconnect the water circuit connection Disconnect the plug connections on the refrigeration cir- cuit switch box... -
Page 11: Installation
Air-to-water heat pump 6 kW English Installation 5.1 Outdoor unit If multiple outdoor units are set up next to each other, the re- quired minimum distance at the side adds up. Ensure that the Among other things, when selecting the installation locations cold expelled air is not sucked in again. -
Page 12: Indoor Unit
English Air-to-water heat pump 6 kW 5.2 Indoor unit 5.3 Acoustic emissions The indoor unit must be installed in a frost-free, dry room on an The heat pump operates silently due to efficient sound insula- even, smooth and horizontal surface. The entire base of the tion. -
Page 13: Assembly / Connection
Air-to-water heat pump 6 kW English Assembly / connection 6.1 Assembly of the refrigerant line Once the heat pump has been connected to the heating sys- tem, it must be filled, purged and pressure-tested. and electric wire When doing so, it must be ensured that all heating circuits and isolating valves are open and that the 3-way reversing valve is in The refrigerant lines and electric wires for connecting the in- heating operation (pos. -
Page 14: Domestic Hot Water Connection
English Air-to-water heat pump 6 kW 6.4 Domestic hot water connection Specific system volume Total Total heat (VDI 2035) in l/kW Alkaline earths Installation and commissioning must be performed by an au- output in in mol/m³ and/ thorised specialist company. The entire system, including all 20 <... -
Page 15: Temperature Sensor Connection
Air-to-water heat pump 6 kW English 6.5 Temperature sensor connection The following temperature sensors must also be mounted: Outside temperature (R1) is (NTC-2) The following temperature sensors are already installed: Return temperature (R2) installed (NTC-10) Demand sensor (R2.2) installed (NTC-10) ... -
Page 16: Electrical Connection
English Air-to-water heat pump 6 kW 6.6 Electrical connection 6.6.1 Circuit diagram Symbol legend, see cap. 6.6.2 on page 15 Equipment marking, see cap. 6.6.3 on page 15 DOK4x HOIAO WxDEN · FD 9912 www.gdts.one... - Page 17 Air-to-water heat pump 6 kW English 6.6.2 Symbol legend 6.6.3 Equipment markings +A100 Refrigeration circuit Connector +A110 Outdoor unit +A200 Hydraulics /WPM Plug connection +A210 Master unit +A220 Expansion module WPM Compressor / refrigeration circuit +A300 Electrical distribution system +A350 Router Fan / outdoor unit +A400...
- Page 18 English Air-to-water heat pump 6 kW 6.6.4 Electrical connection general Supply voltage hydraulics For the power supply to the 2nd heat generator, a wire All connection cables must be provided on-site. The cable type must be routed to the device according to the power (2,4,6 (cross-section, conductor type, etc.) must be chosen taking kW configurable) and connected to the hydraulic switch into account the relevant electrical parameters (e.g.
-
Page 19: Refrigerant Pipe Connections
Air-to-water heat pump 6 kW English 6.7 Refrigerant pipe connections HINWEIS NOTE If the indoor unit is mounted 2.5 m or more metres higher or lower than the outdoor unit, a cooling technology specialist ATTENTION! must perform a separate check to ensure that the devices for Work on the system must only be performed by authorised conveying the oil up and down the pipes have been installed and qualified after-sales service technicians. - Page 20 English Air-to-water heat pump 6 kW Step 4: Flanging Flanging must be carried out as follows with a flanging tool for R-410A refrigerant as shown in the figure. Open-end spanner (fixed) Handle Screw nut Rail Rail Connection pipe Torque spanners "A"...
- Page 21 Air-to-water heat pump 6 kW English Step 3: Evacuation Connect the vacuum pump on the maintenance valve (with Schrader). Run the vacuum pump until the relevant vacuum is reached. Close the vacuum pump and start filling immediately. The duration of the pumping empty process varies with differ- ent lengths of the pipework and the pump output.
-
Page 22: Commissioning
English Air-to-water heat pump 6 kW Commissioning 7.1 General The overflow valve should be opened far enough to produce the maximum temperature spread between the heat flow and To ensure that commissioning is performed correctly, it should heat return flow, listed in the following table, for the current only be carried out by an after-sales service technician author- heat source temperature. -
Page 23: Cleaning / Maintenance
Air-to-water heat pump 6 kW English Cleaning / maintenance 8.1 Maintenance It is then important that the system be thoroughly flushed using appropriate neutralising agents to prevent any damage from To protect the paintwork, avoid leaning anything against the being caused by cleaning agent residue remaining in the sys- device or putting objects on the device. -
Page 24: Faults / Troubleshooting
English Air-to-water heat pump 6 kW Faults / troubleshooting This heat pump is a quality product and is designed for trouble- ATTENTION! free operation. In the event that a fault should occur, it will be Before opening the device, ensure that all circuits are discon- indicated on the master unit display. -
Page 25: Device Information
Air-to-water heat pump 6 kW English 11 Device information Type and order code 06CHOIAOC6 06IHOIAOC6 Design System M Compact Plus System M Compact Plus Heat source Energy efficiency class high temperature Energy efficiency class low temperature Seasonal coefficient of performance (COP) for average climate 35°C/ 55°C 4.1 / 3.0 4.1 / 3.0 (SCOP in accordance with EN 14825) - Page 26 English Air-to-water heat pump 6 kW Type and order code 06CHOIAOC6 06IHOIAOC6 4.11 Volume expansion vessel litres 4.12 Start-to-leak pressure, safety valve Electrical connection Supply voltage / fusing / RCD type Compressor 1~/N/PE 230 V (50 Hz) / C20A / B 1~/N/PE 230 V (50 Hz) / C20A / B Pipe heater 1~/N/PE 230 V (50 Hz) / B32A / A 3~/N/PE 400 V (50 Hz) / B10A / A Control voltage / fusing via WPM...
-
Page 27: Dimension Drawing
Air-to-water heat pump 6 kW English 12 Dimension drawing 12.1 Dimension drawing outdoor unit www.gdts.one DOK4x HOIAO WxDEN · FD 9912... -
Page 28: Dimension Drawing Indoor Unit
English Air-to-water heat pump 6 kW 12.2 Dimension drawing indoor unit DOK4x HOIAO WxDEN · FD 9912 www.gdts.one... -
Page 29: Dimension Drawing Legend
Air-to-water heat pump 6 kW English 12.3 Dimension drawing legend Outdoor unit Connection refrigerant line 10 mm outdoor unit Connection refrigerant line 12 mm outdoor unit Condensate drain Feedthrough refrigerant lines and electric wires; condensate hose Optional feedthrough refrigerant line Optional feedthrough, electric wires External dimensions wood design variant Included pipe set for optional rear connection of the re-... -
Page 30: Diagrams
English Air-to-water heat pump 6 kW 13 Diagrams 13.1 Characteristic curves heating 6 kW Heat output in [kW] EN 14511 A7 W35...30 0,8 m³/h A7 W45...40 0,8 m³/h A7 W55...47 0,6 m³/h max. min. Air intake temperarure in [°C] Heating water temperature [°C] Power consumption (including proportion of pump output) [kW] max. -
Page 31: Product Information As Per Regulation (Eu) No 813/2013, Annex Ii, Table 2
Contact details Glen Dimplex Deutschland GmbH, Am Goldenen Feld 18, 95326 Kulmbach (*) For heat pump space heaters and heat pump combination heaters, the rated output Prated is equal to the design load for heating Pdesignh , and the rated heat output of a supplementary capacity for heating sup(Tj ). - Page 32 Contact details Glen Dimplex Deutschland GmbH, Am Goldenen Feld 18, 95326 Kulmbach (*) For heat pump space heaters and heat pump combination heaters, the rated output Prated is equal to the design load for heating Pdesignh , and the rated heat output of a supplementary capacity for heating sup(Tj ).
- Page 33 15 Warranty certificate The prerequisite for accepting the extended warranty is chargeable commissioning by the authorised after-sales service for complete Glen Dimplex Thermal Solutions systems (see fixed charges in the service price list) with an opera- Warranty certificate - System M...
-
Page 34: Information On The Use Of Data
16 Information on the use of data IV. Information on products and new developments. It is very important to Glen Dimplex Thermal Solutions (GDTS) that your data is handled correctly. We should therefore like to GDTS will use your contact details on occasion to show you provide you with information on the data collected when oper- new products and innovations relating to smart homes. - Page 35 Air-to-water heat pump 6 kW English 17 Declaration of conformity You can find and download the current CE conformity declaration at: https://gdts.one/m www.gdts.one DOK4x HOIAO WxDEN · FD 9912...
- Page 36 Glen Dimplex Thermal Solutions Zentrale Glen Dimplex Deutschland GmbH Am Goldenen Feld 18 D-95326 Kulmbach T +49 9221 709-100 F +49 9221 709-339 dimplex@gdts.one www.gdts.one Geschäftsstelle Österreich Glen Dimplex Austria GmbH Hauptstraße 71 A-5302 Henndorf am Wallersee T +43 6214 20330 F +43 6214 203304 info@dimplex.at...
